The LotusScript Web Agent I/O Model: Print Is Your Response, DocumentContext Is Your Request

Come to a LotusScript web agent from any modern web framework and the first thing you’ll look for is the request object and the response object. There isn’t one of either. A Domino web agent — the kind you invoke with ?OpenAgent to build a small JSON endpoint or serve a dynamic fragment — has two much older seams instead: Print, whose accumulated output is the HTTP response body, and DocumentContext, a special in-memory document whose fields are the CGI variables of the request. Learn those two and the whole model falls into place; miss how they work and you get an agent that returns HTML when you wanted JSON, or reads an empty query string and can’t tell why.

This is a field report on the web agent’s I/O model — the output side, the input side, and the two traps on each. It pairs with the error-handling piece; together they’re most of what a hand-written Domino web endpoint needs.

TL;DR

• Output is Print. The reference is blunt: “Domino accumulates print statements and creates a page with their contents after the agent runs.” Whatever you Print is the response body.
• Set the content type with the first Print. To return JSON instead of the default HTML, the first line you print is the header — Content-Type: application/json — followed by a blank line, then the body. That blank line is the HTTP header/body separator; skip it and the header bleeds into your JSON.
• Input is Session.DocumentContext — a NotesDocument carrying the request’s CGI variables. GET arguments are in its Query_String item; a POST body is in Request_Content.
• The CGI-fields gotcha: for a form-triggered agent (WebQueryOpen/Save), CGI values only appear if the form has a field named for each one. A standalone ?OpenAgent agent gets them on DocumentContext directly.

The output side: Print is the body

There is no response.write. There is Print, and Domino’s contract for it is exactly one sentence: “Domino accumulates print statements and creates a page with their contents after the agent runs.” Every Print appends to one buffer, and that buffer is flushed to the browser as the response when the agent finishes.

By default that response is served as text/html. To serve anything else — JSON for an API, CSV for a download, plain text — you set the header yourself, and the mechanism is a small HTTP convention rather than a property: the first thing you print is the header line, then a blank line, then the body.

Sub Initialize
    Dim session As New NotesSession
    Print "Content-Type: application/json"    ' the header — must be first
    Print ""                                   ' blank line: end of headers
    Print "{""status"":""ok"",""count"":42}"   ' the body
End Sub

Two failure modes live here. If the Content-Type line isn’t the very first output — even a stray Print or a leading space ahead of it — Domino has already begun an HTML response and your header becomes visible text at the top of the page. And if you forget the blank line, the header and the first line of the body run together and the browser can’t parse the response. First line, blank line, body: that order is the whole protocol.

The input side: DocumentContext is the request

The request arrives as DocumentContext on the NotesSession. For a ?OpenAgent call there’s no real document being edited, so Domino hands you a synthetic one whose items are the CGI variables — the same Query_String, Request_Content, Remote_Addr, Remote_User you’d read from any CGI environment, as document fields.

For a GET, the arguments are in Query_String; you read and parse it yourself:

Dim ctx As NotesDocument
Set ctx = session.DocumentContext
Dim qs As String
qs = ctx.Query_String(0)              ' e.g. "OpenAgent&id=1024&fmt=json"

For a POST, the body is in Request_Content:

Dim body As String
body = ctx.Request_Content(0)         ' the raw POST payload — parse as form or JSON

There’s no automatic query parsing and no automatic JSON binding; you get the raw strings and split them yourself (or feed the JSON body to NotesJSONNavigator). That’s the price of the model’s age, and it’s also why it’s predictable — nothing is decoded behind your back.

The gotcha: CGI values aren’t always there

The web agents page warns about the input side in a way that catches people: “CGI values are available but not automatically. The form backing up the current document must contain a field named after each desired CGI variable.” That applies to agents triggered from a form — WebQueryOpen or WebQuerySave — where DocumentContext is the form’s own document. In that case reading ctx.Query_String(0) returns empty unless the form design actually has a Query_String field to receive it. Add the CGI fields to the form, or the values silently aren’t there.

A standalone ?OpenAgent agent doesn’t have this problem — its DocumentContext is the synthetic CGI document and the variables are present directly. So the same ctx.Query_String(0) line works out of the box in an ?OpenAgent endpoint and returns empty in a form agent whose form lacks the field. Knowing which kind of agent you’re in tells you whether to expect the CGI values for free.

Putting the two halves together

A hand-written JSON endpoint is just the two sides plus a guard: read the request off DocumentContext, do the work, print the Content-Type and the JSON body — and wrap it in the top-level handler from the error-handling piece so a failure prints a clean JSON error instead of a truncated response. Read, work, print, guard. That’s the whole shape of a Domino web agent, and once the two seams are clear it’s a surprisingly direct way to stand up a small endpoint without XPages or the REST API in the picture.

What about Java and SSJS?

The model has cousins, not twins. A Java agent doesn’t use Print — it calls AgentBase.getAgentOutput() to get a PrintWriter and writes the response through that, but the “first line is the Content-Type header, then a blank line” convention is identical, because it’s an HTTP convention, not a language one. Java reads the request the same way, off getDocumentContext(). SSJS in XPages is a different world entirely: there’s a real request/response through facesContext.getExternalContext(), with proper parameter maps and no CGI-field ceremony — which is exactly the upgrade you feel when you move a JSON endpoint from a web agent to XPages. The LotusScript agent is the most bare-metal of the three, and for a one-file endpoint that’s a feature.
