Containerizing HCL Domino 9.0.1 Outside HCL's Official Scope — A Community PoC and 5 Pitfalls You'll Hit

TL;DR

• HCL only ships container images for Domino 10.0.1 FP3 and up (the previous post covered the two official paths) — anyone still on 9.0.x is outside the official support scope
• A community PoC proves it’s doable: RHEL UBI 7.9 base, two-stage build, ~1.48 GB image running Domino 9.0.1 FP10, joining an existing Domino domain, with HTTP / NRPC / LDAP / IMAP / POP3 / SMTP all coming up normally
• The PoC hit 5 pitfalls HCL docs don’t mention: Perl namespace bug / FP installer rejects -silent / J9 JVM heap too small / setup-complete marker uses the wrong variable / password-protected server.id stdin block
• Full Dockerfile + entrypoint + troubleshooting in the public bryanHsiao/build-hcl-domino9-container repo
• ⚠️ Suitable for dev/test, migration rehearsal, legacy server preservation — not a replacement for production bare-metal/VM; self-built images sit outside HCL’s support scope

Why would anyone containerize Domino 9?

“Who’s still running Domino 9 in 2026?” — more people than you’d think.

The realistic scenarios:

• App compatibility lockdown — an internal XPages app or an ISV product is certified only against 9.0.x, and the customer hasn’t finished the V10/V14 upgrade regression test
• Migration rehearsal — before going from 9 to 14, run a dry run in dev: real data, a containerized 9 server, verify NSF compat / template upgrade / Notes client behavior all hold up
• Legacy server preservation — historical workloads (compliance, audit, archived data from departed staff) need an environment that can still open old NSFs, without paying to keep a VM alive

The traditional answer is “keep a Domino 9 VM around” — but VM maintenance isn’t cheap (OS patching, backups, host resources, IP planning). If you can move it into a container, you get the modern container workflow (image goes to a private registry, starts fast, stops fast, doesn’t squat on host resources).

The catch: HCL doesn’t give you an official V9 container image.

Where HCL’s line actually is

The previous post covered HCL’s official container story from V10 onwards:

• Path A — download an official pre-built container image TAR from My HCLSoftware Portal and docker load it
• Path B — use the open-source HCL-TECH-SOFTWARE/domino-container build tooling to build your own

Both paths start at Domino 10.0.1 FP3. The entire 9.0.x line is officially “unsupported but works” — no images, no build scripts, no docs.

If you want to containerize 9.x, the only remaining route is full self-build: write your own Dockerfile, handle Domino 9’s silent installer, navigate the setup wizard, and troubleshoot corner cases that aren’t documented anywhere.

The PoC below is a trace of walking that route end-to-end.

PoC outcome

Environment:

• Host: Windows 11 + WSL2 (Ubuntu 24.04 isolated distro) + Docker Engine 29.5.2
• Base image: registry.access.redhat.com/ubi7/ubi:7.9 (Red Hat ELS through 2028)
• Domino version: 9.0.1 base + Fix Pack 10
• Build: two-stage (builder → runtime) silent install + FP10 patch

Output:

REPOSITORY    TAG          IMAGE ID       SIZE
domino9       9.0.1fp10    a8b4c5d2e9f1   1.48GB

Runtime validation (via Notes Admin client running the remote setup wizard):

• ✅ Container went from first-run listen mode through the wizard, server registration complete
• ✅ Restart launched the daemon cleanly, HTTP responds 200 OK
• ✅ Joined an existing Domino domain (existing cert.id + pre-registered server.id)
• ✅ Tasks: HTTP / NRPC / LDAP / IMAP / POP3 / SMTP / Router / Replica all started normally
• ✅ Replicated databases from an existing production server successfully

Verdict per 9.0.x sub-version (excerpt — full table in the repo’s feasibility report):

→ Recommended baseline: 9.0.1 FP10 + Server IF7 or higher + RHEL UBI 7.9

5 pitfalls you’ll hit

For each: the symptom (terminal output), root cause, and the fix.

Pitfall #1: UBI 7 doesn’t ship hostname, install.pl crashes with a Perl namespace bug

docker build runs through to the silent install step, then suddenly dies with:

Undefined subroutine &DingDong::out called at install.pl line 65

Why: Domino 9’s install.pl line 65 needs to call hostname and clear; UBI 7 minimal images don’t ship the hostname package by default. InitCmds() detects the missing command and tries to call out() to report the error — but out() is defined in package main:: while the call site is in package DingDong;, so Perl can’t resolve it and dies with the cryptic message above.

Fix: add a yum install step to the Dockerfile:

RUN yum install -y hostname ncurses procps-ng tar unzip

hostname solves the immediate line-65 problem; ncurses provides clear / tput; procps-ng / tar / unzip are common follow-on omissions the silent install also relies on.

Pitfall #2: The FP installer rejects the -silent flag

Base 9.0.1 install runs ~7 minutes and finishes cleanly, then the FP10 install dies immediately:

Usage: install [-script <scriptfile>]
ERROR: unknown argument '-silent'

Why: the base installer accepts -silent -options <file>; the FP installer accepts only -script <file> and doesn’t recognize -silent. Two different binaries with different argument specs — HCL never documented this in the same place.

