Your DQL Is Correct but Returns Nothing? The Form Is Missing a dql Mode

The last part fetched a single document by unid. But most of the time you don’t want one document, you want the batch that matches — all incomplete todos, every customer in a region, all orders from this month.

DRAPI gives you two paths to a batch: read an existing view/folder (/lists), or run DQL (/query). This part walks both, and adds a trap that follows straight from the last part’s mode concept — a form without a dql mode is completely invisible to DQL.

TL;DR

• Read a view / folder: GET /api/v1/lists/{viewname}?dataSource=<scope>, paginated with count and start.
• Run DQL: POST /api/v1/query?action=execute&dataSource=<scope>, the body carrying a query string.
• DQL supports parameters: use ?VAR placeholders in the query and a variables object for the values — don’t concatenate user input into DQL.
• The mode trap: DQL only sees forms that have a dql mode — a form without one returns zero documents to DQL.
• DQL is opt-in: the schema needs dqlAccess: true, and you can add a dqlFormula (a Notes formula that must evaluate to @True) to restrict who may use it.

Read a view: /lists

If the data you want happens to have an existing view or folder, the easiest route is to read it directly:

curl "http://localhost:8880/api/v1/lists/Customers?dataSource=demo&count=25&start=0" \
  -H "Authorization: Bearer <token>"

Customers is the view name, and dataSource is your scope name as always (this /lists/{view} endpoint also accepts db= as an alias for dataSource — the official tutorial writes it that way; both work). Back comes a batch of entries from that view. Paginate with count (how many at once) and start (which entry to start from) — always paginate a big view rather than pulling it all at once.

This route is fast and reuses the view’s existing sort and selection; the limit is that you only get the view’s columns, and you’re bound to whatever views already exist.

Run DQL: /query

For more flexible conditional queries, run DQL. It’s a POST with the query in the body:

curl -X POST "http://localhost:8880/api/v1/query?action=execute&dataSource=todorest" \
  -H "Authorization: Bearer <token>" \
  -H "Content-Type: application/json" \
  -d '{
        "query": "form = '\''todo'\'' and completed = ?STATUS",
        "variables": { "STATUS": "false" },
        "maxScanDocs": 500000,
        "timeoutSecs": 300,
        "noViews": false
      }'

Back comes the batch of documents matching the DQL. Fields worth knowing:

• query: the DQL string itself.
• variables: the important one — DQL supports parameterized queries. Use a ?STATUS-style placeholder in the query and put the actual value in the variables object. Don’t concatenate user input straight into query; ?VAR + variables is the safe form, the same reasoning as a SQL prepared statement.
• maxScanDocs / timeoutSecs: guardrails on DQL scanning and timeout, so one bad query can’t drag the server down.
• noViews: whether DQL may use view indexes to speed itself up.

/query also takes count / start for pagination, like /lists.

The trap: DQL only sees forms with a dql mode

This is the easiest trap to hit, and it follows straight from the last part’s mode concept. You may already have a default mode on a form (so CRUD works), then run DQL and get zero documents of that form — not because the DQL is wrong, but because that form has no dql mode.

The docs are blunt:

If a form does not include a dql mode, no data for that form will be returned in DQL queries.

dql is one of DRAPI’s five reserved modes (default / dql / odata / raw / vsheet), and it’s not just a switch — the dql mode also decides which fields DQL returns. So to let a form be queried by DQL and control what it returns, you add a dql mode for it in the schema.

DQL is opt-in, and a formula can gate it

Even with a dql mode on the form, the DQL capability itself is enabled at the schema level: set dqlAccess: true. And you can add a dqlFormula — a Notes formula that must evaluate to @True for DQL to be allowed (the docs default it to @True, i.e. no restriction). That gives you a gate, written in familiar @formula, over who may run DQL and under what conditions.

Choosing between the two

• An existing view whose columns are enough → /lists/{view}. Fastest and leanest, reusing the view’s sort and selection.
• Flexible conditions, cross-field, dynamic → /query with DQL, and parameterize it.
• Both paginate (count / start), and both need the right mode: /lists uses default (or whichever you name on read), /query requires dql.

The next part closes the series: error handling and security — what errors look like on the REST side, whether Readers fields still count over DQL and lists, and the ports to close before you go live.
