Implementation Notes: DRAPI Login via Keycloak OIDC — Works on Domino 12.0.2, No Need to Wait for 14

You want to plug DRAPI (Domino REST API) into a modern IdP — Keycloak, Azure AD, Okta — to bypass the legacy LTPA cookie and domcfg.nsf form-login. The instinct is to assume this requires Domino 14, since most of the public OIDC documentation centres on 14-era features.

It turns out DRAPI’s oidc mode works on Domino 12.0.2 — no server upgrade required. The setup has plenty of steps, but every one has official support; it’s not a hack.

This article is the notebook from reproducing the full setup on a local box. It focuses on three things: how to pick among DRAPI’s three OIDC modes, why DRAPI’s three-layer auth architecture changes how you debug, and the four traps that consume the most time. The complete step-by-step is in the GitHub repo and its companion Pages site; this article doesn’t repeat the setup — it focuses on decisions and pitfalls.

TL;DR

• DRAPI has three OIDC modes: jwt (public keys only), oidc (standard OIDC providers, needs clientId + clientSecret), oidc-idpcat (requires Domino 14+, shares idpcat.nsf config with Domino server).
• This demo uses oidc mode — clientId / clientSecret go straight into keepconfig.d, independent of Domino server version.
• Domino 12.0.2 is enough — 12.0.2 already shipped OIDC web login configuration; no need to wait for 14.
• Three independent auth layers: identity (OIDC verifies who you are) → mapping (token claims map to a Person doc) → authorization (scope determines what you can do). Any layer can fail with the same “login failed” surface — debug needs to traverse them in order.
• Four pitfalls: missing adminui block / providerUrl set to localhost failing across machines because Java resolves IPv4 by default (the worst) / browser localStorage caching stale OIDC config / default client scopes not back-applying to existing clients.
• Complete setup — WSL Ubuntu + Keycloak install, realm / client / scope config, DRAPI keepconfig.d wiring, PEM cert trust, curl reachability checks — all on the repo + Pages site.

Why this demo is worth running once

A few motivations:

1. Replacing domcfg.nsf form login: The traditional domcfg.nsf login form is hard-wired to Domino accounts and painful to integrate with modern IdPs. OIDC is the industry standard; Keycloak is a mature open-source option; combining them lets you wire single sign-on across systems.
2. DRAPI is the entry point for modern stacks: For React, Vue, plain SPAs, and mobile apps, DRAPI is the primary path to Domino data. If that authentication layer speaks OIDC, the entire frontend toolchain can use industry-standard IdP libraries.
3. Running it locally eliminates version anxiety: A lot of teams stall on “our server is 12.x, we have to wait for 14 before we can use OIDC.” Actually trying it shows oidc mode works on 12.0.2 — this is a documentation-coverage misperception, not a technical limit.

DRAPI’s three OIDC modes

The official DRAPI authentication doc splits OIDC configuration into three modes, picked based on environment and requirements:

Why this demo picked oidc

• Works on Domino 12.0.2 — oidc-idpcat requires 14+; demo environments still on 12.x can’t use it
• Decoupled from Domino server auth — DRAPI carries its own clientId / clientSecret, doesn’t depend on the Domino server’s IdP setup. Useful when DRAPI and the Domino server need to point at different IdPs
• Single JSON file — config is centralized in keepconfig.d; no cross-file chase into idpcat.nsf

The oidc-idpcat advantage (per the official doc) is shared cache and shared diagnostics — when Domino server and DRAPI both authenticate against the same provider, the token cache and diagnostics are unified. When the server eventually moves to 14+, migrating this demo from oidc to oidc-idpcat is the natural next step.

Three independent auth layers

When OIDC against DRAPI fails, the most common reaction is to treat “login failed” as “OIDC config is wrong” and start digging through Keycloak. In practice, DRAPI’s OIDC handling has three independent checkpoints, and any of them can fail with the same “login failed” message:

Debug by traversing the layers in order:

Login failed
  ├─ Keycloak realm log shows an error?      → Layer 1, OIDC itself
  ├─ DRAPI log shows "user not found in directory"?  → Layer 2, mapping
  └─ DRAPI log shows "missing scope"?         → Layer 3, authorization

Treating these as independent checkpoints dramatically speeds up debugging — you stop wasting time on Keycloak realm settings when the actual problem is a layer-2 mapping issue.

Key config — keepconfig.d JSON shape

DRAPI’s OIDC configuration lives in JSON files under the keepconfig.d/ directory (official doc shows the format). The minimal oidc mode structure:

{
  "oidc": {
    "keycloak": {
      "active": true,
      "providerUrl": "https://192.168.x.x:8443/realms/domino",
      "clientId": "Domino",
      "clientSecret": "your-keycloak-client-secret",
      "userIdentifier": "email",
      "scope": "$DATA",
      "adminui": {
        "active": true,
        "displayName": "Keycloak SSO"
      }
    }
  }
}

Fields that matter most:

• providerUrl — the base URL of the Keycloak realm. Must not be localhost (see Pitfall 2 below)
• clientId / clientSecret — the client configured in the Keycloak realm. The docs recommend using Domino as the clientId
• userIdentifier — which token claim DRAPI uses to map to a Domino user. Setting email means using the token’s email claim against the Person doc’s Internet address. For LDAP DN mapping, also set userIdentifierInLdapFormat: true
• scope — the scope DRAPI accepts. $DATA for document read/write, $SETUP for administration, keepconfigadmin for keepconfig management
• adminui block — this block must not be omitted, otherwise the provider won’t appear in the DRAPI Admin UI login dropdown and the URL ends up at /admin/undefined (Pitfall 1)

A fuller example including additionalClientIds, userIdentifierInLdapFormat, multi-scope, etc., is in the keepconfig.d template inside the repo.