Fix: for the FP install step, use -script without -silent, and set the environment variable that points at the base install:

ENV NUI_NOTESDIR=/opt/ibm/domino
RUN cd /tmp/fp10 && ./install -script script.dat

Pitfall #3: The bundled J9 JVM runs out of heap during the setup wizard

The container starts, you point Notes Admin client at serversetup -remote <host>:8585 to run the wizard, and the Admin client returns a network error. Container log:

java/lang/OutOfMemoryError

Why: the 2013-era Domino 9 bundles IBM’s J9 JVM, and the serversetup script launches it with only stack flags (-ss512k -Xmso5M) — no heap upper bound (-Xmx) at all. J9’s default heap is ~64 MB, which isn’t enough to load the wizard’s Swing GUI classes. JAVA_TOOL_OPTIONS is ineffective with this J9 build (it doesn’t honor it).

Fix: sed-patch the serversetup script line 168 in the Dockerfile to inject heap arguments:

RUN sed -i 's|"$JAVA" |"$JAVA" -Xmx512m -Xms128m |' \
    /opt/ibm/domino/notes/latest/linux/serversetup

Pitfall #4: The setup-complete marker is Setup=, not ServerName=

The setup wizard finishes, the container restarts, the entrypoint should just start the server — but it runs the wizard again.

Why: a lot of containerized Domino templates (including HCL’s V10+ path) check grep ServerName= notes.ini to decide whether setup is done. Domino 9 doesn’t write ServerName= to notes.ini at all — it writes Setup=900100, a version-code marker. An entrypoint looking for ServerName= will never find it, will always assume setup is incomplete, and will always drop back into listen mode.

Fix: change the detection to match Setup=<digits> instead:

if grep -qE "^Setup=[0-9]" "$NOTES_INI"; then
    exec "${DOMINO_HOME}/bin/server"
else
    exec "${DOMINO_HOME}/bin/server" -listen
fi

Pitfall #5: A password-protected server.id blocks on stdin at startup

Setup wizard done, docker restart into normal mode, the container looks like it’s up — but HTTP doesn’t respond and CPU is at 0%. docker logs:

Enter password (press the Esc key to abort):

Why: the server.id was registered with a password, and Domino reads that password from stdin at startup. In docker run -d mode there’s no interactive stdin, so the prompt blocks indefinitely.

Fix: have the entrypoint read the password from an environment variable and pipe it into the server’s stdin:

printf '%s\n' "${DOMINO_ID_PASSWORD}" | "${DOMINO_HOME}/bin/server" &

At runtime:

docker run -d -e DOMINO_ID_PASSWORD='your-passphrase' ...

Full troubleshooting (including 4 other secondary pitfalls, complete log dumps, and the patch details) lives in the repo’s TROUBLESHOOTING.md.

Want to give it a spin?

What you need:

1. HCL Domino 9 entitlement + a FlexNet Portal account — download installers from hclsoftware.flexnetoperations.com: DOMINO_9.0.1_64_BIT_LIN_XS_EN.tar (~834 MB) + domino901FP10_linux64_x86.tar (~441 MB)
2. Linux host or WSL2 — Ubuntu 22.04/24.04, Debian 12, RHEL 9 all work
3. Docker Engine 20.10+ (tested up to 29.x)
4. ~5 GB of disk space + at least 2 GB RAM available to the container

Rough flow:

git clone https://github.com/bryanHsiao/build-hcl-domino9-container.git
cd build-hcl-domino9-container/dockerfiles/domino9.0.1-fp10-ubi7

# Drop the downloaded installers in
cp /path/to/DOMINO_9.0.1_64_BIT_LIN_XS_EN.tar .
cp /path/to/domino901FP10_linux64_x86.tar .

# Build (~10-12 min)
docker build -t domino9:9.0.1fp10 .

# Run (first-run listen mode, waiting for Notes Admin to connect)
docker volume create domino9-data
docker run -d --name domino9 --hostname domino9 \
  -p 1352:1352 -p 80:80 -p 8585:8585 \
  -v domino9-data:/local/notesdata domino9:9.0.1fp10

Detailed setup-wizard walkthrough and the “joining an existing domain” path are in repo BUILD.md and ADDITIONAL-SERVER.md.

⚠️ Boundaries to know before you go

This PoC is not a production replacement and is not inside HCL’s official support scope. Explicit envelope:

• ✅ Suitable for: internal dev/test, dry-run rehearsal before a V14 migration, legacy data preservation (reading old NSFs)
• ❌ Not suitable for: replacing an existing production bare-metal/VM Domino 9 server (HCL 9.x EOM 2024-06, EOS 2026-06, and self-built images sit outside the support scope)
• ⚠️ License: the HCL Domino EULA doesn’t explicitly prohibit container deployment, but doesn’t explicitly endorse 9.x either; check your entitlement’s PVU / Authorized User accounting with HCL Support
• ⚠️ Distribution: the built image contains Domino binaries — do not push to public registries or share with anyone who doesn’t already hold an entitlement; private internal registry only
• ⚠️ Issue reproduction: if a self-built container hits a real bug, HCL Support requires reproduction on a certified bare-metal/VM platform before they’ll take the case; keep a comparison environment handy

→ The long-term direction is still to upgrade to Domino 14.5.1 (Domino 2026) and switch to the official container path; this PoC just gives a dev/test container option to “stuck on 9 for now” scenarios.

Wrap-up

The 5 pitfalls (Perl namespace / FP installer flag / J9 heap / setup marker / server.id stdin) are all “docs don’t mention it, you only know after you hit it” territory. This PoC bundles the trip hazards into a reproducible Dockerfile so the next person still stuck on V9 doesn’t have to walk into them blind.

Full build scripts, Dockerfiles, troubleshooting, and operations docs all live in bryanHsiao/build-hcl-domino9-container — MIT license, PRs welcome, no SLA.
