Walking a Parsed XML DOM in LotusScript: DocumentNode, ElementNode, NodeList, NamedNodeMap

You’ve fed an XML file through NotesDOMParser and called Process. Now you have a tree in memory and need to pull values out of it — the root element, every <item> under it, the id attribute on each. The navigation surface is a small family of node classes, and while it follows the W3C DOM shape, the LotusScript binding has a few sharp edges worth knowing before you write the loop.

This is the first of three pieces on the Domino DOM node classes: navigation here, the content-carrying node types next, and the DTD/declaration tier plus SAX error handling after that.

TL;DR

• After Set domParser = session.CreateDOMParser(inStream, outStream) and domParser.Process, the root is domParser.Document — a NotesDOMDocumentNode. “There is only one document node in a DOM tree.”
• The root element is documentNode.DocumentElement; the document node itself is above it.
• GetElementsByTagName(name) (on the document or any element) returns a NotesDOMNodeList of matching elements.
• GetItem is 1-based — iterate For i = 1 To list.NumberOfEntries. This is the single biggest trap coming from JavaScript/Java DOM.
• An element’s attributes come from its Attributes property as a NotesDOMNamedNodeMap — also 1-based GetItem. To fetch one attribute by name, use the element’s GetAttribute(name) / GetAttributeNode(name) — there is no GetItemByName.
• There is no ChildNodes NodeList property — walk children with FirstChild + NextSibling (+ NumberOfChildNodes).
• All these classes are new with Release 6, not supported in COM.

The shape of the tree

Every node — document, element, text, attribute — derives from NotesDOMNode, which carries the navigation properties: NodeName, NodeType, NodeValue, ParentNode, FirstChild, LastChild, NextSibling, PreviousSibling, Attributes, NumberOfChildNodes, and the all-important IsNull guard. You discriminate node kinds by comparing NodeType to the DOMNODETYPE_* constants:

(The full list runs 0–13; the others come up in the later articles.)

The NotesDOMDocumentNode sits at the top — “the root of the document tree” — and adds one key property over the base node: DocumentElement, which jumps you straight to the root element. The NotesDOMElementNode adds TagName and the attribute accessors GetAttribute / GetAttributeNode.

Querying and reading attributes

GetElementsByTagName “Returns a NotesDOMNodeList of all descendant elements with a given tag name, in the order in which they are encountered.” The list exposes NumberOfEntries and a 1-based GetItem:

Dim session As New NotesSession
Dim inStream As NotesStream, outStream As NotesStream
Set inStream = session.CreateStream
Call inStream.WriteText(|<order id="A1"><line sku="X9">Widget</line><line sku="Z2">Gadget</line></order>|)
inStream.Position = 0
Set outStream = session.CreateStream

Dim domParser As NotesDOMParser
Set domParser = session.CreateDOMParser(inStream, outStream)
domParser.Process

Dim docNode As NotesDOMDocumentNode
Set docNode = domParser.Document

Dim root As NotesDOMElementNode
Set root = docNode.DocumentElement
Print "Root element: " & root.TagName & ", id=" & root.GetAttribute("id")

Dim lines As NotesDOMNodeList
Set lines = root.GetElementsByTagName("line")
Dim i As Integer
For i = 1 To lines.NumberOfEntries          ' 1-based!
  Dim el As NotesDOMElementNode
  Set el = lines.GetItem(i)
  Print "line sku=" & el.GetAttribute("sku")
Next

(Adapted — the parser requires a NotesStream, so the XML is written into one rather than passed as a string.)

To enumerate all attributes of an element rather than fetch one by name, go through its Attributes property — a NotesDOMNamedNodeMap, “used by methods of the NotesDOMNode class for returning the list of an element node’s attributes.” Same 1-based GetItem:

Dim attrs As NotesDOMNamedNodeMap
Set attrs = root.Attributes
For i = 1 To attrs.NumberOfEntries
  Print attrs.GetItem(i).NodeName & " = " & attrs.GetItem(i).NodeValue
Next

There’s no GetItemByName on the map — when you know the attribute name, the element’s GetAttribute(name) is the direct route.

The full recursive walk

When you don’t know the structure ahead of time, recurse with FirstChild / NextSibling, branching on NodeType. This is the official pattern:

Sub walkTree(node As NotesDOMNode)
  If node.IsNull Then Exit Sub
  Select Case node.NodeType
  Case DOMNODETYPE_DOCUMENT_NODE
    Dim child As NotesDOMNode
    Set child = node.FirstChild
    Dim n As Integer
    n = node.NumberOfChildNodes
    While n > 0
      Call walkTree(child)
      Set child = child.NextSibling
      n = n - 1
    Wend
  Case DOMNODETYPE_ELEMENT_NODE
    Print "Element: " & node.NodeName
    Dim kid As NotesDOMNode
    Set kid = node.FirstChild
    Dim m As Integer
    m = node.NumberOfChildNodes
    While m > 0
      Call walkTree(kid)
      Set kid = kid.NextSibling
      m = m - 1
    Wend
  Case DOMNODETYPE_TEXT_NODE
    Print "Text: " & node.NodeValue
  End Select
End Sub

The shape — IsNull guard, Select Case node.NodeType, walk children by count via FirstChild/NextSibling — is exactly what the official NotesDOMParser walk-tree example uses. Note there’s no node.ChildNodes to iterate; NumberOfChildNodes + sibling-stepping is how you traverse.

What about Java and SSJS?

This is the unusual case where there’s no clean Domino-API counterpart. The NotesDOM* node family is a LotusScript (and Java-agent) facility in the Domino API; the standard route for XML DOM work in Java and XPages is the platform’s own org.w3c.dom / JAXP stack, not a lotus.domino class. So relatedJava and relatedSsjs are intentionally empty here — if you’re doing this in Java, you’d reach for javax.xml.parsers.DocumentBuilder and the W3C interfaces rather than a Domino class, which (unlike the Domino binding) are 0-based and use getData() / getChildNodes() in the canonical W3C shape.
