NotesOutline + NotesOutlineEntry Deep Dive — Programmatic UI Navigation in Domino, 4 Entry Types, 24 Properties

TL;DR

• NotesOutline — HCL: “Represents an outline in a database. An outline supports a hierarchy of OutlineEntries and the NotesOutline class provides methods for navigation and manipulation of the individual OutlineEntries”
• NotesOutlineEntry — HCL: “Represents an entry within an outline”
• Containment: NotesOutline Contains NotesOutlineEntry; Contained by NotesDatabase
• 4 entry target types: OUTLINE_TYPE_NOTELINK (link to a document/db/view), OUTLINE_TYPE_NAMEDELEMENT (link to a view/form/folder by name), OUTLINE_TYPE_URL (URL link), OUTLINE_TYPE_ACTION (run @Formula)
• ⚠️ Outline is a legacy design element — XPages and modern Notes UI largely displaced it as the client navigation surface. But programmatic outline construction is still the right tool for multilingual menus, role-conditional navigation, and personalized link lists

What an outline is

An outline is the Domino application’s navigation design element — when you open a Notes app, the menu strip on the left is the outline. Each entry can link to a view, a document, a URL, or run a formula action.

Outlines are usually authored in Designer and exist statically. The cases where programmatic outline construction or modification comes up:

• Multilingual switching — update each entry’s Label based on user locale
• Role-conditional menus — dynamically hide / show entries based on ACL roles
• Personalized navigation — add user-specific links (bookmarks, recently opened docs)
• DXL export / import — outline structures for version control or cross-db replication

NotesOutline ↔ NotesOutlineEntry — containment

Per the official class definitions:

• NotesOutline — Contained by NotesDatabase, Contains NotesOutlineEntry
• NotesOutlineEntry — Contained by NotesOutline

In other words: get the outline first, then walk / create / modify / remove entries through it. Outline itself doesn’t expose a “list of entries” property; you traverse with GetFirst + GetNext etc.

Obtaining the outline and walking entries

Getting the outline

Two NotesDatabase methods:

Dim session As New NotesSession
Dim db As NotesDatabase
Dim outline As NotesOutline

Set db = session.CurrentDatabase

' Existing outline
Set outline = db.GetOutline("MainOutline")

' Or create new
Set outline = db.CreateOutline("MyNewOutline")

GetOutline returns Nothing if the outline doesn’t exist (no error thrown). CreateOutline builds an outline in memory — you must call outline.Save to actually persist it.

8 tree-walking methods

Per the official docs, NotesOutline exposes these 8 navigation methods:

The standard pattern for walking the entire outline:

Dim entry As NotesOutlineEntry
Set entry = outline.GetFirst()
Do Until entry Is Nothing
    Print entry.Label & " (Level " & entry.Level & ")"
    Set entry = outline.GetNext(entry)
Loop

GetNext traverses depth-first — into children, then siblings. Use GetNextSibling to stay at one level.

6 manipulation methods

NotesOutlineEntry — 24 properties

Read-write (modifiable)

Read-only

4 Set* methods — setting an entry’s target

NotesOutlineEntry provides 4 methods to set the target (one per Type):

⚠️ There is no SetView method — many examples online (and AI-generated code) write entry.SetView(db, "ViewName"), but that’s wrong, not documented by HCL. To link to a view, use SetNamedElement(db, "ViewName", OUTLINE_CLASS_VIEW).

4 Type constants (target type)

OUTLINE_TYPE_NOTELINK         ' Link to doc / db / view (via SetNoteLink)
OUTLINE_TYPE_NAMEDELEMENT     ' Link to a named design element (via SetNamedElement)
OUTLINE_TYPE_URL              ' Link to a URL (via SetURL)
OUTLINE_TYPE_ACTION           ' Run a formula (via SetAction)

Plus three system-type constants you may encounter when reading outlines (rarely set explicitly):

OUTLINE_OTHER_FOLDERS_TYPE    ' The "Other Folders" system entry
OUTLINE_OTHER_VIEWS_TYPE      ' The "Other Views" system entry
OUTLINE_OTHER_UNKNOWN_TYPE    ' Unknown type

9 EntryClass constants (which design element it links to)

When an entry’s Type is OUTLINE_TYPE_NAMEDELEMENT, the EntryClass tells you which kind of design element:

OUTLINE_CLASS_DATABASE        ' Whole db
OUTLINE_CLASS_VIEW            ' A view
OUTLINE_CLASS_FOLDER          ' A folder
OUTLINE_CLASS_FORM            ' A form
OUTLINE_CLASS_DOCUMENT        ' A document
OUTLINE_CLASS_FRAMESET        ' A frameset
OUTLINE_CLASS_NAVIGATOR       ' A navigator
OUTLINE_CLASS_PAGE            ' A page design element
OUTLINE_CLASS_UNKNOWN         ' Unknown

A complete example — create outline, add varied entries, walk, save

Sub Initialize
    Dim session As New NotesSession
    Dim db As NotesDatabase
    Dim outline As NotesOutline
    Dim entryView As NotesOutlineEntry
    Dim entryUrl As NotesOutlineEntry
    Dim entryAction As NotesOutlineEntry
    Dim entryHeader As NotesOutlineEntry

