NotesACLEntry Deep Dive — Programmatic ACL Management in Domino: 7 Access Levels, 20 Properties, Roles

TL;DR

A Domino database’s ACL (Access Control List) is the core security mechanism for “who can touch this database and what can they do.” From LotusScript:

• NotesACL — HCL: “Represents the access control list (ACL) of a database.” The container for the whole list.
• NotesACLEntry — HCL: “Represents a single entry in an access control list. An entry may be for a person, a group, or a server.” Each individual entry.

Key things to internalize:

1. Always call acl.Save — HCL’s direct warning: “If you don’t call Save before closing a database, the changes you made to its ACL will be lost”
2. Seven access-level constants — ACLLEVEL_NOACCESS (0) through ACLLEVEL_MANAGER (6), strictly increasing power
3. NotesACLEntry has 20 properties — beyond access level, seven fine-grained permission flags like CanCreateDocuments, CanDeleteDocuments
4. Don’t mix db.QueryAccess/GrantAccess/RevokeAccess with NotesACL objects — HCL warns this “may produce inconsistent results”

NotesACL vs NotesACLEntry — Container / Entry Relationship

Per the official class definitions, these two classes are related by containment:

• NotesACL — “Contains: NotesACLEntry”
• NotesACLEntry — “Contained by: NotesACL”

In practice: get the ACL object first, then walk / create / modify / remove entries through it.

Obtaining the ACL and entries

Get the NotesACL

HCL: “Every NotesDatabase contains a NotesACL object representing that database access control list. To get it, use the ACL property in NotesDatabase.”

Dim session As New NotesSession
Dim db As NotesDatabase
Dim acl As NotesACL

Set db = session.CurrentDatabase
Set acl = db.ACL

Get a NotesACLEntry

“NotesACL provides three ways to access an existing NotesACLEntry”:

Seven access levels

The level% parameter of CreateACLEntry accepts these seven constants, ordered weakest to strongest:

In practice, 4-5 of them get most use: Reader / Author / Editor for users, Designer / Manager for developers and admins. Depositor for anonymous submission. NoAccess for explicit blocks.

UserType vs IsPerson / IsGroup / IsServer

NotesACLEntry exposes two parallel ways to label an entry’s type:

• UserType property — HCL: “Read-write. Indicates the type of user for a particular entry.” Newer, more expressive.
• IsPerson / IsGroup / IsServer — three separate Booleans, older convenience flags.

The two stay in sync — set IsPerson = True and UserType updates accordingly. But for entries like mixed groups (groups containing both persons and servers), the convenience flags can’t capture the nuance — you need UserType.

Practical guidance:

• New code: prefer UserType
• Reading existing code: If entry.IsPerson Then ... is fine
• Working with advanced group scenarios: must check UserType

20 properties for fine-grained permissions

NotesACLEntry goes beyond access level — there are 20 properties controlling specific permissions:

Note the “access level prerequisite” pattern: CanCreateDocuments only matters for Author-or-higher entries; setting it on a NoAccess entry has no effect.

Roles — custom role mechanism

Beyond access level, the ACL supports custom Roles (names in square brackets like [Manager], [Approver]). Forms, views, agents, and Reader/Author fields can use these role names for finer-grained access control.

• acl.Roles — “All the roles defined in an access control list” — the role catalog for the database
• entry.Roles — “The roles that are enabled for an entry” — which roles this specific entry has
• entry.EnableRole(name) — “Given the name of a role, enables the role for an entry”
• entry.DisableRole(name) — “Given a role, disables the role for an entry”
• entry.IsRoleEnabled(name) — “Given a role, indicates whether the role is enabled for an entry”

Common pattern: define an [Approver] role, use @UserRoles on a form’s Reader field to gate visibility — only users whose entry has the role enabled can see or modify the document.

