NotesDOMParser Deep Dive — Loading XML into a DOM Tree, 14 Node Classes, Walking / Modifying / Serializing

TL;DR

NotesDOMParser — HCL: “Processes input XML into a standard DOM (Document Object Model) tree structure.” The whole XML becomes a tree in memory, with 14 Node subclasses representing the various XML constructs.

Four key points:

1. Whole file in memory — the opposite of SAX. The right choice for small-to-medium XML when you need random access or modification
2. Document property is the entry point — gives you the root NotesDOMDocumentNode; walk via FirstChild / NextSibling / ParentNode
3. 14 Node subclasses all inheriting from NotesDOMNode — Element / Text / Attribute / Comment / CDATA / ProcessingInstruction / and 8 others
4. Serialize writes the tree back out as XML — after you modify the tree, serialize emits it to the output stream

Compared to the NotesSAXParser piece: SAX is forward-only streaming; DOM is random-access tree.

What the DOM tree looks like

Take this XML:

<library>
    <book id="b1">
        <title>The Hobbit</title>
        <author>Tolkien</author>
    </book>
    <book id="b2">
        <title>Dune</title>
    </book>
</library>

The DOM tree looks like this:

Document (root, NotesDOMDocumentNode)
└─ library (Element)
   ├─ book (Element, attribute id="b1")
   │  ├─ title (Element)
   │  │  └─ "The Hobbit" (TextNode)
   │  └─ author (Element)
   │     └─ "Tolkien" (TextNode)
   └─ book (Element, attribute id="b2")
      └─ title (Element)
         └─ "Dune" (TextNode)

Every XML construct — element, text, attribute, comment — is a Node object, all subclasses of NotesDOMNode. Once loaded, you can walk anywhere, modify anything, serialize back out.

Starting from NotesSession.CreateDOMParser

NotesDOMParser is created via session.CreateDOMParser:

Dim session As New NotesSession
Dim domParser As NotesDOMParser
Dim xml_in As NotesStream
Dim xml_out As NotesStream

Set xml_in = session.CreateStream
Call xml_in.Open("c:\data\library.xml")

Set xml_out = session.CreateStream
Call xml_out.Open("c:\data\library_modified.xml")
Call xml_out.Truncate

Set domParser = session.CreateDOMParser(xml_in, xml_out)
Call domParser.Process()   ' Start parsing — loads whole file into a tree

Process() triggers parsing (inherited from the NotesXMLProcessor base class). Parse() is also available.

NotesDOMParser properties and methods

The 14 Node classes

Per the official docs, a DOM tree is built from these 14 Node classes, all inheriting from NotesDOMNode:

In practice 90% of code touches only the first five (Document / Element / Attribute / Text / Comment); the other nine are for DTD / CDATA / processing instructions and similar XML advanced features that are rarer in real use.

NotesDOMNode tree-walking API

The walking API shared by every Node (inherited from NotesDOMNode):

NodeType is how you tell which kind of node you have. Common constants:

A complete example — parse → walk → modify → serialize

Read library.xml, uppercase every book title, add a modified="true" attribute to each <book>, and write the result to a new file (adapted from HCL’s official example):

Sub Initialize
    Dim session As New NotesSession
    Dim domParser As NotesDOMParser
    Dim xml_in As NotesStream, xml_out As NotesStream

    Set xml_in = session.CreateStream
    If Not xml_in.Open("c:\data\library.xml") Then
        Print "Cannot open input" : Exit Sub
    End If

    Set xml_out = session.CreateStream
    Call xml_out.Open("c:\data\library_modified.xml")
    Call xml_out.Truncate

    Set domParser = session.CreateDOMParser(xml_in, xml_out)
    domParser.ExitOnFirstFatalError = True
    Call domParser.Process()

    ' Get the root
    Dim docNode As NotesDOMDocumentNode
    Set docNode = domParser.Document

    ' Walk and modify
    Call WalkAndModify(docNode)

    ' Serialize back to XML
    Call domParser.Serialize()
    Call xml_out.Close()

    Print "Done — output at c:\data\library_modified.xml"
End Sub

Sub WalkAndModify(node As NotesDOMNode)
    If node Is Nothing Then Exit Sub

    ' Element handling
    If node.NodeType = DOMNODETYPE_ELEMENT_NODE Then
        Dim elem As NotesDOMElementNode
        Set elem = node    ' downcast

        If elem.TagName = "title" Then
            ' Uppercase the title's text content
            If elem.HasChildNodes Then
                Dim textNode As NotesDOMNode
                Set textNode = elem.FirstChild
                If textNode.NodeType = DOMNODETYPE_TEXT_NODE Then
                    textNode.NodeValue = UCase(textNode.NodeValue)
                End If
            End If
        ElseIf elem.TagName = "book" Then
            ' Add an attribute
            Call elem.SetAttribute("modified", "true")
        End If
    End If

