When DQL Says "Domino Query execution error": A Diagnostic Ladder

Your DQL query fails and the screen shows Domino Query 執行時錯誤: — “Domino Query execution error:” — trailed by several lines of text. It’s tempting to grab the error number and search for it. Don’t: the 4854 you’ll find in LotusScript’s Err is the least useful thing here. This is a field report on reading that message the way it actually wants to be read — and the short version is that the whole diagnosis lives in one specific line, not in the error code. (Environment: Domino 12.0.2, a 412-document test database; the reproduction assets — 5 views and 4 agents — are in the knowledge-base case.)

TL;DR

• The number is a dead end. Every DQL execution failure returns Err = 4854 (lsERR_NOTES_DQUERY_EXECUTION) — syntax errors, empty queries, missing views, all of it. The constants 4852/4853/4855/4856 exist but aren’t used in practice. Diagnose from the message text (Error$), never the number.
• The message has four segments: the Domino Query execution error: prefix, ① an engine-classification line, ② a detailed-reason line (this is the one that matters), ③ an echo of your query, ④ a Call hint.
• A three-rung ladder on line ②: ...needs to be cataloged via updall -e (missing catalog or a typo in a view/column name — check spelling first) → View never built [x] (the view’s index was never created; DQL won’t build it) → Partial TIMEDATEs NOT supported... (a date-only @dt).
• Intermittent behaviour (“works sometimes”) is often a half-corrupt design catalog — after a view design change, updall -d can fail and leave the catalog inconsistent, so some views error while others silently return 0. Rebuild with updall -e.
• Your error handler must print Error$ in full — the number tells you nothing.

Read the message, not the number

The single most important reproduction finding: in LotusScript, a DQL failure always surfaces as Err = 4854. We threw everything at it — a syntax error (... and and ...), an empty query string, a nonexistent view — and every one came back 4854. The constant is lsERR_NOTES_DQUERY_EXECUTION, defined in lsxbeerr.lss; its siblings 4852/4853/4855/4856 are defined too, but in practice you never see them. So the number classifies nothing. Whatever went wrong, the description is in the text:

On Error GoTo errh
' ... run the DQL query ...
Exit Sub
errh:
  Print "DQL failed: " & Error$      ' the WHOLE text — this is your diagnosis
  Print "  (Err = " & Err & ")"      ' always 4854; ignore it
End Sub

Miss the Error$ and you’ve thrown away the only useful information.

The four segments

The message is structured. Reading it in order tells you where to look:

1. Prefix — Domino Query 執行時錯誤: / “Domino Query execution error:”. Just the wrapper.
2. ① Engine classification — a broad category, e.g. Query is not understandable (syntax) or Error validating view column name.
3. ② Detailed reason — the diagnostic key. This is the line you act on.
4. ③ Query echo — your query text played back. For syntax errors it’s followed by a caret-pointer line, .....^....., marking the exact offending character.
5. ④ Call hint — the internal API point where it failed.

For a syntax error, ① plus the ③ caret line pinpoint the character. For everything else, ② is the whole story.

The three-rung ladder (line ②)

Match the detailed-reason line against these, top to bottom:

The first rung’s dual meaning is the trap: the same message appears whether the catalog is genuinely missing or you simply mistyped a view or column name. Check the name before you run updall. On the design catalog itself, the docs are clear about why it exists — “for high speed access to internal information about views and view columns, DQL processing uses a design catalog that contains design data extracted from view notes” — and what happens without one: “all other syntax will function but there will be no view access and all terms will be satisfied utilizing NSF scanning.” You create it with load updall <db> -e and update it after design changes with load updall <db> -d.

When it “works sometimes”: a half-corrupt catalog

The intermittent version is the most confusing, and the field report pinned the usual culprit. The design catalog is persistent state stored inside the NSF (the mechanics are covered in the DQL production notes). After you sync view design changes, a updall -d refresh can fail — in the test it threw DesignCatalog::LoadColumnData ... Named Object corrupt — and leave the catalog in a half-corrupt state. The symptom of that half state is exactly “works sometimes”: some views error, others silently return 0 documents, with no consistency. The recovery is a full updall -e rebuild (the corruption persists across server restarts, so restarting doesn’t help).

In code, prefer the refresh/rebuild pattern over a manual runbook — the same approach the production notes use:

' Cheap when the catalog is current:
query.RefreshDesignCatalog = True
' ... run the query ...
' If it fails with "needs to be cataloged via updall -e", retry harder:
query.RebuildDesignCatalog = True
' ... re-run ...

One limit: RefreshDesignCatalog can’t bootstrap a catalog that doesn’t exist yet in a fresh NSF — that first build needs RebuildDesignCatalog (or updall -e).

”Zero documents, no error”: a five-step checklist

The failure mode with no message is its own problem — the query runs clean and returns nothing. Walk these in order:

1. Does the data even exist? Run a non-view comparison query (or a plain search) that doesn’t touch the view, to confirm matching documents are actually there.
2. Is the view index fresh? Set RefreshViews = True on the query so a stale index isn’t hiding new documents.
3. Is the catalog stale or half-corrupt? See the section above — this is the “works sometimes” cause.
4. Is the selection formula filtering them out? If the view’s selection isn’t @All, excluded documents aren’t in the view to find (the @All pitfalls piece covers this).
5. Is it a type or time-zone mismatch? A wrong query-term type or a @dt missing its +08:00 returns 0 (or the wrong rows) silently — the whole subject of the date-column piece.

Reading Explain output

When you need to know why a query is slow or which node matched what, Explain (or RunQuery with explain) prints a plan. The fields worth knowing:

• ScannedDocs — 0 means the query ran purely on the index (no full-database scan); a high number is your performance red flag.
• Entries / FoundDocs — index entries examined at a node, and documents that matched there.
• estimated cost — the optimiser’s cost estimate that drives execution order; it’s an estimate, not a measured time (the Prep/Exec msecs are the real wall-clock).
• A @dt('...+08:00') term shows up in the plan normalised to UTC (e.g. 2023-12-31T16:00:00Z) — that’s expected, not a bug.

What about Java and SSJS?

The engine and its messages are identical across languages — the four-segment text, the three-rung ladder, and the catalog behaviour are all engine-level. The only difference is packaging: LotusScript flattens every failure to Err = 4854 (so you read Error$), while Java surfaces a NotesException whose message carries the same detailed-reason line. In every case, the diagnosis is in the text.
