Getting 401s from the Domino REST API? Understand Its JWT Authentication and Scopes First

Part one said almost every DRAPI call carries a token. This part covers how you get one, how you send it, and what’s actually inside it.

Coming from classic Domino, adjust your mental model first: DRAPI uses no session cookie and no LTPA. It follows the modern-API standard — a JWT bearer token: you exchange Domino credentials for a token, then send that token in a header on every request; the server verifies it to know who you are and what you’re allowed to touch.

TL;DR

• The login endpoint is POST /api/v1/auth: the body is {"username": "...", "password": "..."} (a Domino account + its HTTP password), and you get back a JWT.
• Every later request carries Authorization: Bearer <token>.
• The token is a JWT: the docs say “All actions in Domino REST API are secured with JWT.” Its claims decide who you are (sub), what you can reach (scopes), who it’s for (aud must be Domino), and when it expires (exp).
• Tokens come from three places: Domino-signed JWT (the /auth endpoint), an external OIDC provider (Entra ID / Keycloak), and OIDC managed centrally via idpcat.nsf (HCL’s recommendation, Domino 14+).
• A common trap: the Domino-signed default is “a random symmetric key that changes every time DRAPI restarts” — so a restart invalidates every previous token. Set RSA key files for stable tokens.

Logging in: POST /api/v1/auth

The most direct route is to exchange a token with Domino’s own auth endpoint. The official login example does exactly this:

curl -X POST http://localhost:8880/api/v1/auth \
  -H "Content-Type: application/json" \
  -d '{"username": "KEEP Admin", "password": "passw0rd"}'

username is the Domino account, password is its HTTP password. A successful login returns a chunk of JSON with your bearer token inside (paste it into jwt.io to read what’s in it).

Once you have the token, every following request carries it in a header:

curl http://localhost:8880/api/v1/... \
  -H "Authorization: Bearer eyJhbGciOiJSUzI1Ni.....(your token)"

The Swagger UI works the same way — paste the token into the Authorize box and every endpoint you try on the page carries it.

What’s inside the token

A JWT isn’t opaque gibberish — it’s a readable set of claims. The ones DRAPI cares about:

{
  "sub": "CN=John Doe/O=MyOrg",
  "scopes": "MAIL $DATA",
  "aud": "Domino",
  "iat": 1618506339,
  "exp": 1618509939
}

• sub — who you are, the Domino hierarchical name.
• scopes — which scopes you can reach, space-separated (e.g. MAIL $DATA, or a database’s scope alias). This is the heart of permissions; the next part covers how a scope is defined.
• aud — who the token is for; it must be Domino, or the server rejects it.
• exp — when it expires. Past that, log in again for a new one.

In other words, “can you do this” isn’t recomputed against the ACL on every call — your identity and scopes are sealed into the token the moment you log in.

Where tokens come from: three routes

/auth is just one route. Broadly, there are three ways a token gets issued or trusted; the larger your setup, the further down you should go:

1. Domino-signed JWT: the /auth route above, signed by Domino itself. By default it uses “a random symmetric key that changes on every Domino REST API restart” — convenient, but a restart invalidates every token already issued. For tokens that survive a restart, configure permanent RSA public/private key files (JwtPrivateKeyFile / JwtPublicKeyFile).
2. External OIDC provider: have DRAPI trust a standard OIDC provider (Microsoft Entra ID, Keycloak), with tokens signed by them. You set clientId and clientSecret and discover via .well-known/openid-configuration. If your enterprise already has an IdP, this is the natural route.
3. OIDC managed via idpcat.nsf (HCL’s recommendation): keep IdP configuration centralized in idpcat.nsf; requires Domino 14+.

There are also functional accounts (functional users), but their scope is narrower than you’d guess: the docs limit them to administrative / monitoring endpoints (Management console, Metrics, Health check), useful especially when the directory is unavailable — and state plainly that “they don’t need access to regular end points.” So don’t treat them as a general service account for the data API.

Two practical notes

• A restart invalidates tokens (the default self-signed key). In development you’ll hit “yesterday’s token 401s today” — usually the server restarted and rotated the key. Set RSA key files for stability.
• Scopes have to line up: the scopes in your token decide which databases you can touch. Call a resource whose scope isn’t in your token and you’re blocked. The token is fixed at login time; to reach something else later, get a fresh token carrying the right scope.

The next part moves to scopes and schemas — how the names in that scopes claim actually map an NSF into REST endpoints.
