What That `?` Icon Means in Domino 14.5 — Mandated NRPC Port Encryption Concepts and Modes

May 11, 2026 1,104 words

The `?` icon you see after upgrading to 14.5

The first time admins open the [Server] - [Server] view in the Domino Directory (names.nsf) after a 14.5 upgrade, they notice a new rightmost column where every server document carries a ? (unknown.png) icon.

The Japanese-language HCL KB0127764 gives the answer directly: that ? is not a bug or an error. It’s the compliance status indicator for the new 14.5 feature Mandated NRPC Port Encryption, where ? means “feature disabled, no evaluation has run, status unknown.”

Layer 1 vs Layer 2: two things that are easy to confuse

The 14.5 docs use “port encryption,” “mandated port encryption,” and “Encrypt network data” in places that overlap — but they refer to two distinct layers:

Layer	What it is	14.5 default
Layer 1: per-port encryption capability	Server document → Ports → Notes Network Ports → “Encrypt network data” checkbox per port	On (fresh install — per HCL: “NRPC port encryption is enabled for increased security level”)
Layer 2: mandate enforcement	Directory Profile’s Mandated Port Encryption settings (the subject of this article)	Off (the `?` icon’s origin)

What Layer 1 does

NRPC (Notes Remote Procedure Call) is the protocol Domino servers use to talk to each other and that Notes clients use to talk to servers. The Layer 1 “Encrypt network data” checkbox has been around for many releases. HCL’s documentation frames its threat model as “prevent the network eavesdropping that’s possible with a network protocol analyzer” — stop somebody running wireshark or tcpdump on your network from reading NRPC traffic.

There’s a critical nuance, though. The same doc states “Network data encryption occurs if you enable network data encryption on either side of a network connection” — either side enabling encryption is enough, typically “server enables, client follows along.” Sounds great, but the inverse: if the other side won’t accept encryption — older version, deliberate refusal, configuration drift — that link may run in plaintext. Layer 1 doesn’t give the admin a way to insist “every link in the domain must be encrypted.”

What Layer 2 fills in

Layer 2 is precisely that “insist” lever. The official Mandated Port Encryption page puts it directly: “Enables and enforces NRPC port encryption on both the client and server. If configured by an administrator, encryption needs to be enforced even if the other side does not want to use encryption” — enforce even when the other side declines.

So:

Layer 1 = “I can do encryption”
Layer 2 = “I insist on encryption — won’t accept anything else”

Two concepts, two configuration surfaces. The “default enabled” you see is Layer 1; the ? icon corresponds to Layer 2 (default disabled).

What 14.5 actually adds: mandate + monitor

Per the 14.5 security features release note, the feature delivers two things:

Aspect	What it does
Mandate (enforce)	Once enabled in the Directory Profile, the local 14.5 server or client requires encryption on every authenticated NRPC session — the connection drops if the other side won’t accept
Monitor (log only)	Without enforcing, you enable logging first to observe which connections are currently in plaintext and would break under enforcement — admins get an evaluation window

So admins can adopt this through “watch first, then enforce” rather than “enable and pray nothing breaks.”

`?` is one of several status icons

The official Mandated Port Encryption page describes this column as a compliance indicator that switches icons based on configuration. In practice admins will see:

Status	Icon	Meaning
Not enabled	`?` (unknown)	Feature still disabled — server hasn’t evaluated. The “normal” state
Logging enabled (monitor)	Lock / transition icon	Enabled, status under evaluation
Mandate enforced	Active state icon	Encryption is being enforced

So a ? doesn’t need to be “fixed.” If you have no plan to enable this feature, the icon staying ? is perfectly fine — it doesn’t affect server operation.

Three enablement modes (also the recommended migration path)

Mode	Directory Profile setting	Server-view icon	Use case
Disabled (default)	logging level = off, mandate = off	`?`	Default state right after a 14.5 upgrade
Monitor window	logging = on, mandate = off	Transition icon	Capture connection records, see which connections would be affected
Enforced	logging + mandate both on	Active icon	NRPC encryption is mandated — clients that refuse encryption can’t connect

The official recommendation: enable logging first, watch for several days to confirm no breakage, then enforce. Skipping straight to enforcement is the textbook way to lock out a legacy node nobody remembered to upgrade.

Risk assessment if Layer 2 is left off

Layer 1 alone isn’t enough (per the earlier section). Whether to also enable Layer 2 depends on the environment:

Environment	Risk of leaving Mandated off
Single-DC, pure intranet office	Low — the internal network is trusted. The “lateral-movement-then-sniff-NRPC” risk persists, though
Cross-DC / VPN over Internet	Medium-high — any segment outside your control means plaintext NRPC is readable end-to-end
Regulated industries (finance, healthcare, government)	High — compliance audits expect provable “all traffic encrypted” guarantees, which Layer 1’s “either side” model can’t demonstrate cleanly
Multi-partner B2B server-to-server	High — the other side’s environment is outside your control; downgrade risk isn’t manageable

The HCL Layer 1 documentation frames the threat model as “network eavesdropping … with a network protocol analyzer” — assuming an attacker is already running packet capture on your network. Pure intranet office treats that risk as low; cross-network or public-Internet links treat it as high. “Lateral movement” and “compliance auditability” are industry considerations not enumerated by HCL but practically influence whether to enable Mandated.

Practical guidance:

Pure internal, no regulatory requirements: Layer 1’s default is sufficient; Mandated is nice-to-have
Any cross-segment traffic, compliance-bound, or B2B partner links: schedule Mandated, at minimum starting in logging mode to gather evidence

Relationship to the 5/10 trust-store article

The 5/10 piece on the NotesHTTPRequest 14.5 trust-store change and this one are both 14.5 security hardening, but they cover two completely separate channels:

Topic	Scope	What’s encrypted / trusted
5/10 trust-store change	LotusScript NotesHTTPRequest making outbound HTTPS calls	TLS cert chain for the outbound connection
5/11 / 5/12 Mandated Port Encryption	NRPC (client–server / server–server internal traffic)	Symmetric encryption on the NRPC port

Both should be configured. Neither replaces the other.

Tomorrow: hands-on enablement

This piece focuses on three conceptual questions: what the ? icon means, why 14.5 introduced this feature, and what status modes you’ll see. The follow-up Mandated Port Encryption hands-on guide breaks down the official 10-step procedure:

The CheckPortEncryption scheduled agent (specifically its special handling for pre-14.5 servers)
Critical Directory Profile fields
Server ini settings (DEBUG_MANDATED_ENCRYPTION, MANDATEDENC_ACTIVE_REFRESH_TIME, etc.)
Desktop policy entries (DISABLE_MANDATED_ENCRYPTION etc.)
The portenc refresh / portenc show console commands
Recovery paths if enforcement breaks something

Closing

If you only remember three things from today:

The ? icon you see in the 14.5 server view isn’t a bug — it’s Mandated Port Encryption sitting in its default disabled, not-yet-evaluated state
The feature plugs the pre-14.5 “negotiated” gap — admins finally have an “I insist on encryption” option
Adopt via “log first, then enforce” — going straight to enforcement is how you accidentally lock out a legacy node

Not planning to enable this feature? Leave it. Planning to enable? See tomorrow’s hands-on piece.
