NotesLLMRequest: Call an LLM from LotusScript in 4 Lines

TL;DR

• Domino 14.5 introduced NotesLLMRequest / NotesLLMResponse — LotusScript sends a prompt to the server-side LLM and reads the response. The call goes through in-process IPC, so no HTTP latency.
• 4-line minimum: session.CreateLlmRequest() → Completion(serverName, commandName, userPrompt) → read .Content.
• The API design separates prompt from command — commandName references a Command document pre-built by the admin in dominoiq.nsf (containing the system prompt + model parameters); the app developer only supplies the user prompt.
• Defensive helpers: IsCommandAvailable(name) and GetAvailableCommands() for production sanity checks.
• Streaming mode: CompletionStream + CancelStream for long responses you want to surface incrementally in a UI.
• Prerequisite: Domino IQ enabled on the server + at least one Command document (architecture / installation in the earlier Domino IQ intro).

4-line minimum

Once the server has Domino IQ configured and a Command document, the entire call flow is:

Dim session As New NotesSession
Dim llmreq As NotesLLMRequest
Dim llmresp As NotesLLMResponse

Set llmreq = session.Createllmrequest()
Set llmresp = llmreq.Completion(db.server, "StdReplyEmail", "Customer said: 'How do I return this?'")
MsgBox llmresp.Content

Things to notice:

• Not New NotesLLMRequest() — use the session.Createllmrequest() factory method (same NotesSession factory pattern as CreateRichTextItem / CreateDateTime).
• db.server resolves to the current database’s server name; pass a different server name string to target a remote Domino IQ server.
• "StdReplyEmail" is one of the Commands shipped with Domino IQ — no need to create it yourself.
• Synchronous call — once Completion returns, llmresp.Content is ready.

The full NotesLLMRequest surface

Factory method:

Set llmreq = session.Createllmrequest()

NotesLLMRequest exposes five methods:

Completion(serverName, commandName, userPrompt) → NotesLLMResponse

Synchronous chat completion request to Domino IQ. All three parameters are strings:

CompletionStream(...) — streaming mode

Same semantics as Completion, but the response is delivered incrementally as it’s generated — useful for “typewriter effect” UIs or long responses you don’t want users staring at a spinner for.

CancelStream()

Aborts an in-progress CompletionStream (user clicked cancel, the UI was closed, etc.).

IsCommandAvailable(commandName) → Boolean

Checks whether the named Command document exists in the current server’s dominoiq.nsf. Essential for production — avoids the app blowing up if an admin renames or deletes a command.

If Not llmreq.IsCommandAvailable("MyCustomSummary") Then
    Print "Command missing — cannot proceed"
    Exit Sub
End If

GetAvailableCommands() → Variant array

Returns an array of all Command names available on the current server. Useful for: populating a UI dropdown where the user picks a command, or doing a startup sanity check.

Dim cmds As Variant
cmds = llmreq.GetAvailableCommands()
ForAll c In cmds
    Print c
End ForAll

NotesLLMResponse — three fields

The response object is flat — just three properties:

.Content As String

The LLM’s generated response text. 90% of use cases only need this.

.FinishReason As String

Why the LLM stopped generating. Common values (aligned with the OpenAI vocabulary):

Important: FinishReason = "length" means the response is incomplete — don’t treat it as a final answer. Production code should branch:

Select Case llmresp.FinishReason
Case "stop"
    ' OK, process normally
Case "length"
    Print "Warning: response truncated — bump Maximum tokens or split the prompt"
Case "content_filter"
    Print "Guard model blocked the response"
End Select

.Role As String

The role of the message — almost always "assistant" when returned by Completion. Different models may vary, but 90% of cases don’t touch this field.

Why the API takes commandName instead of a raw prompt

Seeing Completion(server, commandName, userPrompt) for the first time raises a question: why can’t the system prompt just live in LotusScript? Why must a Command document be pre-built on the server?

