NotesRichTextTable: Dropping a Table into Rich Text from Code

You’re assembling a rich text notification email in code with NotesRichTextItem, and the body needs a small table — order line items, an approval summary, a reconciliation list. Plain text can’t lay out clean gridlines, and that’s where NotesRichTextTable comes in.

The official definition is short: “Represents a table in a rich text item.” (new in Release 6). Like the other classes in this site’s Rich Text series, it isn’t created with New — it grows out of a rich text item: call AppendTable, and what comes back is the table object.

TL;DR

• Create it with NotesRichTextItem’s AppendTable, which “Inserts a table in a rich text item.”
• Properties (mostly read-only): RowCount / ColumnCount, Color / AlternateColor (primary / alternate color), RightToLeft (read-write, right-to-left reading order).
• Methods: AddRow, RemoveRow, SetColor, SetAlternateColor.
• Walk an existing table with NotesRichTextNavigator using RTELEM_TYPE_TABLE to find the table and RTELEM_TYPE_TABLECELL to get cells (cells are ordered by row, then column).
• The key limitation, verbatim: you can’t determine a cell’s contents (text paragraphs, runs, doclinks…) unless you know the rich text’s exact structure.

Creating it: AppendTable

Dim doc As NotesDocument
Set doc = db.CreateDocument()
Dim body As NotesRichTextItem
Set body = doc.CreateRichTextItem("Body")

Dim table As NotesRichTextTable
Set table = body.AppendTable(3, 2)   ' 3 rows, 2 columns

AppendTable’s basic arguments are “how many rows, how many columns” (it also has optional arguments for left-column labels, margins, paragraph styles). What you get back is a NotesRichTextTable.

Properties and methods

The alternate color is handy — set SetColor + SetAlternateColor and the table alternates color row by row (zebra striping), which makes a long table far more readable:

Dim session As New NotesSession
Dim white As NotesColorObject
Dim gray As NotesColorObject
Set white = session.CreateColorObject() : white.NotesColor = COLOR_WHITE
Set gray = session.CreateColorObject() : gray.NotesColor = COLOR_GRAY
Call table.SetColor(white)
Call table.SetAlternateColor(gray)

Walking an existing table

To read a table in an existing document (not build a new one), use a NotesRichTextNavigator: find the table with RTELEM_TYPE_TABLE and walk cell by cell with RTELEM_TYPE_TABLECELL (the docs: cells are ordered “by row, then column”).

But there’s a limitation you must know, and the docs state it plainly:

“You cannot determine the contents of a cell (text paragraphs, text runs, doclinks, and so on) unless you know the exact structure of the rich text item.”

In other words — you can reach “which cell”, but whether that cell holds text, a doclink, or something else, you have to know the structure in advance to decode it. Rich text is fundamentally a stream of mixed elements, and a table cell won’t label the types for you. So “automatically parsing the contents of arbitrary rich text tables” is harder than it sounds; the controllable scenario is “the table was built by your own code and you know its structure.”

What about Java and SSJS?

Consistent across all three: appendTable to create, addRow / removeRow, the alternate-color pattern. To produce table-bearing rich text in a back-end Java agent (an automated reconciliation email, say), this carries straight over. Pair it with the site’s NotesRichTextStyle to control fonts and colors along the way.
