NotesJSONNavigator: Native JSON Parsing in LotusScript, Without the String Surgery

If you’ve been doing Domino long enough, you remember parsing JSON in LotusScript the hard way: Evaluate with @Explode, or regex-flavoured string surgery that broke the moment a value contained a comma. Since Domino 10.0.1 there’s a proper answer — NotesJSONNavigator, “a LotusScript class used to parse JSON data.” It hands you a typed tree of objects, arrays, and values that you navigate directly. The API is clean; the only friction is a couple of naming choices that don’t match what you’d guess.

TL;DR

• Set nav = session.CreateJSONNavigator(jsonString$) parses JSON into a navigable tree. The input can be an empty string (to build JSON), a JSON string, or a NotesStream (UTF-8 only). Introduced in Domino 10.0.1.
• Navigate with GetElementByName(name), GetNthElement(index) (1-based), or GetElementByPointer("/path/to/value") (JSON Pointer). Each returns a NotesJSONElement.
• A NotesJSONElement has Name, Type, and Value. When Type is object or array, .Value is a NotesJSONObject or NotesJSONArray you then iterate.
• Naming surprise #1: iteration is GetFirstElement / GetNextElement everywhere — not GetFirstItem/GetItem.
• Naming surprise #2: building JSON, AppendElement(value, name) takes the value first, name second; serialize the tree with Stringify().

Parsing and navigating

Create the navigator from a JSON string, then reach values by name, by JSON Pointer, or by iterating:

Sub Initialize
    Dim session As New NotesSession
    Dim nav As NotesJSONNavigator
    Dim el As NotesJSONElement
    Dim arr As NotesJSONArray
    Dim item As NotesJSONElement

    Dim testJSON As String
    testJSON = |{ "variable1":"value1", "variable2":"value2",| _
             & | "myarray":["An","array","of","strings"],| _
             & | "myobject":{"property1":"yourValue1"} }|

    Set nav = session.CreateJSONNavigator(testJSON)

    ' By name -> "value2"
    Set el = nav.GetElementByName("variable2")
    Print "variable2 = " & el.Value

    ' By JSON Pointer -> "yourValue1"
    Set el = nav.GetElementByPointer("/myobject/property1")
    Print "property1 = " & el.Value

    ' Descend into a nested array: the element's Value IS the NotesJSONArray
    Set el = nav.GetElementByName("myarray")
    Set arr = el.Value
    Set item = arr.GetFirstElement()
    While Not (item Is Nothing)
        Print "array item = " & item.Value
        Set item = arr.GetNextElement()
    Wend
End Sub

Two things this shows. First, GetElementByPointer uses JSON Pointer syntax (/myobject/property1) to jump straight to a nested value — far cleaner than descending node by node. Second, the way you go deeper is element.Value: when an element’s Type is object or array, its Value isn’t a scalar — it’s the NotesJSONObject / NotesJSONArray you then walk.

The element type system

Every NotesJSONElement reports a Type you compare against the JSONELEM_TYPE_* constants:

Note there’s no separate null type — JSON null maps to JSONELEM_TYPE_EMPTY. Branch on Type before reading Value so you know whether you’re getting a scalar or a container:

Select Case el.Type
Case JSONELEM_TYPE_STRING, JSONELEM_TYPE_NUMBER, JSONELEM_TYPE_BOOLEAN
    Print el.Name & " = " & el.Value
Case JSONELEM_TYPE_OBJECT
    Dim obj As NotesJSONObject
    Set obj = el.Value        ' descend
Case JSONELEM_TYPE_ARRAY
    Dim arr As NotesJSONArray
    Set arr = el.Value
End Select

NotesJSONObject and NotesJSONArray each expose Size (the element count) plus the same GetFirstElement / GetNextElement / GetNthElement iterators — consistent across the whole family.

Building JSON — mind the argument order

The navigator produces JSON as well as consuming it. Start with an empty navigator, append, and Stringify:

Dim nav As NotesJSONNavigator
Set nav = session.CreateJSONNavigator("")
Call nav.AppendElement("value1", "variable1")   ' AppendElement(value, name) — value FIRST
Call nav.AppendElement(123, "count")
Print nav.Stringify()                            ' => {"variable1":"value1","count":123}

The gotcha is the argument order: AppendElement(value, name) — value first, name second, which is the reverse of what most people type on the first try. AppendArray(name) and AppendObject(name) return a fresh NotesJSONArray / NotesJSONObject you fill the same way. When you’re done, Stringify() serializes the whole tree back to a JSON string (there’s no ToJSONString/GetJSONString — the method is Stringify).

What about Java and SSJS?

There’s no direct counterpart in the Domino APIs, which is worth stating plainly. lotus.domino has no JSONNavigator class — Java developers reach for a standard library (com.google.gson, org.json, or com.ibm.commons.util.io.json). SSJS/XPages has no JSONNavigator object either; it uses the global fromJson() / toJson() helpers. So relatedJava and relatedSsjs are empty here — NotesJSONNavigator is a LotusScript convenience with no 1:1 mapping, which is a nice reversal of the usual “LS is the poor cousin” framing: for JSON, LotusScript got a purpose-built native parser while the other two lean on general-purpose libraries. (This article is a companion to the JSON element/array/object deep-dive.)