The design deliberately separates dev and admin concerns:

Concrete payoffs:

1. Tweak the prompt without changing code: an admin edits the system prompt in Notes client, the 5-minute cache expires, the new prompt is live — no app redeploy.
2. Multiple apps share a command: one “customer-reply” Command serves the mail, CRM, and ticketing apps.
3. Centralised governance: switching all LLM calls to a new model or enabling a guard model is a Command-document change, not an app code change.
4. Separate audit trails: dev changes to user prompt logic go through the app deployment pipeline; LLM behavior changes go through Domino DB document changes — different change-tracking flows.

Practical example 1: auto-reply agent

A scheduled agent that drafts LLM replies for the inbox and saves them as drafts:

Sub Initialize
    Dim session As New NotesSession
    Dim mailDb As NotesDatabase
    Dim docs As NotesDocumentCollection
    Dim doc As NotesDocument
    Dim llmreq As NotesLLMRequest
    Dim llmresp As NotesLLMResponse

    Set mailDb = session.CurrentDatabase
    Set llmreq = session.Createllmrequest()

    ' Production defense: bail if the command isn't there
    If Not llmreq.IsCommandAvailable("StdReplyEmail") Then
        Print "StdReplyEmail command not available on this server"
        Exit Sub
    End If

    ' Pull unprocessed inbox messages
    Set docs = mailDb.UnprocessedDocuments
    Set doc = docs.GetFirstDocument()

    Do Until doc Is Nothing
        Set llmresp = llmreq.Completion(mailDb.Server, "StdReplyEmail", doc.Body(0))

        If llmresp.FinishReason = "stop" Then
            doc.DraftReply = llmresp.Content
            Call doc.Save(True, False)
            Call session.UpdateProcessedDoc(doc)
        End If

        Set doc = docs.GetNextDocument(doc)
    Loop
End Sub

Practical example 2: conditional summarization

Summarize documents over 1000 characters; return the original otherwise:

Function SummarizeIfLong(doc As NotesDocument) As String
    Dim session As New NotesSession
    Dim llmreq As NotesLLMRequest
    Dim llmresp As NotesLLMResponse
    Dim bodyText As String

    bodyText = doc.GetItemValue("Body")(0)
    If Len(bodyText) < 1000 Then
        SummarizeIfLong = bodyText  ' Short enough — return as-is
        Exit Function
    End If

    Set llmreq = session.Createllmrequest()
    Set llmresp = llmreq.Completion( _
        doc.ParentDatabase.Server, _
        "StdSummarize", _
        bodyText _
    )

    Select Case llmresp.FinishReason
    Case "stop"
        SummarizeIfLong = llmresp.Content
    Case "length"
        ' Summary itself got truncated — safer to fall back to original
        SummarizeIfLong = bodyText
    Case Else
        SummarizeIfLong = bodyText
    End Select
End Function

"StdSummarize" is one of the built-in Commands. Or build your own in dominoiq.nsf — e.g. "MyCustomTechSummary" with a specific system prompt that makes the LLM summarize in technical-article voice.

CompletionStream: when it’s worth switching

Completion blocks until the full response is ready — simple, but a long prompt may take several seconds and the UI stalls.

CompletionStream delivers chunks as they’re generated, useful for:

• Web UIs that want a “typewriter” effect
• Long-form generation (let the user see the start early and cancel if it’s heading the wrong way)
• Backend streaming pipelines forwarding to another service

The cost: LotusScript’s callback model isn’t as ergonomic as JavaScript’s — you assemble your own buffer + handle partial UI updates. Complexity is meaningfully higher than Completion. For most backend agent scenarios, you don’t need streaming — Completion is plenty.

Relationship to other IQ articles

Community supplement: XPagesDeveloper’s “Quick LLM Access via 4 Lines of Code” is the cleanest demo of how compact this API really is.

What about Java and SSJS?

SSJS has no Domino IQ class. The standard workaround is to write an LS agent that does the IQ work and trigger it from SSJS via lotusScript:, or expose the call as a Domino REST API endpoint.
