NotesStream and Text Encoding: Charsets, the BOM, and the Byte-vs-Character Trap

You write a CSV export from an agent, it opens fine on your machine, and then a colleague reports the accented names come out as mojibake — or the file has a stray character at the very start that breaks their importer. Both are NotesStream encoding issues, and both are avoidable once you know three facts the class quietly assumes you understand: the charset you opened with, whether a byte-order mark got written, and that Position counts bytes, not characters.

TL;DR

• Open with an explicit charset: stream.Open(path$, "UTF-8"). The default is "System" (the machine’s ANSI code page) — rarely what you want for portable text. The Charset property is read-only; you set it through Open.
• WriteText emits a BOM only for the UTF-16 family, never for UTF-8. The docs: on an empty file with charset “Unicode, UTF-16, UTF-16BE, or UTF-16LE,” it “writes byte order mark or signature bytes at the beginning of the stream.” UTF-8 is deliberately absent from that list.
• Position is a byte offset — “No special support exists for multi-byte characters.” Setting Position = n can land you inside a UTF-8/UTF-16 character.
• Bytes never equals Len(text) for non-ASCII, and it excludes the BOM: “The size excludes any detected Unicode signatures or byte order marks.”
• Line endings are constants: WriteText(text$, eol&) defaults to EOL_NONE (5); ReadText defaults to EOL_CRLF (0). The asymmetry means round-tripping lines needs explicit constants.

Opening with the right charset

A NotesStream — “a stream of binary or character data” — comes from the session, and the charset is an argument to Open:

Dim session As New NotesSession
Dim s As NotesStream
Set s = session.CreateStream
If Not s.Open("c:\export\names.csv", "UTF-8") Then
  Print "Open failed" : Exit Sub
End If

The accepted charset names include ASCII, ISO-8859-1 through -15, Shift_JIS, Big5, GB2312, UTF-7, UTF-8, UTF-16, UTF-16BE, UTF-16LE, the Windows-125x family, and System (the default — the OS ANSI code page). The read-only Charset property reports back whatever you opened with; you can’t assign it directly. The asymmetry matters: Open’s argument decides how bytes on disk are encoded and decoded, and reopening the same file with a different charset mis-decodes it silently — the API won’t warn you.

The BOM: UTF-16 yes, UTF-8 no

This is the single most useful fact in the class. Per the WriteText docs:

“If the stream is opened on an empty file and the character set is Unicode, UTF-16, UTF-16BE, or UTF-16LE, this method writes byte order mark or signature bytes at the beginning of the stream.”

UTF-8 is not in that list — so a UTF-8 stream gets no BOM. That’s usually what you want (most Unix tooling dislikes a UTF-8 BOM), but it means if some consumer requires a UTF-8 BOM, you have to write those bytes yourself. Conversely, a UTF-16 file gets a BOM automatically — but only when the file starts empty. And the BOM is invisible to Bytes: “The size excludes any detected Unicode signatures or byte order marks,” so don’t use Bytes to compute on-disk file size when a UTF-16 BOM is present.

Position is bytes, not characters

The trap that produces corrupted reads. The Position property is an “offset from the beginning of the stream in bytes,” and the docs add the crucial warning: “No special support exists for multi-byte characters.” In UTF-8, an accented Latin character is two bytes and a CJK character is three; in UTF-16 everything is at least two. So Position = 5 lands at byte 5, which may be the middle of a character. Seeking to a character boundary means knowing the byte widths yourself — there’s no character-based seek.

The corollary is that Bytes (on-disk size) and Len(text) (character count) diverge for anything non-ASCII, which is the cleanest way to see the encoding at work:

Sub Initialize
  Dim session As New NotesSession
  Dim s As NotesStream
  Dim txt As String
  txt = "Héllo 世界"                     ' accents + CJK

  ' Write UTF-8 (no BOM), then compare byte size to character length
  Set s = session.CreateStream
  Call s.Open("c:\export\demo.txt", "UTF-8")
  Call s.Truncate                        ' ensure empty
  Call s.WriteText(txt, EOL_CRLF)
  Print "Charset:   " & s.Charset
  Print "Bytes:     " & s.Bytes          ' > Len(txt): é=2 bytes, 世/界=3 bytes each
  Print "Len(txt):  " & Len(txt)         ' character count
  Call s.Close

  ' Read back with the SAME charset
  Set s = session.CreateStream
  Call s.Open("c:\export\demo.txt", "UTF-8")
  s.Position = 0                         ' byte 0 = start (safe)
  Print "Round-trip: " & s.ReadText()
  Call s.Close
End Sub

(Constructed from the documented Open / WriteText / ReadText / Bytes signatures to isolate the encoding behaviour, rather than a single verbatim HCL listing.)

Bytes will report more than Len(txt) here — that gap is the multi-byte encoding, made visible. And because we read back with the same "UTF-8" we wrote with, the round-trip is clean; open it as System or ISO-8859-1 instead and the accented characters mangle.

Line endings

WriteText’s optional second argument is the end-of-line style, and the constants are worth pinning: EOL_CRLF (0), EOL_LF (1), EOL_CR (2), EOL_PLATFORM (3), EOL_ANY (4, read side — treats any of CR/LF/CRLF as a line break), EOL_NONE (5). The catch is the defaults differ by direction: WriteText defaults to EOL_NONE (it appends nothing), while ReadText defaults to EOL_CRLF. If you write lines without specifying an EOL and then read them line-by-line expecting CRLF, they won’t split — pass the constants explicitly on both sides.

What about Java and SSJS?

Java’s lotus.domino.Stream and the SSJS Stream (both via session.createStream()) carry the same charset argument on open, the same EOL_* constants, and the same byte-based Position. The BOM behaviour and the bytes-vs-characters distinction are properties of the encoding, not the language, so every caveat here applies identically — the method names just lowercase to writeText / readText.