    ' Recurse children
    Dim child As NotesDOMNode
    Set child = node.FirstChild
    Do Until child Is Nothing
        Call WalkAndModify(child)
        Set child = child.NextSibling
    Loop
End Sub

Things to notice:

• node.NodeType = DOMNODETYPE_ELEMENT_NODE — the standard way to test “is this an Element”
• Set elem = node — NotesDOMElementNode is a subclass of NotesDOMNode, so direct assignment works (implicit downcast)
• elem.SetAttribute("name", "value") — Element-specific method
• textNode.NodeValue — TextNode content lives in NodeValue (not NodeName)

Five pitfalls

1. Text is a separate TextNode — not a property of the Element

Intuition says <title>Hobbit</title>’s element has a “text content” property — wrong. The XML spec models text as a child node of the element, with type NotesDOMTextNode:

' WRONG
Print elem.Text     ' No such property

' Correct — retrieve the child TextNode
Dim t As NotesDOMNode
Set t = elem.FirstChild
If t.NodeType = DOMNODETYPE_TEXT_NODE Then
    Print t.NodeValue
End If

If the element has indentation whitespace, that’s a TextNode too — FirstChild may return a whitespace node instead of the real content. You need to skip whitespace nodes when walking.

2. Whitespace TextNodes need explicit skipping

Pretty-printed XML produces whitespace text nodes. While walking, you’ll see plenty of “\n “-style nodes:

Set child = elem.FirstChild
Do Until child Is Nothing
    If child.NodeType = DOMNODETYPE_TEXT_NODE And Trim(child.NodeValue) = "" Then
        ' skip whitespace
    Else
        ' real handling
    End If
    Set child = child.NextSibling
Loop

Or configure the parser ahead of time. The simplest is to filter while walking.

3. No GetElementsByTagName etc. — recurse yourself

Unlike browser-side JavaScript DOM, LotusScript’s NotesDOMNode doesn’t expose GetElementsByTagName / GetElementById as convenience methods. Finding specific elements means recursing the tree manually:

Function FindByTagName(node As NotesDOMNode, tagName As String) As NotesDOMElementNode
    If node.NodeType = DOMNODETYPE_ELEMENT_NODE Then
        Dim e As NotesDOMElementNode
        Set e = node
        If e.TagName = tagName Then
            Set FindByTagName = e
            Exit Function
        End If
    End If
    Dim child As NotesDOMNode
    Set child = node.FirstChild
    Do Until child Is Nothing
        Dim found As NotesDOMElementNode
        Set found = FindByTagName(child, tagName)
        If Not found Is Nothing Then
            Set FindByTagName = found
            Exit Function
        End If
        Set child = child.NextSibling
    Loop
End Function

After writing this a few times, most developers wrap it as a script library utility.

4. After modifying the tree, you MUST call Serialize() — or changes don’t get written

Serialize() is what flushes the in-memory DOM back into XML output. Forgetting Call domParser.Serialize() produces an empty / unmodified output file. Same shape of silent bug as forgetting NotesDocument.Save.

5. Large files consume memory — be careful past tens of MB

DOM loads the whole thing — a 1 MB XML file consumes roughly 5-20 MB of memory (depending on structure). A 100 MB XML file can OutOfMemory the agent. Big file + read-only? Use SAX instead.

NotesDOMNamedNodeMap + NotesDOMNodeList — two helpers

You’ll run into these helpers when traversing attributes or NodeLists:

• NotesDOMNamedNodeMap — “Used by methods of the NotesDOMNode class for returning the list of an element node’s attributes.” elem.Attributes returns this. Use GetNamedItem("id") for name-based lookup or Item(i) for index-based
• NotesDOMNodeList — “Used by methods of the NotesDOMNode class for returning the list of an element node’s child elements.” elem.ChildNodes returns this (though FirstChild + NextSibling is more common in practice)

What about Java and SSJS?

LotusScript’s NotesDOMParser is essentially “a subset of W3C DOM Level 2” — it’s missing some convenience methods. On the Java/SSJS side, prefer javax.xml.parsers when you have the choice.

Closing

DOM is the standard tool in LotusScript for small-to-medium XML with random-access or modification needs. Three things to remember:

1. Text is a separate TextNode — not an element property; retrieve via FirstChild
2. No GetElementsByTagName — recurse yourself (then wrap as utility)
3. Always Serialize() after modification — same shape of bug as forgetting NotesDocument.Save

The DOM vs SAX comparison piece consolidates the decision tree: when SAX, when DOM, when NotesXMLProcessor (XSLT) — three XML routes, side by side.
