DXL in Java: Exporting and Importing Domino Data with DxlExporter / DxlImporter

You need to move a set of design elements from a test DB to production, or snapshot a batch of documents as XML to diff, back up, or feed another system — DXL (Domino XML) is the XML representation of Domino data and design, and in Java the two workhorses for going in and out are DxlExporter and DxlImporter.

Going out is simple; coming back is where the thought goes — import isn’t just “load the XML.” You have to tell it how design, documents, and ACL are each handled: create, replace, update, or ignore. Get the policy wrong and things either don’t land, or overwrite what they shouldn’t.

This piece covers both classes and the import options that decide success.

TL;DR

• DxlExporter (Domino → DXL): create with session.createDxlExporter(); exportDxl(...) takes a Database / Document / DocumentCollection / NoteCollection and returns a DXL String.
• DxlImporter (DXL → Domino): create with session.createDxlImporter(); importDxl(...) takes a String / Stream / RichTextItem and writes into a target Database; walk the imported notes with getFirstImportedNoteID / getNextImportedNoteID (the latter takes the current note ID).
• Import is policy-driven: setDesignImportOption (create/ignore/replace), setDocumentImportOption (create/ignore/replace/update), setAclImportOption (ignore/replace/update), setReplaceDbProperties, setReplicaRequiredForReplaceOrUpdate.
• recycle the exporter/importer and the backend objects along the way, per the Java recycle discipline.
• Round-trip has traps: out-and-back isn’t guaranteed identical — see the DXL round-trip pitfalls piece.

DxlExporter: Domino → DXL

The official Exporting and importing DXL is direct: “Use the createDxlExporter method in Session to create a DxlExporter object. Use the exportDxl method to perform the export. Input to exportDxl can be a Database, Document, DocumentCollection, or NoteCollection object. Output is a String object.”

DxlExporter exporter = session.createDxlExporter();
String dxl = exporter.exportDxl(doc);      // or a Database / DocumentCollection / NoteCollection
// …write dxl to a file, diff it, ship it…
exporter.recycle();

To control the output, the exporter has a set of options (whether to emit a DOCTYPE, how rich text is handled). Defaults are usually fine; reach for the exporter’s setters when you need exact formatting.

DxlImporter: DXL → Domino

Official: “Use the createDxlImporter method in Session to create a DxlImporter object. Input to DxlImporter can be a String, Stream, or NotesRichTextItem object. Output is to a Database object.” After importing, “You can access these note IDs using the getFirstImportedNoteId and getNextImportedNoteId methods.”

DxlImporter importer = session.createDxlImporter();
importer.setDocumentImportOption(DxlImporter.DXLIMPORTOPTION_CREATE);
importer.importDxl(dxl, targetDb);          // writes into targetDb

String noteId = importer.getFirstImportedNoteID();
while (noteId != null) {
    // …handle each newly imported note…
    noteId = importer.getNextImportedNoteID(noteId);   // pass the current note ID to get the next
}
importer.recycle();

Import is policy-driven: three ImportOptions

This is the step to think through. The target DB may already hold the same things, so you decide “what happens when it’s already there.” The official DxlImporter options:

A few practical notes:

• Think about the replica condition before replace/update: setReplicaRequiredForReplaceOrUpdate decides “must the DXL’s replica ID match the target’s.” When you move design across databases that aren’t replicas, this setting determines whether replace/update can happen at all.
• update vs replace for documents differ: update merges into the existing one; replace swaps it out — moving data vs overwriting it gives very different results.
• Don’t drag ACL in by accident: importing DXL that contains ACL with setAclImportOption unset can change the target’s permissions — usually not what you want when you’re just moving design.

recycle and round-trips

DxlExporter / DxlImporter are backend objects too — recycle() when done, per the Java recycle piece. And DXL “out and back” isn’t guaranteed byte-identical (some elements, rich text, and attachments have quirks) — the site’s DXL round-trip pitfalls covers that, worth reading before you move production data.

What about LotusScript and SSJS?

• LotusScript: the counterparts are NotesDXLExporter / NotesDXLImporter, with nearly the same shape (CreateDXLExporter / CreateDXLImporter, Export / Import, the same import options) — the site’s NotesDXLImporter (LS) piece covers the LS side. This one is the Java form.
• SSJS: you can reach the same classes through the Java API, but DXL in and out is more typically done in an agent / background job (Java or LS) than in front-end SSJS.
