NotesDXLImporter: Pushing DXL Back into Domino — Separate Strategies for Design, Documents, and ACL

The earlier NotesXMLProcessor piece introduced NotesDXLExporter — turning Domino design elements or documents into DXL (Domino XML). The natural reverse question: given a piece of DXL, how do you push it back into a database?

That’s the job of NotesDXLImporter. The official definition: “Represents the conversion of DXL (Domino XML) to Domino data.” It turns DXL back into Domino data — design elements, documents, ACL. Common uses: programmatically deploying design (pushing a few forms / views to several databases), restoring documents from backup DXL, or moving data between systems.

TL;DR

• Create with session.CreateDXLImporter(); the input is DXL (string / file / stream), and the output target database is set with SetOutput().
• Three key import strategies, each controlling one kind of content:
  • DesignImportOption — design elements: create / ignore / replace
  • DocumentImportOption — documents: create / ignore / replace / update
  • ACLImportOption — ACL entries: ignore / replace / update
• Import(dxl, db) runs the import; ImportedNoteCount returns how many notes came in; GetFirstImportedNoteID / GetNextImportedNoteID walk the results.
• Other controls: ReplaceDbProperties, ReplicaRequiredForReplaceOrUpdate, InputValidationOption (validate against a DTD), ExitOnFirstFatalError, Log / LogComment.
• Pairs with NotesDXLExporter — one exports, one imports, forming a full DXL round-trip.

Creating it and the basic flow

Dim session As New NotesSession
Dim importer As NotesDXLImporter
Set importer = session.CreateDXLImporter()

' set the import strategy (see below)
importer.DocumentImportOption = DXLIMPORTOPTION_CREATE

' run it: import dxl into targetDb
Call importer.Import(dxlString, targetDb)
Print "Imported " & importer.ImportedNoteCount & " notes"

The dxl source can be a string, file, or stream; targetDb is the NotesDatabase to import into.

The three keys: Design / Document / ACL ImportOption

The thing to think through before importing is “what happens when it meets something that already exists.” A piece of DXL can contain design, documents, and ACL all at once, and each has its own strategy property:

Some practical calls:

• Deploying design: usually DesignImportOption = replace (overwrite the old design), documents mostly ignore (don’t touch user data), ACL often ignore (don’t overwrite the target database’s permissions).
• Restoring / importing documents: DocumentImportOption = create (all new) or update (update existing documents by UNID). The difference between update and replace is that update matches existing documents — and there ReplicaRequiredForReplaceOrUpdate decides “whether a matching replica ID is required” before updating, which matters when importing across non-replica databases.

The classic disaster from a wrong strategy is “I only meant to update documents, but it also overwrote the target database’s design or ACL.” Before importing, be clear about what’s in the DXL and what each of the three options is set to.

Retrieving results and debugging

• ImportedNoteCount — how many notes were imported.
• GetFirstImportedNoteID() / GetNextImportedNoteID(noteid) — walk the note IDs of what was just imported, for follow-up processing or verification.
• InputValidationOption — if the XML declares a DTD, validate the input format against it.
• ExitOnFirstFatalError — stop on the first fatal error, or keep going.
• Log / LogComment — record the import process, which you’ll want for batch deployments.

Paired with DXLExporter: a full round-trip

NotesDXLImporter and NotesDXLExporter are a mirror pair:

Domino data  --(DXLExporter)-->  DXL (XML)  --(DXLImporter)-->  Domino data

That round-trip underpins many “manage Domino design / data as text files” approaches — export design to DXL into source control, then import it back to deploy when needed. It’s also the underlying mechanism for source-control-for-Domino and automated-deployment DevOps pipelines.

What about Java and SSJS?

Consistent across all three: the same three import options, importDxl() / setDocumentImportOption() and so on. To build a Domino automated-deployment tool, the Java DxlImporter plus the strategy judgment in this article transfers directly.
