The Content-Carrying DOM Nodes: TextNode, AttributeNode, Comment, CDATASection in LotusScript

The previous article covered getting around a parsed DOM — document, elements, node lists. But the elements are mostly scaffolding; the data is in the leaves: the text inside a tag, the value of an attribute, a comment, a CDATA block. These are the content-carrying nodes, and the LotusScript binding for them has one surprise big enough to break your first attempt.

If you come from JavaScript or Java, you’ll reach for .data, .length, .name, .value — and none of them exist. The Domino LotusScript DOM exposes character content through the inherited NodeValue, and attribute name/value through AttributeName / AttributeValue. Use the W3C names and the code won’t compile.

TL;DR

• Read text/comment/CDATA content through NodeValue (inherited from NotesDOMNode). There is no Data and no Length property in this binding.
• Attribute name/value are AttributeName (read-only) and AttributeValue (read-write) — not Name/Value. Plus IsSpecified (was it explicitly set in the source?).
• Inheritance: NotesDOMCharacterDataNode is the abstract base of TextNode, CommentNode, CDATASectionNode; CDATASection derives from Text; AttributeNode sits directly on NotesDOMNode, not under CharacterData.
• CharacterData editing methods: SubstringData, AppendData, InsertData, DeleteData, ReplaceData.
• NotesDOMTextNode adds SplitText — “Breaks this node into two nodes at the specified offset, keeping both in the tree as siblings.” CDATASection inherits it; Comment does not.
• All new with Release 6, not supported in COM.

The inheritance, and why it matters

NotesDOMNode
├─ NotesDOMCharacterDataNode   (abstract — never instantiated directly)
│   ├─ NotesDOMTextNode
│   │   └─ NotesDOMCDATASectionNode
│   └─ NotesDOMCommentNode
└─ NotesDOMAttributeNode        (separate — NOT character data)

NotesDOMCharacterDataNode — “Represents character data in a DOM node” — is abstract: “you do not create NotesDOMCharacterDataNode objects. Instead, you create objects for a specific derived node class.” Its value is that Text, Comment and CDATASection all inherit the same five editing methods from it. The two-level chain (CDATASection → Text → CharacterData) means a CDATA node also has SplitText, while a Comment does not. And NotesDOMAttributeNode is deliberately off to the side — an attribute is character-ish but it’s not a CharacterDataNode, so it has its own AttributeName / AttributeValue accessors instead of the editing methods.

Reading content — via NodeValue

When you land on a text, comment, or CDATA node while walking the tree, the content is in NodeValue:

Select Case node.NodeType
Case DOMNODETYPE_TEXT_NODE          ' 3
  Print "Text: [" & node.NodeValue & "]"
Case DOMNODETYPE_COMMENT_NODE       ' 8
  Print "Comment: " & node.NodeValue
Case DOMNODETYPE_CDATASECTION_NODE  ' 4
  Print "CDATA: " & node.NodeValue
End Select

The official walk-tree example reads exactly this way — node.NodeValue for all three. There is no .Data; reaching for it is the number-one compile error people hit porting DOM code into LotusScript.

Attributes — AttributeName / AttributeValue

An attribute node comes from an element’s Attributes map. Read it with the typed accessors (the inherited NodeName / NodeValue also work, and the official example uses them):

Dim attrs As NotesDOMNamedNodeMap
Set attrs = element.Attributes
Dim i As Integer
For i = 1 To attrs.NumberOfEntries
  Dim a As NotesDOMAttributeNode
  Set a = attrs.GetItem(i)
  Print a.AttributeName & " = " & a.AttributeValue
  If Not a.IsSpecified Then Print "  (defaulted, not in source)"
Next

IsSpecified “Indicates whether or not this attribute was explicitly given a value in the original document” — handy when a DTD supplies defaults and you want to know which attributes the author actually wrote. Note what’s absent: no Name, no Value, no Specified, no OwnerElement. The binding is a renamed subset of W3C DOM, not a mirror of it.

Editing character data

The five CharacterData methods let you manipulate content in place — useful when transforming a parsed tree before re-serialising:

' textNode currently holds "Hello"
Call textNode.AppendData(" World")              ' -> "Hello World"
Call textNode.InsertData(5, ",")                ' -> "Hello, World"
Print textNode.SubstringData(0, 5)              ' -> "Hello"
Call textNode.DeleteData(5, 1)                  ' remove the comma
Call textNode.ReplaceData(0, 5, "Howdy")        ' -> "Howdy World"

' Text-only: split into two sibling text nodes at offset 5
Dim tail As NotesDOMTextNode
Set tail = textNode.SplitText(5)

SplitText is the one method unique to Text (and inherited by CDATASection) — Comment nodes don’t have it, because splitting a comment in two has no meaningful tree semantics.

This is the second of three pieces on the Domino DOM node classes — the first covered navigation, and the third covers the DTD/declaration tier and SAX error handling.

What about Java and SSJS?

As with the navigation classes, there’s no clean Domino-API counterpart to point at — XML DOM work in Java and XPages goes through the standard org.w3c.dom interfaces (Text, Attr, Comment, CDATASection), not a lotus.domino class. Those W3C interfaces are worth knowing precisely because they’re the names this LotusScript binding renamed: what W3C calls Node.getNodeValue() / CharacterData.getData() / Attr.getValue() collapses here to NodeValue and AttributeValue. So relatedJava and relatedSsjs are empty — the equivalent in those languages is the platform DOM, not a Domino object.
