NotesJSONArray / Element / Object: Parsing and Building JSON in LotusScript

TL;DR

• Continues from the earlier lotusscript-http-json article — going deep on the three building blocks under NotesJSONNavigator.
• Three classes map to the three JSON node types:
  • NotesJSONElement — leaf (name/value pair)
  • NotesJSONObject — object {} node
  • NotesJSONArray — array [] node
• Each one supports both parsing and building — GetFirstElement / GetNextElement / GetNthElement to walk; AppendElement / AppendArray / AppendObject to construct.
• Starting point for building JSON: session.Createjsonnavigator("") gives you an empty navigator; after appending, call .Stringify() to render JSON text.
• The 64K limit story is version-sensitive — both the parse-side 64K cap and the “navigator chokes on CR/LF line endings” problem were fixed in 10.0.1 FP2 (SPR# DCONB8VMAV / ASHEB95LFR). On 14.5 the only live trap is “a single element’s value exceeding 64K still produces garbled results” (a LotusScript String engine limit the JSON classes can’t route around).

How the three classes relate

Mapping JSON structure to classes:

{                              ← whole thing is an Object
  "name": "Bryan",             ← Element: name="name", value="Bryan"
  "tags": ["Domino", "AI"]     ← Element: name="tags", value=Array
}

NotesJSONNavigator is the entry point to the whole tree — once you have the root from it (typically an Object or Array), you walk the tree using these three classes’ methods.

NotesJSONElement — the leaf

The simplest: three properties + one method.

For the exact .Type constant values, see the Designer help page for NotesJSONElement. Production code usually checks .Type before reading .Value:

Dim el As NotesJSONElement
Set el = obj.GetElementByName("age")
If el.Type = JSON_TYPE_NUMBER Then  ' actual constant name: check Designer help
    Print "Age is " & CStr(el.Value)
End If

NotesJSONObject — the {} node

A named key/value collection. Size + 4 navigation + 3 append + Copy:

Note that AppendElement / AppendArray / AppendObject are three separate methods, not overloads — pick the one matching the type you’re appending.

NotesJSONArray — the [] node

Nearly the same shape as Object, but no GetElementByName (arrays don’t have names):

JSON permits mixed-type arrays ([1, "two", {"three": 3}]) — the three separate Append methods exist precisely to support that.

Parsing: walking from the navigator

The earlier lotusscript-http-json piece showed the “HTTP Get + PreferJSONNavigator = True returns a navigator directly” pattern. Once you have the navigator, three common walks:

1. Jump straight to a known field (Object path)

Dim root As NotesJSONObject
Set root = nav.GetElementByName("data").Value  ' assuming "data" is an object
Dim emailEl As NotesJSONElement
Set emailEl = root.GetElementByName("email")
Print emailEl.Value

2. Walk a whole object

Dim el As NotesJSONElement
Set el = obj.GetFirstElement()
Do Until el Is Nothing
    Print el.Name & " = " & CStr(el.Value)
    Set el = obj.GetNextElement()
Loop

3. Walk an array, pulling fields from each item

Dim arr As NotesJSONArray
Set arr = root.GetElementByName("users").Value  ' users: [...]
Dim i As Integer
For i = 1 To arr.Size
    Dim user As NotesJSONObject
    Set user = arr.GetNthElement(i).Value
    Print user.GetElementByName("name").Value
Next i

GetElementByPointer aside: the navigator also exposes GetElementByPointer (RFC 6901 JSON Pointer syntax) for deep-path direct access — nav.GetElementByPointer("/data/users/0/email") is much cleaner than chains of GetElementByName.

Building: reverse-direction JSON construction

What the earlier article didn’t cover: these three classes also work in reverse to build JSON. Starting point:

Dim session As New NotesSession
Dim nav As NotesJSONNavigator

' Empty object to start
Set nav = session.Createjsonnavigator("")
' Or an empty array:
' Set nav = session.Createjsonnavigator("[]")

Then use Append* to build structure:

Dim root As NotesJSONObject
Set root = nav.GetFirstElement().Value  ' grab the root object

' Add a leaf
Dim nameEl As NotesJSONElement
Set nameEl = nav.AppendElement("Bryan")  ' a string
nameEl.Name = "name"
Call root.AppendElement(nameEl)

' Add an array
Dim tagsArr As NotesJSONArray
Set tagsArr = nav.AppendArray()  ' empty array
Call root.AppendArray(tagsArr)
' then call Append* on tagsArr to add items

' Serialize back to a JSON string
Dim jsonStr As String
jsonStr = nav.Stringify()

Detailed API quirks (does AppendElement take the value or a pre-built element object? are indexes 0-based or 1-based?) are best learned from eknori’s 2019 worked example — the most complete build-side demo in the community.

