The Two Jobs of dircat: You Think It Only Builds the Directory Catalog — Since Domino 12 It Also Runs Entitlement Auditing
See dircat (Directory Cataloger) in show tasks and your first thought is probably “oh, the directory catalog thing” — aggregating the company’s several Domino Directories into one directory that’s easy to look names up in. Right, that’s its day job. But since Domino 12, this task quietly picked up a second one with nothing to do with directories: aggregating each server’s entitlement data for licensing-compliance auditing. One task, two unrelated identities — and the second one is exactly why a server that shouldn’t be minding everyone else’s business suddenly starts “connecting to every server in the domain.”
TL;DR
- Day job: dircat aggregates multiple Domino Directories into a Directory Catalog, so clients and servers can quickly look up addresses, names, groups, and resources.
- Two catalog types: condensed (
DIRCAT5.NTF, for Notes clients, hugely compressed, works offline) vs extended (PUBNAMES.NTF, for servers, faster and more flexible lookups). - Second job (since Domino 12): dircat also “manages the synchronization process” that aggregates each server’s entitlement data into
entitlements.nsf— entitlement/licensing compliance tracking, unrelated to directories. - One gotcha: build a condensed catalog from
DIRCAT5.NTF— notCATALOG.NTF(that’s the database catalog, a completely different thing). - The cost of one task, two jobs: once a box is wrongly promoted to domain admin, dircat’s second identity fires — walking the whole domain to aggregate entitlement data, flooding on whatever it can’t reach.
Day job: aggregating Domino Directories into one catalog
HCL’s definition of a directory catalog is plain:
A directory catalog is an optional directory database that typically contains information aggregated from multiple Domino directories.
Its purpose is to let clients and servers “look up mail addresses and other information about the people, groups, mail-in databases, and resources throughout an organization” — look people and addresses up across several domains / Domino Directories without paging through each one.
dircat is the task that builds and maintains this catalog. HCL describes its actions: the first run builds it; after that it usually updates — “it checks for changes to the contents of fields in the source Domino Directories, and then makes the appropriate changes to the directory catalog” — with partial and full rebuilds also available. Scheduled runs, incremental updates: that’s its daily routine.
Two catalog types: condensed vs extended
| Type | Template | Used on | Character |
|---|---|---|---|
| Condensed | DIRCAT5.NTF | Notes clients | combines multiple documents into single documents; hugely compact; offline name lookups |
| Extended | PUBNAMES.NTF (same template as the Domino Directory) | servers | ”faster and more flexible directory lookups” |
The condensed compression is dramatic: HCL’s own example takes a directory of “more than 350,000 users and total 3GB” down to a condensed catalog of “only about 50MB” — by “combin[ing] multiple documents from Domino directories into single documents,” which is what lets it fit on a client for offline use. Note that a condensed catalog is no longer supported on a server (“Using a condensed directory catalog on a server is no longer supported”); on servers, use extended.
A common gotcha: to build a condensed catalog, select DIRCAT5.NTF — HCL explicitly warns “DO NOT select the Catalog (V6) template (CATALOG.NTF).” CATALOG.NTF is the database catalog (what databases exist on a server) — a different thing with a confusingly similar name; pick it and the whole thing is wrong.
Second job: since Domino 12, dircat also aggregates entitlements
Here’s the part a lot of people miss. Since Domino 12, the domain-wide aggregation for Entitlement Tracking was also handed to dircat. HCL’s wording:
The entitlement data collected daily by each Domino server in a domain is also aggregated for the entire domain on the domain administration server. The directory catalog task manages the synchronization process…
In other words: the same dircat, besides maintaining the directory catalog, is responsible for aggregating each server’s daily-collected entitlement data (each user’s highest access level, for HCL licensing compliance) into entitlements.nsf. This runs only on the domain administration server.
Why hand it to dircat? Probably because dircat is already the “aggregate data across servers” specialist, so aggregating entitlement data reuses the same synchronization machinery. But as a responsibility, it’s a different job from building the directory catalog — one is looking up addresses for people, the other is counting licenses for the vendor. The name only tells you about the first.
One task, two identities — how it bites
The trouble is that both jobs share one auto-starting dircat:
- You see
dircatinshow tasks(see the site’s console troubleshooting piece), and the name alone won’t tell you which identity it’s in, or whether it’s doing both. - Worse, entitlement aggregation is tied to the domain administration server identity. Once a box is wrongly promoted to domain admin (say, someone changed
names.nsf’s Administration Server while setting up CertMgr), dircat’s second identity fires — walking the server list innames.nsfto aggregate entitlement data across the domain, throwing an error every 5 seconds on whatever it can’t reach. The full cause-and-fix is in the Domino admin-server identity piece. - How to tell which job it’s doing: read
console.log. “Entitlement Tracking Aggregator processing directory CN=…!!entitlementtrack.ncf” is the second identity (entitlement aggregation); ordinary directory-catalog build/update messages are the day job.
Can you turn off just the audit half?
Since both identities ride one task, the natural next question is: can you disable just the entitlement-audit half and keep the directory-catalog day job? Honestly — there’s no clean, official switch.
- No documented disable setting: the official entitlement tracking page says nothing about turning it off, and notes that the database and collection are “offered as is.”
DISABLE_ENTITLEMENT_TRACKING=1is a community setting, and it targets the wrong layer: this notes.ini setting that circulates online isn’t in HCL’s docs, and it addresses the local collection layer (each server building its ownentitlementtrack.ncf), not the aggregation layer. In practice, adding it on an aggregating server and cold-starting still leaves dircat aggregating — it doesn’t stop the audit half.- What actually separates them is the role, not a switch: aggregation runs only on the domain administration server. So to make a server’s dircat do directory catalog only and never touch entitlement aggregation, keep it from being the domain admin (hand
names.nsf’s Administration Server back to the real domain admin server) — which is exactly the fix in the Domino admin-server identity piece. Conversely, on the domain admin server itself, there’s no verified, supported way to keep the directory catalog but drop entitlement aggregation.
In one line: the audit half is bound to the domain-admin role, not toggled off by some XXX=off switch. To keep a server out of entitlement aggregation, keep it from being the domain admin.
Wrap-up
dircat is a task with a misleading name: it says “Directory Cataloger,” and its day job really is building the directory catalog — condensed for clients, extended for servers. But since Domino 12 it carries a second identity the name never mentions: licensing-compliance entitlement aggregation. Know that, and the next time you see dircat “connecting to every server in the domain” on an additional server, you won’t assume the directory is broken — that’s its second job running, and what to check is whether this box was accidentally made the domain administration server.
