NotesRichTextDocLink & NotesRichTextSection: Doclinks and Collapsible Sections in Code

You’re assembling a notification email from an agent and you want it to contain a clickable link straight into the source document — not a URL, a real Notes doclink. Or you’re building a long report and want the appendix tucked into a collapsible section the reader can expand. Both are rich-text elements, and both are scriptable — but not the way you might expect.

Neither NotesRichTextDocLink nor NotesRichTextSection is a class you New. They’re read objects. You create the elements through NotesRichTextItem methods, and you get a class instance back only when you navigate existing rich text with NotesRichTextNavigator. That write-with-one-API, read-with-another split is the thing to understand first.

TL;DR

• Create a doclink with Call rtitem.AppendDocLink(target, comment$ [, hotspotText$]), where target is a NotesDatabase, NotesView, or NotesDocument.
• Create a section by bracketing content: rtitem.BeginSection(title$, …) → append text → rtitem.EndSection. You cannot wrap rich text that already exists.
• You only get a NotesRichTextDocLink / NotesRichTextSection object back by navigating with NotesRichTextNavigator and the element types RTELEM_TYPE_DOCLINK / RTELEM_TYPE_SECTION — to read, edit, or remove an existing one.
• Doclink properties are read-write: DbReplicaID, ViewUNID, DocUNID, HotSpotText, DisplayComment, ServerHint.
• AppendDocLink needs a default view set on the target database to resolve the link.
• Section: Title and IsExpanded are read-write; BarColor and TitleStyle are read-only (set them at BeginSection or via SetBarColor / SetTitleStyle). Note the naming mismatch — the property is IsExpanded, the BeginSection argument is expand.
• Both classes are new with Release 6.

Doclinks

The class is just “Represents a doclink in a rich text item” — a clickable hotspot that jumps to a database, view, or document. You don’t create it directly; you call AppendDocLink on the rich text item, and the target’s type decides what kind of link you get. Straight from the official examples:

Dim session As New NotesSession
Dim db As NotesDatabase
Dim newDoc As NotesDocument
Dim rtitem As NotesRichTextItem
Set db = session.CurrentDatabase
Set newDoc = New NotesDocument(db)
Set rtitem = New NotesRichTextItem(newDoc, "Body")

' Link to a database
Call rtitem.AppendDocLink(db, db.Title)

' Link to a view
Dim view As NotesView
Set view = db.GetView("Boots")
Call rtitem.AppendDocLink(view, view.Name & " in " & db.Title)

' Link to a document
Dim doc As NotesDocument
Set doc = view.GetFirstDocument
Call rtitem.AppendDocLink(doc, doc.Subject(0) & " in " & view.Name)

The second argument is the hover comment. There’s an optional third argument (Release 5+) for the visible boxed hotspot text — without it the link renders as a small token: Call rtitem.AppendDocLink(db, db.Title, "Open the database"). One caveat the AppendDocLink docs call out: “For this method to work you must set a default view in the database.”

To touch an existing doclink — change its target, retitle the hotspot, or remove it — you navigate to it. The class description spells out the route: “To access a NotesRichTextDocLink object, use the NotesRichTextNavigator methods in conjunction with the type RTELEM_TYPE_DOCLINK.” Then its read-write DbReplicaID / ViewUNID / DocUNID / HotSpotText / DisplayComment / ServerHint are yours to edit, and two removal methods differ in a useful way: Remove deletes the doclink entirely, while RemoveLinkage “Removes the doclink link from the rich text item while keeping hotspot text and formatting” — i.e. it de-links but leaves the words.

Collapsible sections

NotesRichTextSection — “Represents a collapsible section in a rich text item” — has the strictest creation rule of the two. You cannot enclose existing content; you must bracket new content as you append it:

Dim session As New NotesSession
Dim db As NotesDatabase
Set db = session.CurrentDatabase
Dim doc As New NotesDocument(db)
Dim rt As New NotesRichTextItem(doc, "Body")

Dim titleStyle As NotesRichTextStyle
Set titleStyle = session.CreateRichTextStyle
titleStyle.Bold = True

Dim bar As NotesColorObject
Set bar = session.CreateColorObject
bar.NotesColor = COLOR_BLUE

' Begin a collapsed section, append its content, then end it
Call rt.BeginSection("Appendix", titleStyle, bar, False)   ' expand = False -> collapsed
Call rt.AppendText("This content lives inside the collapsible section.")
Call rt.AddNewLine(1)
Call rt.EndSection

Call doc.Save(True, False)

(The doclink snippets above are verbatim from the official examples; this section snippet is adapted from the documented signatures — the official section example pages 404 under the 14.5.1 path.)

The docs are explicit about the rule: “You cannot create a section containing existing rich text. You must start the section with BeginSection, append rich text, and end the section with EndSection.” BeginSection’s parameters are title$, an optional title NotesRichTextStyle, an optional bar NotesColorObject, and expand (True = expanded, default False = collapsed). To read or modify an existing section you navigate with RTELEM_TYPE_SECTION; then Title and IsExpanded are read-write, and SetBarColor / SetTitleStyle adjust the look. Watch the naming: the property is IsExpanded, but the creation argument is expand.

One shared caveat

Both elements share the open-document quirk: if you edit the rich text of a document that’s currently open in the UI, the new doclink or section won’t render until the document is closed and reopened. For agent-generated documents that aren’t open this never bites, but it surprises people scripting against a NotesUIDocument.

What about Java and SSJS?

The same create-via-NotesRichTextItem, read-via-NotesRichTextNavigator split holds across all three languages — appendDocLink, beginSection / endSection, and the RTELEM_TYPE_* navigator types are the same. The classes are the read-side handles, not constructors, in every language.
