Domino 14.5 Mandated Port Encryption Hands-On — CheckPortEncryption Agent, portenc Commands, and Recovery Paths

Recap

Yesterday’s concept piece covered what the ? icon means after a 14.5 upgrade, why Mandated NRPC Port Encryption exists, and the three enablement modes (off / logging-monitor / mandate-enforce). This post walks the HCL “Enabling mandated NRPC port encryption” guide step by step with ini names, commands, and the gotchas to watch for.

Prerequisites

• Primary administration server must run 14.5 or later — other servers in the domain can still be pre-14.5 (the CheckPortEncryption agent handles those, more on that below)
• A plan to upgrade the server address book design to 14.5 (step 1)
• Agreement on the two-stage adoption (logging first, then enforce — never skip straight to enforce)

The 10-step procedure

1. Upgrade the server address book design to 14.5

Foundational — the new “Mandated Port Encryption” section in the Directory Profile only shows up on the 14.5 design.

2. Sign and enable the CheckPortEncryption scheduled agent

The 14.5 server address book ships a new scheduled agent called CheckPortEncryption. The admin must:

• Sign it with an ID that’s allowed to run unrestricted agents
• Enable the agent
• Confirm the server document’s Agents section permits unrestricted runs by that signer

The agent runs daily across every server in the domain, with different behavior depending on server version:

Put differently, this agent is a transition-period helper — it lets pre-14.5 servers participate in the directory-profile mandate setting. Once every server is on 14.5+, the agent retires.

3. Build an exclusion group (optional)

Servers that shouldn’t be subject to the mandate can be grouped and added to the Directory Profile’s exclusion list. Passthru servers and the ADPWSync utility server are auto-excluded — no manual step needed for those.

4. Build a 14.5+ server group (optional)

Either create a server group of 14.5+ servers or use * - [All Servers]. Skip this if you’re managing per-server ini files manually.

5. Set server ini values (one-time restart needed)

Via a server configuration document’s Notes.ini section:

These changes require a server restart.

6. Set Desktop policy (for clients)

On the client side, use desktop policy → Custom Settings → Notes.ini tab:

These are the “opt out of the mandate” knobs — set to 0 means “stay opted in, comply with the mandate.” Keeping these two entries in desktop policy matters — if a client breaks badly after enforcement, flipping the policy to 1 remotely lets that client opt out without anyone visiting the workstation.

7. Enable logging (enter the monitor window)

Edit the Directory Profile → Security tab → enable logging for mandated port encryption, but do not enforce yet.

The server-view icon for affected servers transitions from ? to a “status evaluating” icon at this point.

8. Run portenc refresh

On the primary admin server console:

portenc refresh

That refreshes every server’s mandate-setting cache and runs a compliance pass. To verify:

portenc show

Shows the current state for each server.

9. Observe for several days

During the logging window, watch the debug log entries (from the ini settings in step 5) for connections that would be dropped under enforcement. Typical things you’ll catch:

• A legacy server with R9 clients that don’t accept encryption → logged, but the connection still goes through (because enforcement isn’t on yet)
• A misconfigured partition → unexpected plaintext connections appear in the log

Resolve those before stepping into enforcement.

10. Enable enforcement

Once the logging window passes without surprises, edit the Directory Profile setting to Enforce port encryption mandate and run portenc refresh again.

The server-view icon switches to the “enforced” state. From this moment on, NRPC connections that won’t accept encryption get refused.

Recovery paths

If enforcement breaks something (a critical client can’t connect, a partner server suddenly fails clustering):

Prepare the recovery path before the upgrade and write it into your runbook. Looking up docs the day enforcement breaks is not a fun place to be.

Frequently overlooked details

• If the CheckPortEncryption agent isn’t signed, the whole mechanism silently does nothing — there’s no error. Admin enables logging, runs refresh, but the server-view icons don’t move. The first debug step for “I followed the steps but nothing happened” is to check this agent’s signing
• MANDATEDENC_ACTIVE_REFRESH_TIME defaults to 24 hours, which is long — drop it to ~300 seconds during the monitor window if you want faster iteration
• For pre-14.5 servers, the change vector is ini, not the server configuration doc — the agent writes PORT_ENC_ADV directly into notes.ini

Closing

The actual setup isn’t complicated, but there are a lot of steps — miss any one of the 10 (especially the agent signing in step 2) and you end up with “looks enabled, doesn’t work” for ambiguous reasons. Recommendations:

1. Write a runbook that captures all 10 steps, every ini name, every command, and the recovery paths
2. Plan a logging window of at least one week so weekly cron jobs and monthly batch processes all run before enforcement
3. Pre-stage the recovery levers — DISABLE_MANDATED_ENCRYPTION=1 over desktop policy is the fastest emergency valve on the client side

Read this alongside the 5/10 NotesHTTPRequest trust-store change — that piece covers the trust store moving for outbound HTTPS, this one covers internal NRPC encryption being enforced. Both ship in 14.5 and both want attention.