Complete CRUD examples

1. Iterate every entry

Sub Initialize
    Dim session As New NotesSession
    Dim db As NotesDatabase
    Dim acl As NotesACL
    Dim entry As NotesACLEntry

    Set db = session.CurrentDatabase
    Set acl = db.ACL

    Set entry = acl.GetFirstEntry()
    Do Until entry Is Nothing
        Print entry.Name & " — Level: " & entry.Level _
            & " — Roles: " & Join(entry.Roles, ", ")
        Set entry = acl.GetNextEntry(entry)
    Loop
End Sub

2. Create an entry

Dim entry As NotesACLEntry
Set entry = acl.CreateACLEntry("Bryan Inc./ACME", ACLLEVEL_EDITOR)
entry.IsPerson = False
entry.IsGroup = True              ' Mark as group
entry.CanCreateDocuments = True
entry.CanDeleteDocuments = False  ' Editor can delete by default; explicitly turn off

Call entry.EnableRole("Approver") ' Enable the [Approver] role

Call acl.Save                     ' Required!

3. Modify an entry

Dim entry As NotesACLEntry
Set entry = acl.GetEntry("Bryan Inc./ACME")

If entry Is Nothing Then
    Print "Entry not found"
    Exit Sub
End If

entry.Level = ACLLEVEL_DESIGNER  ' Bump to Designer
Call entry.DisableRole("Approver")

Call acl.Save

4. Remove an entry

Dim entry As NotesACLEntry
Set entry = acl.GetEntry("Bryan Inc./ACME")

If Not entry Is Nothing Then
    Call entry.Remove()    ' Remove called on the entry object, not the ACL
    Call acl.Save
End If

Note Remove lives on NotesACLEntry, not on NotesACL — you get the entry first, then remove.

Five pitfalls

1. Forgetting acl.Save — changes silently lost

HCL’s direct warning: “If you don’t call Save before closing a database, the changes you made to its ACL will be lost.”

Agent modifies the ACL but never calls acl.Save, the agent finishes, all changes are in memory, and the database close discards them. The most common silent bug. Code-review habit: for every ACL modification, grep for a corresponding .Save.

2. GetEntry returns Nothing when not found — not an error

Set entry = acl.GetEntry("Someone Not In ACL")
entry.Level = ACLLEVEL_EDITOR     ' WRONG — Object variable not set

Correct:

If entry Is Nothing Then
    Print "Entry not found"
    Exit Sub
End If

3. Don’t mix db.QueryAccess / GrantAccess / RevokeAccess with NotesACL objects

HCL’s warning: “The Database class has three methods that you can use to access and modify an ACL without getting an ACL object: QueryAccess, GrantAccess, and RevokeAccess. However, using these methods at the same time that an ACL object is in use may produce inconsistent results.”

Practical rule: pick one path per agent — go through NotesACL objects, or use NotesDatabase’s convenience methods, not both.

4. To modify the ACL, the caller needs Manager access

Modifying the ACL itself requires Manager-level access. If the agent’s signer is only an Editor, acl.Save will fail (possibly silently — LotusScript may not throw a loud error, looking like a no-op).

• Server-side execution: the signer needs Manager in that database’s ACL
• Client-side execution: the current user needs Manager

5. Effective access vs entry-level access — overlapping groups

A user can appear in multiple ACL entries simultaneously (e.g., directly as Editor and also a member of [ALL_USERS] group which is Reader). Effective access isn’t the minimum or the average — it’s the maximum: whichever applicable entry grants the highest level wins.

For audit-style “what can this user actually do?” queries, use db.QueryAccess(name) — that returns the effective level, not any specific entry’s level.

How this ties into the 14.5 security mini-series

This piece covers db-level ACL (who can access this NSF and what they can do). The recent 14.5 security articles cut at different layers:

Complete Domino security picture: transport encryption (5/11/12) + outbound trust (5/10) + database-level permissions (this post). Three layers, all required.

What about Java and SSJS?

Cross-language behavior is identical — Java requires explicit acl.recycle() / entry.recycle() to free C++-side memory. LotusScript auto-recycles, so this isn’t an LS concern.

Closing

Domino developers spend most of their time on documents and views — ACLs typically get configured once and forgotten. But for dynamic permission adjustment (auto-grouping by org structure, role flips by workflow stage), NotesACL and NotesACLEntry are unavoidable.

The three pitfalls most likely to bite:

1. Forgetting acl.Save — agent ran, ACL unchanged, no error
2. GetEntry returns Nothing — always Is Nothing first
3. Don’t mix db methods with ACL objects — one path per agent

Plus the precondition “to modify ACL, you need Manager yourself” — and you have the foundation for writing real ACL automation in production.