Full round-trip: POST and parse

Build a request JSON from user input, POST to an external API, parse the response:

Sub PostAndParse
    Dim session As New NotesSession
    Dim http As NotesHTTPRequest
    Dim navOut As NotesJSONNavigator
    Dim navIn As NotesJSONNavigator
    Dim root As NotesJSONObject

    ' 1. Build request JSON
    Set navOut = session.Createjsonnavigator("")
    Set root = navOut.GetFirstElement().Value

    Dim el As NotesJSONElement
    Set el = navOut.AppendElement("hello world")
    el.Name = "message"
    Call root.AppendElement(el)

    ' 2. POST it
    Set http = session.CreateHTTPRequest()
    http.PreferJSONNavigator = True
    http.ContentType = "application/json"
    Set navIn = http.Post("https://api.example.com/echo", navOut.Stringify())

    ' 3. Parse response
    Dim respRoot As NotesJSONObject
    Set respRoot = navIn.GetFirstElement().Value
    Dim statusEl As NotesJSONElement
    Set statusEl = respRoot.GetElementByName("status")
    Print "API returned status: " & statusEl.Value
End Sub

Full HTTP examples (with error handling, headers, TLS trust store) are in lotusscript-http-json and notes-httprequest-14-5-trust-store.

The 64K limit story — version-sensitive, three layers

This one has more version evolution than most people realize. Worth laying out:

For 14.5 environments (which is most readers): the old “parse-side 64K cap” was fixed seven years ago, and “doesn’t handle CRLF” was patched in the same release (SPR# ASHEB95LFR). The only live trap left is ↓

⚠️ Single element value > 64K — still alive on 14.5

eknori’s 2019/05/30 follow-up test: after upgrading to 10.0.1 FP2, whole-document > 64K works fine, but a single element with .Value > 64K (e.g., JSON containing a base64-encoded PDF blob) makes NotesJSONElement return “strange results.”

Root cause: LotusScript’s String engine has its own size limits (same family as the NotesItem 32K text / 64K summary constraints) — the JSON classes can’t route around it. If your payload is shaped like “meta + a large base64 attachment”:

• Split the attachment out into its own HTTP call (multipart or binary stream)
• Or chunk it into an array of slices (< 60K each) and reassemble at the application layer

NotesStream usage — pass the stream object, don’t ReadText it

The Designer help page for NotesJSONNavigator lists three overloads: no input / string / NotesStream. The correct NotesStream form:

Dim session As New NotesSession
Dim stream As NotesStream
Dim nav As NotesJSONNavigator

Set stream = session.CreateStream
Call stream.Open("c:\temp\big.json", "UTF-8")  ' UTF-8 enforced here
stream.Position = 0
Set nav = session.Createjsonnavigator(stream)  ' ← pass the stream object directly
Call stream.Close  ' fine to close once the navigator is built

Common mistake — ReadText the stream into a string first:

Set nav = session.Createjsonnavigator(stream.ReadText)  ' ❌ falls right back into the string 64K cap

A commenter on eknori’s article hit exactly this: their original code was stream.Position = 0; Set jsnav = session.CreateJSONNavigator(stream.ReadText); and it kept failing — only after switching to passing the stream object directly did it work.

Note also: stream.Open with "UTF-8" as the second parameter takes care of the “UTF-8 only” concern that used to be a separate caveat (anything coming through the stream is forced to UTF-8). The help page adds: “The NotesStream must be opened when creating the navigator and can be closed as soon as the navigator is created.”

Build / POST side big payloads — also fixed in FP2

navigator.Stringify() returns a String which has no real cap (LS String can hold up to 2GB) — the problem used to surface at the next step. NotesHTTPRequest.Post(url, body) had its own 64K cap before 10.0.1 (SPR# JCORBB2KWU, fixed in the same FP2 wave as the parse side). On 14.5 this isn’t a concern either.

If you’re stuck on an older release and need to POST a large payload, the classic workaround is to drop down to a Java agent or LS2J wrapping Apache HttpClient — pre-V12 NotesHTTPRequest’s HTTP stack was fairly bare-bones.

Relationship to the earlier HTTP/JSON article

What about Java and SSJS?

The SSJS case is flipped: because JS treats JSON as first-class, nobody uses Domino-specific classes there — JSON.parse(http.responseText) is enough. LotusScript needs these three classes precisely because LS has no JSON literal syntax of its own, so you need objects to represent JSON structure.
