LotusScript's Outbound HTTP / JSON Toolchain: NotesHTTPRequest + NotesJSONNavigator

Why these classes matter starting V12

Before V12, calling an external REST API from LotusScript meant one of:

• routing through COM/ActiveX, borrowing IE or WinHTTP objects,
• using Shell to call curl and reading the output file,
• writing a Java agent and using Java’s HTTP stack.

Domino V12 baked in two LS classes — NotesHTTPRequest and NotesJSONNavigator — that keep the whole “fire HTTP → get JSON → walk fields” workflow inside LotusScript itself. No shims, no out-of-process tools.

NotesHTTPRequest: making the call

Construction

Off the NotesSession:

Dim session As New NotesSession
Dim req As NotesHTTPRequest
Set req = session.CreateHTTPRequest()

Methods

Five HTTP verbs plus header / proxy operations:

Properties

NotesJSONNavigator: parsing the response

Construction

Dim nav As NotesJSONNavigator
' Three input shapes are accepted: nothing, a string, a NotesStream
Set nav = session.CreateJSONNavigator()                 ' empty — for building with Append* later
Set nav = session.CreateJSONNavigator(jsonString)       ' parse from a string
Set nav = session.CreateJSONNavigator(notesStream)      ' parse from a stream

Methods for walking the JSON tree

Companion classes

NotesJSONNavigator handles the tree as a whole, but individual nodes are typed:

• NotesJSONElement — a name/value pair
• NotesJSONArray — an array node
• NotesJSONObject — an object node

The Get*Element methods return these, and you read values off them.

Wiring the two together: PreferJSONNavigator

The naive flow is “req.Get(url) returns a string → feed that string to CreateJSONNavigator and parse.” There’s a trap: the string return path has a 64K cap. Any JSON response over 64K silently truncates.

The PreferJSONNavigator property fixes that — set it to True and Get / Post etc. return a NotesJSONNavigator directly, with no string intermediary:

req.PreferJSONNavigator = True
Dim nav As NotesJSONNavigator
Set nav = req.Get("https://api.example.com/items")
' Walk the tree directly
Dim el As NotesJSONElement
Set el = nav.GetElementByPointer("/items/0/title")

NotesJSONNavigator has no internal 64K limit — that’s what the docs mean by “JSONNavigator has no 64k limit unlike HTTPRequest strings.” Whenever the response is JSON, set PreferJSONNavigator = True rather than going through the string path.

End-to-end example: GET an external API and extract one field

Sub Initialize
    Dim session As New NotesSession
    Dim req As NotesHTTPRequest
    Set req = session.CreateHTTPRequest()

    ' Headers (API key, Accept JSON)
    Call req.SetHeaderField("Authorization", "Bearer YOUR-TOKEN")
    Call req.SetHeaderField("Accept", "application/json")

    ' Timeout and redirect cap
    req.Timeoutsec = 30
    req.Maxredirects = 3

    ' The important line — get the response as a navigator, not a string
    req.PreferJSONNavigator = True

    Dim nav As NotesJSONNavigator
    Set nav = req.Get("https://api.example.com/v1/users/me")

    ' Check the status code
    If req.Responsecode <> 200 Then
        Print "API error, code = " & req.Responsecode
        Exit Sub
    End If

    ' Pull a deep field with JSON Pointer
    Dim emailEl As NotesJSONElement
    Set emailEl = nav.GetElementByPointer("/profile/email")
    If Not emailEl Is Nothing Then
        Print "User email: " & emailEl.Value
    End If
End Sub

Four things worth noticing:

1. SetHeaderField must be called before sending — order matters.
2. Responsecode is readable after Get() returns — use it to detect failures.
3. PreferJSONNavigator = True must be set before sending — otherwise you get a string back.
4. GetElementByPointer returns Nothing on miss — always Is Nothing check before using .Value.

What about Java and SSJS?

LotusScript used to need workarounds (calling a Java agent, shell-out, COM) for HTTP and JSON; this pair lifts LS to the level Java and SSJS already had. Java has had java.net.HttpURLConnection since 1.0, gained java.net.http.HttpClient in Java 11, and has long-mature libraries like Apache HttpClient and OkHttp; for JSON there’s Jackson, Gson, org.json — take your pick. SSJS in XPages reaches the same APIs via Java imports. Side-by-side:

For an existing Domino LS codebase, this pair fills in “the thing you used to need a Java agent for.”

Caveats

1. 64K string ceiling — the string return path truncates above 64K. Use PreferJSONNavigator = True always; for non-JSON large responses, route through a NotesStream.
2. TLS / trusted CAs — defaults to the Domino server’s TLS stack; trusting external CAs uses certstore.nsf (a server-level setting, separate from NotesHTTPRequest itself). In Domino 14.5+, the server-side default trust source moves from cacerts.pem to the Domino Directory — import your self-signed CAs into the Directory before upgrading. See Domino 14.5 changes where NotesHTTPRequest loads trusted CAs from.
3. Synchronous — Get / Post block until the response arrives. Set Timeoutsec for slow endpoints.
4. Proxy — corporate networks: use Setproxy / Setproxyuser. Don’t forget Resetproxy when leaving the proxied scope.

Closing

NotesHTTPRequest + NotesJSONNavigator + PreferJSONNavigator = True is the V12-and-later official path for “LotusScript talks to a REST API.” Where you used to need ActiveX or a Java agent, it’s now a fully native LS workflow. For shops integrating an existing Domino app with an external SaaS (Slack / Teams / banking / government APIs), this pair drops the entry barrier through the floor.
