The Domino REST API Before Go-Live: the Security Model, One-Way Rich Text, CORS, and Admin Ports

The Domino REST API Before Go-Live: the Security Model, One-Way Rich Text, CORS, and Admin Ports

Aug 24, 2026 918 words
Domino REST API Security DevOps

This is the last part of the DRAPI series. The first five are done: overview, authentication, scope/schema, document CRUD, DQL querying. It all works — but before handing it to real users, a Domino developer usually has two question marks:

  1. Will it bypass the Readers-field security I carefully set, and leak documents that shouldn’t be seen?
  2. What will bite in production?

This part answers both.

TL;DR

  • It doesn’t leak: DRAPI is layered security — JWT (the docs say “All Domino REST API access is authorized using a signed JWT claim” and “No anonymous access is granted for REST data”), scope (only admin-configured databases are exposed), and Domino’s own ACL and Readers/Authors fields still count underneath.
  • secure-by-default: the docs say plainly “Databases aren’t automatically exposed on REST when you run Domino REST API. Only the ones configured by the administrators.”
  • Rich text is one-way: the docs say rich text is translated out to HTML/MIME, but it doesn’t translate MIME back to rich text.
  • Unconfigured fields are unreachable, and a missing item isn’t returned — the “absent ≠ empty” rule holds on the REST side too.
  • Close before going live: CORS configuration, and lock down the admin ports (console 8889, metrics 8890, health 8886) — don’t leave them exposed alongside the data port 8880.

1. Will it leak Readers-protected documents?

This is the first question a Domino developer asks of anything that puts an NSF on the web, and the right one. The answer: no — as long as you don’t dismantle the security yourself. DRAPI’s security is three stacked layers:

  1. JWT: the docs state “All Domino REST API access is authorized using a signed JWT claim,” and “No anonymous access is granted for REST data” — no anonymous access, every request carries a signed token.
  2. scope: the docs say plainly “Databases aren’t automatically exposed on REST when you run Domino REST API. Only the ones configured by the administrators” — an unconfigured database is invisible over REST.
  3. Domino’s own document-level security: the key one. Your JWT’s sub is a Domino name (part two), and DRAPI reads data as that Domino user — so that NSF’s ACL and Readers/Authors fields still count. A user authorized to see only group A of documents gets only group A over REST too — whether via CRUD, /lists, or DQL; what a Readers field blocks stays blocked over REST.

In other words, DRAPI doesn’t stand up a separate security scheme that bypasses Domino — it layers on top of Domino’s existing model. That’s why part three said “three layers at once”: the scope decides whether the door opens, and Domino’s ACL/Readers decide what you — this person — actually see behind it.

(The site’s earlier RAG webinar notes mentioned a related lesson: Domino IQ’s RAG also honors Readers fields — but that only really started working in 2026 FP1. Whether document-level security is being respected is worth verifying in your own environment, not just trusting the docs.)

2. The limits that actually bite

It works and it’s secure, but a few limits are best known at design time, not discovered after go-live:

  • Rich text is one-way out. The docs put it plainly: “The Domino REST API translates Rich Text to HTML/MIME. This is one way. The Domino REST API doesn’t translate MIME back to Rich Text.” Read a rich text field and you get HTML/MIME; but you can’t write rich text back the same way. For two-way rich-text editing, this is a hard limit.
  • Only configured fields are reachable: “Only configured fields can be created, read, or updated.” A field not in the schema / KeepConfig is inaccessible over REST even if the document really has it.
  • A missing item isn’t returned: “If an item doesn’t exist in a document, it doesn’t get returned.” So a key absent from the returned JSON may mean “this document has no such field,” not “the value is empty” — the same “absent ≠ empty” rule as getItemValue on the Java side.
  • Same-name forms/views are ambiguous: “When you have multiple views with the same name, the Admin UI selects the first one found.” With duplicate-named design elements, don’t assume it picks the one you meant.

3. Ports and CORS to close before going live

  • CORS: your front end usually runs on another origin, and the browser blocks cross-origin requests. DRAPI’s troubleshooting lists CORS as a common error when reaching the Admin UI or calling the API — get the allowed origins right before launch.
  • Lock the admin ports: data goes over 8880, but the console (8889), metrics (8890), and health-check (8886) admin/monitoring ports (from part two’s functional accounts) shouldn’t be exposed openly — firewall them off in production.
  • Other operational regulars: Address already in use at startup (port clash), OutOfMemoryError (Java heap), and bad JSON in keepconfig.d — all listed on the troubleshooting page, worth knowing before you deploy.

Series recap: see X, it’s usually Y

Six parts in, here are the traps you’re most likely to hit, in one table:

SymptomUsually
A call returns 401token expired, or the server restarted and rotated the signing key (part two)
You have a token but it’s blockedyour scope isn’t in the token, or Domino ACL/Readers blocked it (part three)
Correct DQL returns nothingthat form is missing a dql mode (part five)
Rich text won’t write backit’s a one-way conversion, unsupported by design (this part)
The browser front end can’t connectCORS isn’t configured (this part)

DRAPI turns an NSF into a modern, standard, language-agnostic REST API — but it doesn’t throw away Domino’s security and rules; it layers on top of them. Understand these six parts and you can expose an NSF cleanly and safely. End of series.
