NotesMIMEEntity + NotesMIMEHeader: Parsing Email MIME Structure in LotusScript

Jun 4, 2026 250 words

Your agent needs to parse incoming mail — extract the HTML body, list attachments, or read a specific header like Reply-To or X-Mailer. You open the NotesDocument, call GetItemValue("Body"), and get empty or mangled text.

The problem: modern email is a nested MIME tree — HTML body, plain-text fallback, attachments, and inline images each live in separate nodes. Domino converts this tree to its proprietary rich-text format by default. To access raw MIME data, you have to tell Domino to stop converting, then walk the tree with NotesMIMEEntity.

TL;DR

ConvertMIME = False is a prerequisite — the default True causes MIME-to-rich-text conversion; GetMIMEEntity then returns Nothing
NotesMIMEEntity represents one node in the MIME tree; ContentType and ContentSubType identify what it contains
Navigation: GetFirstChildEntity descends into children; GetNextSibling moves across siblings
NotesMIMEHeader represents one header field (e.g. Content-Type, Content-Disposition)
Available since Release 5.0.2 — supported in all current versions
Set ConvertMIME back to True when done — leaving it False causes problems when saving documents

Getting the root MIME entity

Dim session As New NotesSession
Dim db As NotesDatabase
Set db = session.CurrentDatabase

' Critical: disable auto-conversion first
session.ConvertMIME = False

' Open a mail document
Dim doc As NotesDocument
Set doc = db.GetDocumentByUNID("...")

' Get the root MIME node
Dim mime As NotesMIMEEntity
Set mime = doc.GetMIMEEntity()

If mime Is Nothing Then
    Print "No MIME content (or ConvertMIME was still True)"
Else
    Print "Root Content-Type: " & mime.ContentType & "/" & mime.ContentSubType
End If

session.ConvertMIME = True  ' Restore

A document with the item $NoteHasNativeMIME = "1" contains native MIME content.

The structure of a MIME tree

A typical HTML email with an attachment looks like this:

multipart/mixed                ← root
├── multipart/alternative      ← child (HTML + plain-text alternative)
│   ├── text/plain             ← plain-text fallback
│   └── text/html              ← HTML body
└── application/pdf            ← attachment

Walk it with GetFirstChildEntity (descend) and GetNextSibling (across):

' Recursively walk the MIME tree
Sub WalkMIME(entity As NotesMIMEEntity, level As Integer)
    Dim indent As String
    indent = Space(level * 2)
    Print indent & entity.ContentType & "/" & entity.ContentSubType

    Dim child As NotesMIMEEntity
    Set child = entity.GetFirstChildEntity()
    Do Until child Is Nothing
        Call WalkMIME(child, level + 1)
        Set child = child.GetNextSibling()
    Loop
End Sub

' Call it
session.ConvertMIME = False
Dim mime As NotesMIMEEntity
Set mime = doc.GetMIMEEntity()
Call WalkMIME(mime, 0)
session.ConvertMIME = True

Extracting the body text

Once you find a text/html or text/plain node, GetContentAsText returns the decoded content:

Function GetHTMLBody(rootEntity As NotesMIMEEntity) As String
    If rootEntity.ContentType = "text" And rootEntity.ContentSubType = "html" Then
        GetHTMLBody = rootEntity.GetContentAsText()
        Exit Function
    End If
    ' Recurse into children
    Dim child As NotesMIMEEntity
    Set child = rootEntity.GetFirstChildEntity()
    Do Until child Is Nothing
        Dim result As String
        result = GetHTMLBody(child)
        If result <> "" Then
            GetHTMLBody = result
            Exit Function
        End If
        Set child = child.GetNextSibling()
    Loop
End Function

Identifying attachments

An attachment node has a Content-Disposition: attachment header:

Sub ListAttachments(entity As NotesMIMEEntity)
    Dim dispHeader As NotesMIMEHeader
    Set dispHeader = entity.GetNthHeader("Content-Disposition")
    If Not (dispHeader Is Nothing) Then
        If InStr(LCase(dispHeader.HeaderVal), "attachment") > 0 Then
            Print "Attachment: " & entity.ContentType & "/" & entity.ContentSubType
        End If
    End If
    ' Recurse
    Dim child As NotesMIMEEntity
    Set child = entity.GetFirstChildEntity()
    Do Until child Is Nothing
        Call ListAttachments(child)
        Set child = child.GetNextSibling()
    Loop
End Sub

Reading header values

Each node’s headers are accessible through NotesMIMEHeader objects:

' Get a specific header
Dim ctHeader As NotesMIMEHeader
Set ctHeader = mime.GetNthHeader("Content-Type")
If Not (ctHeader Is Nothing) Then
    Print "Content-Type: " & ctHeader.HeaderVal
    Print "  charset param: " & ctHeader.getParamVal("charset")
End If

' Get multiple headers as a single string
Dim someHeaders As String
someHeaders = mime.GetSomeHeaders("Content-Type, Content-Transfer-Encoding")
Print someHeaders

Commonly useful headers: Content-Type, Content-Disposition, Content-Transfer-Encoding, Content-ID (for inline images).

Building a MIME message from scratch with CreateMIMEEntity

The CreateMIMEEntity method on NotesDocument creates the root node:

session.ConvertMIME = False

Dim doc As NotesDocument
Set doc = db.CreateDocument()
doc.Form = "Memo"
doc.SendTo = "recipient@example.com"
doc.Subject = "MIME test message"

' Create the root node
Dim root As NotesMIMEEntity
Set root = doc.CreateMIMEEntity("Body")
root.ContentType = "multipart"
root.ContentSubType = "alternative"

' Add plain-text child
Dim textPart As NotesMIMEEntity
Set textPart = root.CreateChildEntity()
Call textPart.SetContentFromText("Plain text version", "text/plain;charset=UTF-8", ENC_NONE)

' Add HTML child
Dim htmlPart As NotesMIMEEntity
Set htmlPart = root.CreateChildEntity()
Call htmlPart.SetContentFromText("<p>This is the <b>HTML</b> version</p>", "text/html;charset=UTF-8", ENC_NONE)

Call doc.Save(True, False)
session.ConvertMIME = True

What about Java and SSJS?

Language	Counterpart
LotusScript	`NotesMIMEEntity` / `NotesMIMEHeader`
Java	`lotus.domino.MIMEEntity` / `MIMEHeader` (drop the `Notes` prefix; `.recycle()` when done)
SSJS	`MIMEEntity` / `MIMEHeader` (callable in XPages, same API surface)

Sources
