NotesRichTextParagraphStyle, NotesRichTextTab & NotesColorObject: Laying Out Rich Text in Code

You’re generating a report document from an agent — a title centred, body indented, figures lined up on a decimal tab, a heading in your brand blue. In Designer you’d do all this by clicking in the editor. From LotusScript, formatting isn’t part of AppendText — it lives in separate style objects you apply before the text they govern.

Three of those objects work together: NotesRichTextParagraphStyle holds paragraph layout, NotesRichTextTab represents one tab stop inside it, and NotesColorObject does the colour arithmetic. This piece walks through all three and the one gotcha that surprises everyone: the colour object doesn’t actually colour your text.

TL;DR

• Create a paragraph style with session.CreateRichTextParagraphStyle, set alignment / margins / spacing / tabs, then Call rtitem.AppendParagraphStyle(style) before appending the text it should govern.
• Margins and tab positions are in twips — RULER_ONE_INCH = 1440, RULER_ONE_CENTIMETER = 567. The docs put it plainly: “one centimeter is 567 twips and one inch is 1440 twips.”
• Alignment uses constants ALIGN_LEFT (0) / ALIGN_RIGHT (1) / ALIGN_FULL (2) / ALIGN_CENTER (3) / ALIGN_NOWRAP (4).
• Tabs are set on the paragraph style (SetTab, SetTabs, ClearAllTabs); a NotesRichTextTab is read-only — Position and Type (TAB_LEFT/TAB_RIGHT/TAB_DECIMAL/TAB_CENTER).
• NotesColorObject (session.CreateColorObject) converts between the Domino palette value (NotesColor, 0–240), RGB (0–255) and HSL (0–240). SetRGB / SetHSL snap to the closest Domino colour and return it.
• The catch: a NotesColorObject does not attach to rich text. You use it to derive a Domino colour value, then assign that to NotesRichTextStyle.NotesColor (the character style). Three different objects: paragraph style, character style, colour object.

The paragraph style

NotesRichTextParagraphStyle — “Represents rich text paragraph attributes” — is created from the session and carries the layout for a paragraph:

Dim session As New NotesSession
Dim rtps As NotesRichTextParagraphStyle
Set rtps = session.CreateRichTextParagraphStyle
rtps.Alignment = ALIGN_CENTER
rtps.LeftMargin = RULER_ONE_INCH          ' twips
rtps.RightMargin = RULER_ONE_INCH
rtps.SpacingAbove = SPACING_DOUBLE
rtps.SpacingBelow = SPACING_ONE_POINT_50

The properties you’ll use most: Alignment, LeftMargin / RightMargin / FirstLineLeftMargin, SpacingAbove / SpacingBelow / InterLineSpacing (with the SPACING_SINGLE / SPACING_ONE_POINT_50 / SPACING_DOUBLE constants), and Pagination (PAGINATE_BEFORE, PAGINATE_KEEP_WITH_NEXT, PAGINATE_KEEP_TOGETHER) for controlling page breaks. Margins are twips, so RULER_ONE_INCH * 0.75 is three-quarters of an inch.

Tabs

You don’t construct a NotesRichTextTab. You set tabs on the paragraph style and read them back through its read-only Tabs array:

' Three decimal tabs, first at 1 inch, 1 cm apart — figures align on the decimal point
Call rtps.SetTabs(3, RULER_ONE_INCH, RULER_ONE_CENTIMETER, TAB_DECIMAL)

' Or one tab at a time
Call rtps.SetTab(RULER_ONE_INCH * 2, TAB_RIGHT)

' Clear them all
' Call rtps.ClearAllTabs

Each resulting NotesRichTextTab exposes Position (twips) and Type (one of TAB_LEFT = 0, TAB_RIGHT = 1, TAB_DECIMAL = 2, TAB_CENTER = 3), both read-only — to change a tab you re-set the style’s tabs.

Colour — and the object that doesn’t colour anything

NotesColorObject (“Represents a color”) is colour maths. It holds a colour in three representations at once and converts between them:

Dim color As NotesColorObject
Set color = session.CreateColorObject
Dim dominoColor As Integer
dominoColor = color.SetRGB(0, 102, 204)   ' returns the closest Domino palette value

Its read-only Red / Green / Blue (0–255), Hue / Saturation / Luminance (0–240), and read-write NotesColor (the Domino palette value, 0–240) stay in sync — per the docs, “Setting NotesColor sets the RGB and HSL properties to values that correspond to the Domino color value.” Because the palette is only 0–240, SetRGB / SetHSL snap an arbitrary colour to the closest Domino colour, which is the value they return.

Here’s the trap: a NotesColorObject never attaches to a rich text item. Text colour is carried by NotesRichTextStyle (the character style). The colour object’s job is to give you the Domino value to assign there:

Dim richStyle As NotesRichTextStyle
Set richStyle = session.CreateRichTextStyle
richStyle.NotesColor = dominoColor        ' from SetRGB above; or a constant like COLOR_RED
richStyle.Bold = True

So three objects, three jobs: the paragraph style lays out the block, the character style carries colour/bold/font, and the colour object computes a palette value from arbitrary RGB. The colour object is only worth reaching for when you need a colour outside the named COLOR_* constants.

Putting it together

Sub Initialize
  Dim session As New NotesSession
  Dim db As NotesDatabase
  Set db = session.CurrentDatabase
  Dim doc As New NotesDocument(db)
  doc.Form = "Memo"

  ' Paragraph layout
  Dim rtps As NotesRichTextParagraphStyle
  Set rtps = session.CreateRichTextParagraphStyle
  rtps.Alignment = ALIGN_CENTER
  Call rtps.SetTabs(3, RULER_ONE_INCH, RULER_ONE_CENTIMETER, TAB_DECIMAL)

  ' Colour -> character style
  Dim color As NotesColorObject
  Set color = session.CreateColorObject
  Dim richStyle As NotesRichTextStyle
  Set richStyle = session.CreateRichTextStyle
  richStyle.NotesColor = color.SetRGB(0, 102, 204)
  richStyle.Bold = True

  ' Build the item: styles BEFORE text
  Dim rt As New NotesRichTextItem(doc, "Body")
  Call rt.AppendParagraphStyle(rtps)
  Call rt.AppendStyle(richStyle)
  Call rt.AppendText("Q1 Report")

  Call doc.Save(True, False)
End Sub

(Assembled from the official “working with text” examples; the combination of margins, tabs and a colour-object-derived colour in one routine is adapted.)

The order rule is the #1 pitfall: append the paragraph style and the character style before the text they apply to. Stamp them after and they govern nothing.

What about Java and SSJS?

The Java and SSJS surfaces mirror these — session.createRichTextParagraphStyle(), session.createColorObject(), the same twips and constants. The same “style before text” and “colour object feeds the character style” rules carry over unchanged.
