How Domino Web Login and Multi-Server SSO Work

Oct 23, 2026 1,201 words

A user logs into Domino in a browser and then clicks around — opening different databases — without logging in again. Why? Because Domino uses session-based authentication: on a successful login the server issues a token and puts it in a cookie, and the browser carries that cookie on every request, so the server recognizes “who you are and that you’re still logged in.” And when you have several Domino servers and want a user to log into one and reach the others (SSO), the token behind that needs a shared secret.

TL;DR

Basic vs session: basic authentication is the browser’s built-in HTTP prompt, resending the credentials on every request; session-based authentication uses a login form + a cookie — after login the server puts a token in a cookie and recognizes you by it (so the browser must accept cookies).
Single vs multi-server: a Single Server cookie is valid only for that one server; Multiple Servers (SSO) lets a user “log in once” and then reach other enabled servers in the same DNS domain without logging in again.
The Web SSO Configuration document: a domain-wide Domino Directory document that must replicate to every participating server, holding a shared secret key the servers use to verify user credentials (the LTPA token).
What makes SSO fail: participating servers must be in the same DNS domain, whose value must start with a period (e.g. .example.com); URLs must use the full DNS name (not a host name or IP), because the cookie’s DNS domain must match the server URL and cookies can’t cross TCP/IP domains; the participating list can hold only Domino servers (no groups/wildcards); and all SSO servers must use the same Internet-access method (all Internet Site documents, or all Server document).
One big trap: enabling Internet Sites in the Server document automatically disables an existing SSO configuration — directly related to the previous piece on Internet Site documents.
Sharing LTPA with WebSphere: once you import WebSphere’s LTPA key, you can’t set an SSO idle timeout (WebSphere ignores idle timeouts); the LTPA realm must match on all participating servers; SSO across Domino domains means importing the same WebSphere LTPA token into each domain.

Basic vs session-based authentication

Domino web name-and-password authentication comes in two forms:

Basic authentication: HCL describes it as a “challenge/response protocol” that asks the user for a name and password. In HTTP Basic’s standard behavior that’s the browser’s built-in auth prompt, and once entered the browser resends the credentials on every request; there’s no clean “log out” and no timeout.
Session-based authentication: a login form instead. On a successful login, the server generates a token and sends it to the browser in a cookie (HCL: “the authentication token that is generated by the server is sent to the browser in a cookie”), and the browser keeps the session via that cookie. Because the auth state lives in the cookie, the browser must accept cookies — and you get timeouts and a real logout.

The session authentication field on the Web Site document (or Server document) is where you pick among these modes: Disabled / Single Server / Multiple Servers (SSO) (official: setting up session authentication for Web Site documents).

Single-server cookies vs multi-server SSO

Single Server: the cookie is valid only on the server that issued it. Move to another Domino server and the user logs in again.
Multiple Servers (SSO): this is single sign-on. HCL says it lets a web user “log in once to a Domino or WebSphere server” and then reach other enabled servers in the same DNS domain without logging in again.

SSO works because the token isn’t something each server just makes up on its own — it’s signed with a secret key shared across the servers, so server B can verify a token issued by server A and recognize the user.

The Web SSO Configuration document: the shared secret

The core of multi-server SSO is a Web SSO Configuration document (official: creating a Web SSO configuration document):

It’s a domain-wide document in the Domino Directory.
It must replicate to every participating server — each needs the same copy to have the same key.
It “contains a shared secret key used by servers for verifying user credentials” — that shared secret key (the LTPA token key) is the root of trust between the servers.
A domain can technically hold more than one such document (each needs a unique name), but HCL notes this only works “under limited circumstances.”

What makes SSO fail

SSO that’s configured but keeps re-prompting usually hits one of these (official: multi-server SSO):

The DNS domain must match and start with a period: participating servers must be in the same DNS domain, and the value must look like .example.com — starting with a period.
URLs must use the full DNS name: not a host name or IP — because the cookie’s DNS domain must match the server URL, and a cookie can’t be used across TCP/IP domains.
The participating list can hold only Domino servers: no groups, wildcards, or WebSphere server names.
All SSO servers must use the same Internet-access method: all on Internet Site documents, or all on the Server document — no mixing.

One big trap: enabling Internet Sites disables SSO

This one is easy to hit and its symptom is confusing: when you enable Internet Sites in the Server document, an existing SSO configuration is automatically disabled (HCL: “any existing SSO configuration is automatically disabled”).

So if you follow the previous piece and switch a server to Internet Sites, the SSO that was hanging off the Server document no longer counts — you have to reconfigure SSO on the Internet Sites side (the Web Site document’s session authentication). When “everyone has to log in again” right after you switch to Internet Sites, this is almost always why.

To share one login across Domino and WebSphere (or across Domino domains), you use the LTPA token — but know the limits first:

WebSphere can’t directly use a Domino-generated LTPA token; the approach is to export the token from WebSphere and import it into Domino, sharing one LTPA group.
Once you import WebSphere’s LTPA key, you can’t set an SSO idle timeout — WebSphere ignores idle timeouts, so the option disappears.
The LTPA realm must be identical on all participating servers.
For SSO across multiple Domino domains, have each domain use the same key information (concretely, import the same WebSphere LTPA token into each domain).

Wrap-up

Basic vs session: basic = HTTP prompt resending credentials each request; session = login form + cookie carrying a token (must accept cookies).
Single vs multi: a Single Server cookie is only for that server; Multiple Servers (SSO) means log in once, reach the whole DNS domain.
Web SSO Configuration: domain-wide, replicated to every participating server, holding the shared secret key (LTPA) that verifies credentials.
Hard conditions: same DNS domain (starting with a period), URLs use the FQDN, cookies don’t cross TCP/IP domains, only Domino servers listed, all SSO servers on the same Internet-access method.
Big trap: enabling Internet Sites in the Server document disables existing SSO → reconfigure it on the Web Site side.
WebSphere/LTPA: importing WebSphere keys removes the idle-timeout option; the LTPA realm must match; cross-domain means the same token imported into each domain.
