NotesUIWorkspace × NotesUIDocument: Front-End Automation in LotusScript

The classes this site has covered so far — NotesDatabase, NotesDocument, NotesView — are all back-end. They run on the server, in background agents, never seeing (and never needing) the user’s screen. But there’s a whole category of need they can’t touch: the user is typing into a form and hasn’t saved yet, and you want to read the value on their screen right now; or pop a “Are you sure you want to submit?” dialog when they click a button; or flip the open document straight into edit mode.

All of that happens on the “front end” — inside the Notes Client window. The other half handles it: NotesUIWorkspace (the current workspace window) and NotesUIDocument (the document currently open). This article unpacks the front-end pair, and the one concept that costs people hours of debugging if they miss it: the value on screen is not the same thing as the value the back-end Document has stored.

TL;DR

• NotesUIWorkspace is created with Dim ws As New NotesUIWorkspace — it represents “the current workspace window”
• ws.CurrentDocument gives you a NotesUIDocument — the document the user has open and focused right now
• The core concept: NotesUIDocument is the on-screen document (including unsaved edits); its .Document property is the back-end NotesDocument (the last-saved state)
• Read/write on-screen fields with FieldGetText / FieldSetText; they don’t reach the back end until a save
• Interact with the user via Prompt (yes/no / input / list dialogs) and PickListStrings (pick people or documents from a list)
• The rule: UI classes cannot run in a background agent, an API-called agent, or an agent triggered by NotesAgent.Run — only workstation users can

Front-end vs back-end: get this one first

This is the most common trap with the UI classes, so let’s nail it up front. Say a user opens a document and changes the Subject field from “Quote” to “Quote (revised)” — but hasn’t saved yet. At that moment:

The docs define NotesUIDocument as “Represents the document that’s currently open in the Notes workspace” — it’s the one on screen. Its Document property is described plainly: “The back-end document that corresponds to the currently open document.”

So the rule is simple: unsaved edits live only on the front end. To read what the user just typed but hasn’t saved, use FieldGetText; to read what’s actually committed to the database, go through .Document. Confuse the two and you get the classic “but I changed it and the code still reads the old value” head-scratcher.

NotesUIWorkspace: getting “the current thing”

NotesUIWorkspace is your entry point to the front end — just New it:

Dim ws As New NotesUIWorkspace
Dim uidoc As NotesUIDocument
Set uidoc = ws.CurrentDocument

Its three Current* properties map to the three things in front of the user:

⚠️ A focus trap: the docs warn that code in a form can’t assume it has focus unless it’s attached to an action button or similar control. In a composite application or a preview pane, CurrentDocument may not be the one you expect. Putting CurrentDocument calls in a button event is the safe bet.

NotesUIDocument: driving the open document

Once you have uidoc, the most-used group is the field operations:

The smallest official example just prints the current document’s Subject:

Dim workspace As New NotesUIWorkspace
Dim uidoc As NotesUIDocument
Set uidoc = workspace.CurrentDocument
Messagebox( uidoc.FieldGetText( "Subject" ) )

Document state is controlled by: Save(), Close(), Refresh() (per the docs, “its computed fields are recalculated”), and Reload() (pull back-end changes into the front end). Plus a few common properties: IsNewDoc (“a document that hasn’t been saved”), EditMode (read-write, whether you’re in edit mode), and ModifiedSinceSaved (are there unsaved changes).

FieldSetText or Document.ReplaceItemValue?

Both change a field, but the timing differs:

• FieldSetText changes the on-screen value — the user sees it immediately, and it triggers dependent form logic. Use it when “the user has the document open and you want to update what they see, live.”
• Document.ReplaceItemValue (via the back-end NotesDocument) changes the back-end value without touching the UI. Use it for background processing or programmatic edits that need no visual feedback.

Quick rule: a person is looking at the screen and needs to see the change → FieldSetText; everything else → the back-end Document.

Talking to the user: Prompt and PickList

The most useful thing the front-end classes offer is “ask the user.” Prompt packs several dialog types into one method — the docs: “Displays a dialog box and returns a value based on your actions in the dialog box.”

Dim ws As New NotesUIWorkspace
Dim ans As Variant
ans = ws.Prompt(PROMPT_YESNO, "Confirm", "Submit this quote?")
If ans = 1 Then
    Call uidoc.Save()
End If

The first argument’s constant picks the dialog type. The common ones:

The signature is ws.Prompt(type%, title$, prompt$ [, default] [, values]) — for the list types, pass the choices in the values array.

To let the user “pick documents from a view,” use PickListStrings (docs: “Creates a string array from a list selected by the user”) or PickListCollection (returns a NotesDocumentCollection). Far less work than hand-rolling a selection list.

The rule you must know: no UI classes in the background

This is the sharpest line between the UI classes and the back-end ones, and the wall newcomers hit most. Verbatim:

“You cannot use the UI classes in a background agent, an agent called through an API, or an agent called by the NotesAgent Run method. Only workstation users can run scripts that access UI objects.”

In other words: the UI classes are only for a real person at a workstation. Put a NotesUIWorkspace inside a scheduled agent, a web agent, or one triggered by NotesAgent.Run, and at best you get Nothing, at worst an error. To modify documents in the background, stick to the back-end NotesDatabase / NotesDocument.

That restriction is really the flip side of the front-end/back-end split above: the UI classes exist on the premise that “there’s a user, and there’s a screen.” Where there’s no screen, they were never the right tool.

What about Java and SSJS?

As with the GPS trio, the cross-language verdict is no counterpart:

NotesUIWorkspace / NotesUIDocument are LotusScript + Notes Client only front-end classes. The equivalent interaction on the web runs through XPages’ own world — a separate topic for a future article, not the same path as this client front end.