Four traps that consume the most time

Pitfall 1: Missing adminui block routes to /admin/undefined

You set up the oidc block, providerUrl and clientId both look right, but the DRAPI Admin UI’s login dropdown shows no Keycloak option — picking any other option lands on /admin/undefined.

Root cause: adminui is the metadata block DRAPI uses to tell the management UI “expose this provider in the dropdown.” Without it, the provider is registered on the backend but the UI has no idea how to surface it to users.

Fix: every OIDC provider config needs an adminui: { active: true, displayName: "..." }, where displayName is the human-readable label shown in the dropdown.

Pitfall 2: providerUrl set to localhost fails across machines (the worst one)

Common setup: Keycloak runs in WSL Ubuntu, DRAPI runs on Windows. The intuition is to set providerUrl to https://localhost:8443/realms/.... Keycloak can hit itself fine; DRAPI gets connection refused.

Root cause: DRAPI is Java; Java’s default localhost resolution is IPv4, which means 127.0.0.1. DRAPI running on Windows hits Windows-local 127.0.0.1, not the Keycloak inside WSL. WSL and Windows don’t share localhost.

Fix: change providerUrl to WSL’s actual IP (e.g. https://192.168.x.x:8443/...). For WSL2 the IP visible from Windows is available via wsl hostname -I.

Why this trap eats so much time: the failure is at the connection layer, not the OIDC config layer. It’s easy to misdirect into Keycloak realm settings, cert trust, scope mapping — and waste half a day before returning to basic IP resolution.

Verification: from the DRAPI host (Windows), run:

curl https://<wsl-ip>:8443/realms/<your-realm>/.well-known/openid-configuration

JSON coming back means reachability is OK. If this fails, no amount of OIDC config tuning will help.

Pitfall 3: Browser localStorage caches stale config

After changing OIDC config (e.g. providerUrl or clientId), the browser still uses the old redirect URL or client_id and login fails.

Root cause: the DRAPI Admin UI caches OIDC discovery results in browser localStorage; changing the server config doesn’t auto-invalidate that.

Fix: after any OIDC config change, open DevTools → Application → Local Storage, wipe storage for the DRAPI site, then retry. Or test in an incognito window.

Pitfall 4: Default client scopes don’t back-apply to existing clients

You add a new default client scope in Keycloak (e.g. $DATA) expecting the existing Domino client to pick it up automatically — fresh login still fails with missing scope.

Root cause: Keycloak’s default client scope only applies to clients created after the setting; existing clients aren’t retroactively updated.

Fix: Keycloak Admin Console → Clients → select the Domino client → Client Scopes tab → manually Add the scope to “Assigned default client scopes”.

Complete setup walkthrough

The article doesn’t reproduce the steps (to avoid drift) — the full flow covers:

1. WSL Ubuntu 24.04 + Java 21 environment
2. Keycloak install and startup (self-hosted, no Docker)
3. Keycloak realm / client / scope / test user configuration
4. HTTPS / hostname setup (PEM certificate)
5. DRAPI keepconfig.d wiring
6. JVM truststore trusting the Keycloak certificate
7. Identity mapping — token email claim to Person doc Internet address
8. Scope authorization — $DATA / $SETUP / keepconfigadmin
9. certstore.nsf integration test notes

Two places carry the full content:

• GitHub repo: bryanHsiao/drapi-oidc-keycloak
• Public site: drapi-oidc-keycloak Pages

The two stay in sync; the site has cleaner reading layout, the repo can be cloned and walked through against actual config samples.

How this fits with Domino 14 / the 5/31 article

This demo walks the “external IdP (Keycloak) → DRAPI OIDC” path, which is a different layer from the Domino 14.5.1 NotesSession / Session OIDC token API mentioned in the Domino 14 changes article:

• This demo (DRAPI + Keycloak oidc mode): authenticates web / mobile client requests hitting DRAPI — server-side endpoint auth
• 14.5.1 OIDC token API: lets server-side LotusScript / Java code actively obtain a token from the Domino OIDC Provider — application-code-initiated OIDC token request

Together they’re the two faces of Domino’s authentication modernisation from “domcfg form / LTPA cookie” to “full OIDC”: reader-facing (this demo) and code-facing (the 14.5.1 API).

When the server eventually moves to Domino 14+, migrating this demo from oidc to oidc-idpcat mode is the obvious next step — DRAPI and Domino server share the same idpcat.nsf config, share the token cache, and the whole setup gets cleaner.

Closing

“DRAPI + OIDC needs Domino 14” is a widespread misconception — oidc mode works on 12.0.2 and is decoupled from server version. The cost of actually getting it running is the number of setup steps plus a few version-specific traps (the localhost one in particular) that can eat half a day.

Having walked the full setup once, the biggest takeaway isn’t that OIDC is complicated — it’s that DRAPI designed authentication as three independent checkpoints. Debugging by following identity → mapping → authorization in order takes a fraction of the time of trying to fix everything at once.

The complete implementation repo is up on GitHub + Pages — clone and walk through it to reproduce the local demo.
