NotesUIScheduler: Driving the Embedded Free/Busy Grid From LotusScript

You’re building a custom meeting or room-booking form, and it has an embedded scheduler — the busy-time grid where you drop in attendees and a room and see everyone’s free/busy laid out. The control renders itself; the question is how you drive it from code: prefill the required attendees, add the room as a resource, refresh the grid, and read back the slot the user settled on so you can save the meeting. That’s exactly what NotesUIScheduler is for.

Unlike the empty Button / Field / Navigator classes, this one has real state — fifteen display properties, four methods, two events. This is a field report on the one front-end scheduling class: how you get it, manage its participants, refresh its data, and hook its interval. It’s new with Release 6, front-end (Notes client) only, and not supported in COM.

TL;DR

• NotesUIScheduler “represents an embedded scheduler in a document.” You get it by name off the open UI document: Set sched = uidoc.GetSchedulerObject("SchedulerName") — the embedded scheduler must be named and present on the form.
• Manage attendees with AddParticipant, RemoveParticipants, and GetParticipants; then call GetScheduleData to refresh the free/busy grid after the participant list changes.
• The Interval property is the meeting slot the grid is showing / the user picked — read it to save the meeting, or set it to move the selection.
• The Display* properties (DisplayRooms, DisplayResources, DisplayMeetingSuggestions, DisplayCheckboxes, …) toggle what the grid shows.
• Two events: OnIntervalChange (the user dragged a new slot) and OnSuggestionsAvailable (the selected-names set changed).

Getting the object

The scheduler is an embedded control you place and name on the form in Designer. At runtime you reach it from the open NotesUIDocument, not by constructing it:

Dim ws As New NotesUIWorkspace
Dim uidoc As NotesUIDocument
Set uidoc = ws.CurrentDocument

Dim sched As NotesUIScheduler
Set sched = uidoc.GetSchedulerObject("RoomScheduler")   ' the control's name in Designer

If the name doesn’t match a scheduler on the current form, you get nothing back — so the name string is the one thing to keep in sync with the form design. SchedulerName (read-only) reflects it back if you need to confirm which control you’re holding.

Participants and the refresh

The four methods are all about the attendee list. AddParticipant adds a person, room, or resource; RemoveParticipants takes them out; GetParticipants reads the current set. The one to remember is GetScheduleData — after you change the participant list, the grid doesn’t re-query free/busy on its own, so you call GetScheduleData to refresh it:

Call sched.AddParticipant("CN=Alex Chen/O=Acme")
Call sched.AddParticipant("Conference Room 3/Acme")   ' a room resource
Call sched.GetScheduleData()                           ' re-query busy time for the new set

Forgetting the refresh is the classic bug here: you add three required attendees in code, the grid still shows the old two, and the meeting suggestions are computed against the wrong set. Add participants, then refresh.

Reading the chosen slot

The Interval property is the meeting time the grid is focused on — the start/end the user dragged to, or the suggestion they accepted. It’s how the front-end selection gets back into your code: read Interval when the user confirms, and write the start and end into the meeting document (as NotesDateTime values) before saving. You can also set Interval to move the grid’s selection programmatically — handy for seeding the form with a proposed time. The remaining display properties (ScheduleGridStart, DisplayHoursPerDay, TimeZone, DisplayRooms, DisplayResources, DisplayMeetingSuggestions) are the knobs for how much of the grid the user sees and in which time zone — set them once when the form opens.

The two events

OnIntervalChange fires when the user drags to a different slot — the hook for “recompute cost / check the room capacity / update a label” as the proposed time moves. OnSuggestionsAvailable fires when the selected-names set changes and fresh meeting suggestions have been computed — the hook for reacting once the free/busy for a new participant list is ready. Both are front-end events on the control, same Query*-less notification model as the rest of the UI classes: they tell you something happened, and you reach back through the scheduler (and the UI document) to act on it.

What about Java and SSJS?

There’s no counterpart to the control, for the usual reason — it’s a Notes-client UI element, and neither the Domino Java API nor XPages SSJS has a NotesUIScheduler. What does carry across is the free/busy data underneath it: on the back end you compute or read busy time through NotesCalendar and the calendar/scheduling store, and a modern web scheduler is built on the Domino REST API’s calendar endpoints rather than an embedded control. So the grid is classic-client-only; the availability data it visualises is reachable everywhere, just through a different door.