    Set db = session.CurrentDatabase
    Set outline = db.CreateOutline("DynamicNav")

    ' (1) Header — a group title (no target, just labeling)
    Set entryHeader = outline.CreateEntry("Quick Links", Nothing, "", Nothing)
    entryHeader.Label = "Quick Links"  ' Multilingual: change the Label

    ' (2) View link — use SetNamedElement + OUTLINE_CLASS_VIEW
    Set entryView = outline.CreateEntry("AllOrders", entryHeader, "", Nothing)
    entryView.Label = "All Orders"
    Call entryView.SetNamedElement(db, "(AllOrders)", OUTLINE_CLASS_VIEW)

    ' (3) URL link
    Set entryUrl = outline.CreateEntry("HCLDocs", entryHeader, "", Nothing)
    entryUrl.Label = "HCL Docs"
    Call entryUrl.SetURL("https://help.hcl-software.com/")

    ' (4) Action entry — runs a formula
    Set entryAction = outline.CreateEntry("RefreshAll", entryHeader, "", Nothing)
    entryAction.Label = "Refresh"
    Call entryAction.SetAction({@Command([RefreshHideFormulas])})

    ' (5) Save is mandatory
    Call outline.Save()

    ' Walk and verify
    Dim entry As NotesOutlineEntry
    Set entry = outline.GetFirst()
    Do Until entry Is Nothing
        Print String(entry.Level * 2, " "); entry.Label _
            & " [type=" & entry.Type & ", class=" & entry.EntryClass & "]"
        Set entry = outline.GetNext(entry)
    Loop
End Sub

Things to notice:

• CreateEntry(label, parent, type, after) — parent of Nothing adds to root level; pass an existing entry to make this its child
• String(entry.Level * 2, " ") for indented display — Level 0 is root, Level 1 is root’s child
• For multilingual cases: assign entry.Label = ... dynamically, then Save
• outline.Save is mandatory — same shape of silent bug as the other *.Save-required classes

Five pitfalls

1. Forgetting outline.Save — silent data loss

Same shape of silent bug as NotesACLEntry. Modify entry.Label, SetURL, etc., forget Call outline.Save, and nothing gets written. Code-review habit: for every outline modification, grep for a .Save after it.

2. SetView doesn’t exist — use SetNamedElement + OUTLINE_CLASS_VIEW

A lot of legacy LS and AI-generated examples write:

Call entry.SetView(db, "ViewName")    ' WRONG — not a documented method

Correct:

Call entry.SetNamedElement(db, "ViewName", OUTLINE_CLASS_VIEW)

NotesOutlineEntry has exactly 4 Set methods: SetAction, SetNamedElement, SetNoteLink, SetURL. Everything else is property-assignment.

3. HideFormula doesn’t apply automatically — need UseHideFormula = True

Set a hide formula but the entry still shows? Check UseHideFormula:

entry.HideFormula = {@IsMember("[Admin]"; @UserRoles) = False}
entry.UseHideFormula = True   ' Must be set

UseHideFormula is the on/off switch for the formula — without it set, the formula doesn’t fire.

4. GetNext is depth-first, not sibling-only

Set entry = outline.GetFirst()
Do Until entry Is Nothing
    ' This loop visits ALL entries (including children) — not just root level
    Set entry = outline.GetNext(entry)
Loop

To walk only one level, use GetNextSibling:

Set entry = outline.GetFirst()  ' First root entry
Do Until entry Is Nothing
    ' Stay at root level
    Set entry = outline.GetNextSibling(entry)
Loop

Mixing the two patterns produces unexpected traversal orders.

5. Outline is a legacy element — for new design, consider XPages / Modern UI

Outline was introduced in Notes 6 as the Notes client’s left navigation menu. XPages and onwards displaced it in client UI for new design, with the ApplicationLayout custom control taking over the role.

Practical cases still using outline:

• Maintaining legacy Notes client apps — dynamically modifying an existing outline
• DXL export for version control / cross-db sync of outline structures
• Multilingual Notes apps — programmatic outline beats designing a multilingual outline by hand in Designer

For new Domino apps built around XPages or the REST API, outline is usually skipped. Confirm this app actually uses outline before writing outline code.

What about Java and SSJS?

Cross-language behavior is identical — Java requires explicit outline.recycle() / entry.recycle() for C++-side memory. LotusScript auto-recycles.

Closing

NotesOutline / NotesOutlineEntry are LotusScript’s programmatic tools for building Domino UI navigation. Three things to remember:

1. outline.Save is mandatory — same silent-bug shape as other Set* operations
2. There is no SetView method — use SetNamedElement + OUTLINE_CLASS_VIEW for view links
3. Outline is a legacy element — for new design, evaluate XPages / Modern UI first

But for maintaining dynamic menus in legacy Notes client apps, multilingual switching, and role-conditional display, outline remains the most direct tool available.
