NotesAgent: Calling One Agent from Another (Run vs RunOnServer)

You have a heavy batch agent — one run takes several minutes. Now the requirement shifts: when a user clicks a button on a form, it should fire that agent “right now”; or another agent, partway through, needs to hand work off to it. The point is — you don’t want to wait for a schedule, you want to trigger it from code.

That’s what NotesAgent is for. The official definition is “Represents an agent” — it stands for an agent design element in a database, lets you inspect its settings, and lets you run it from code. And “run it” has two methods: Run and RunOnServer — pick wrong and your code runs on the wrong machine, or does nothing useful. This article makes that decision clear.

TL;DR

• Get a NotesAgent with db.GetAgent("agentName"), or all of them with db.Agents
• Run executes the agent in the current (client) context; RunOnServer executes it on the server hosting the database
• Both return an Integer status — 0 means success — and both take an optional noteID$
• noteID$ is passed to the called agent’s ParameterDocID property — the standard way to say “act on this document”
• Properties expose the agent’s settings: IsEnabled (read-write), Trigger, Target, LastRun, ServerName, IsWebAgent / IsNotesAgent, Owner
• Four constraints: no recursive self-call, no debugging the called agent, no direct user interaction, output goes to the Domino log

Getting an agent

Agents belong to a database, so you get one from NotesDatabase:

Dim session As New NotesSession
Dim db As NotesDatabase
Set db = session.CurrentDatabase

Dim agent As NotesAgent
Set agent = db.GetAgent("DailyCleanup")
If agent Is Nothing Then
    ' No agent by that name in this db
    Exit Sub
End If

To list every agent in a database, use db.Agents (returns an array). Note the docs’ warning about Name: “Within a database, the name of an agent may not be unique” — there can be more than one agent with the same name, and GetAgent returns one of them.

Run vs RunOnServer: the decision that matters

Both methods “run the agent”, but which machine they run on is completely different:

Why does the choice matter? Picture that “several minutes” batch agent: with Run, it executes on the user’s Notes Client and the user is frozen waiting for it; with RunOnServer, the work goes to the server and the client gets control back immediately. Heavy work should be RunOnServer.

One exception to remember, verbatim: “On a local database, the RunOnServer method works like the Run method, that is, runs the agent on the local computer.” If the database is local, RunOnServer degrades into Run and runs locally — no server, nowhere to “offload” to.

Both methods “run any agent regardless of source language (simple action, formula, LotusScript, Java)” — the called agent can be written in anything.

Passing a document to the called agent

The optional noteID$ parameter of Run / RunOnServer, per the docs: “The note ID of a document. This value is passed to the ParameterDocID property of the called agent.”

In other words, it’s the standard channel for the caller to tell the callee “act on this document”:

' Caller: pass a document's NoteID
Call agent.RunOnServer(doc.NoteID)

' Inside the called agent: fetch the document from its own ParameterDocID
Dim session As New NotesSession
Dim db As NotesDatabase
Dim doc As NotesDocument
Set db = session.CurrentDatabase
Set doc = db.GetDocumentByID(session.CurrentAgent.ParameterDocID)

The called agent reads its own ParameterDocID (docs: “the note ID of a document passed to the agent by Run or RunOnServer”, read-only, new in Release 5.02), then uses GetDocumentByID to retrieve the document. Far cleaner than a global scratch field.

Knowing the agent: common properties

You don’t just run it — you can inspect its settings (most read-only):

IsEnabled being writable is genuinely useful — disable a scheduled agent in code during maintenance and re-enable it afterward, writing the change back with Save().

A few constraints

Calling agents isn’t unlimited; the docs list some hard rules:

• No recursion: “You cannot run an agent recursively (cannot call it from itself).”
• No debugging: “You cannot debug a called agent.” One fired via Run / RunOnServer won’t enter the debugger.
• No user interaction: “The user cannot interact directly with a called agent.” Don’t put dialogs in a called agent — nobody can click them.
• Output goes to the log: “User output goes to the Domino log.” Print and the like land in the Domino log, not in front of the user. To record a called agent’s progress, the NotesLog class covered earlier is the more controllable route.

What about Java and SSJS?

NotesAgent exists in all three languages, with the same name:

The run / runOnServer and ParameterDocID concepts are consistent across all three. Triggering a back-end agent from an XPages button with SSJS is a very common pattern, and it runs through this same runOnServer — offloading heavy work back to the server, exactly the logic in this article.
