Creating a Document in the Domino REST API: Why It Needs a Form Field and a dataSource

The last part opened the door — a schema decides what’s exposed, a scope gives it a name. This part does the real work: create, read, update, and delete documents in an NSF over REST, all in JSON. (If you haven’t stood DRAPI up yet, walk the official quickstart first.)

Coming from LotusScript, you’ll pause here: no NotesDocument, no ReplaceItemValue, no .Save. A document is a blob of JSON, and one HTTP verb is one operation. But two Domino-specific things need recognizing first: dataSource (your scope name) and the Form field.

TL;DR

• Every CRUD call carries a dataSource query param, whose value is the scope name you made last part — the docs are explicit that the scope name is the dataSource value used across all CRUD operations.
• Create: POST /api/v1/document?dataSource=<scope>, the body a JSON blob that must include a Form field naming the kind of document. The response @meta carries unid and noteid.
• Read: GET /api/v1/document/{unid}/{mode}?dataSource=<scope>.
• Update / delete: PATCH (partial), PUT (full replace), DELETE, all against /api/v1/document/{unid} with dataSource.
• mode is a DRAPI-specific concept: a form can have several modes (default, odata, dql…), each defining which fields you can see/write. Create uses the first, default, mode.

Create: POST /document

Creating a document is packing the fields into JSON, POSTing to the document endpoint, and naming the scope in the query string:

curl -X POST "http://localhost:8880/api/v1/document?dataSource=customers" \
  -H "Authorization: Bearer <token>" \
  -H "Content-Type: application/json" \
  -d '{
        "Form": "Customer",
        "first_name": "Madison",
        "last_name": "Branthwaite",
        "email": "mbranthwaite0@nba.com"
      }'

Two very Domino details:

• dataSource=customers: customers is your scope name, not a file path and not a replica ID. DRAPI uses the scope to find the NSF behind it and apply its schema.
• The Form field is required: it names which form the document uses — DRAPI uses it to look up the corresponding mode (fields and access rules) in the schema. It’s the same Form item a Domino document always had, only now you write it explicitly in the JSON.

On success the returned JSON gains an @meta object carrying the new document’s identifiers:

{
  "@meta": { "unid": "A1B2...C3D4", "noteid": 2458, "...": "..." },
  "Form": "Customer",
  "first_name": "Madison"
}

That unid is the handle you’ll use to read, update, or delete this document later.

Read: GET /document/{unid}/{mode}

With the unid in hand, read the document back:

curl "http://localhost:8880/api/v1/document/A1B2...C3D4/default?dataSource=customers" \
  -H "Authorization: Bearer <token>"

The default in the path is the mode (it’s optional; omit it and you get default). The returned JSON is the document’s fields — Domino items become JSON keys, multi-value fields become JSON arrays — plus an @meta.

Update and delete

Update and delete take the same /document/{unid} path with a different HTTP verb:

• PATCH /api/v1/document/{unid}?dataSource=<scope>: a partial update — the body carries only the fields you’re changing, the rest untouched.
• PUT /api/v1/document/{unid}?dataSource=<scope>: full replace.
• DELETE /api/v1/document/{unid}?dataSource=<scope>: delete it.

From a LotusScript angle, PATCH is probably the one you’ll reach for most — it maps to the everyday “open a document, change a few fields, save,” except you no longer open or save yourself; one request does it.

The thing that gives you pause: mode

mode is DRAPI-specific — classic Domino has no equivalent — and worth its own section. The design: a form’s schema can define several modes, each a set of rules for “from this angle, which fields you can see/write, and under what access conditions.”

• Creating a document uses the first mode, called default.
• Reading, you name in the path which mode to project the document through.
• Some modes have built-in purposes — OData access needs one named odata, for instance.

In other words, the same document can expose different subsets of fields through different modes. This is how DRAPI does field-level exposure control in the schema — you don’t dump the whole document out indiscriminately; the mode decides how much shows this time.

Wrap-up

A Domino document, on the REST side, is a blob of JSON with a @meta; POST / GET / PATCH / DELETE are create / read / update / delete; dataSource is always your scope name, the Form field names the document type on create, and mode decides which fields show. The next part reaches querying — when you want not a single document but “the batch that matches,” how you run DQL over REST and read views.
