NotesXMLProcessor: The Common Base for LotusScript XML Handling

What NotesXMLProcessor actually is

NotesXMLProcessor is “a base class containing properties and methods common to all XML processing classes.” The key thing — and the thing the docs put bluntly up front — is that it is abstract: “The NotesXMLProcessor class is abstract and you do not create NotesXMLProcessor objects.” To use it at all, you go through one of the NotesSession.Create* methods to instantiate a derived class.

Version and platform: introduced in Release 6; not supported in COM (LotusScript works, COM automation does not).

The five derived classes — picking the right one

Quick decision rule:

• Touching Domino design or data → DXLExporter / DXLImporter.
• Parsing third-party XML → DOMParser (small files, random access) or SAXParser (large files, streaming).
• Reshaping DXL into another XML dialect → XSLTransformer.

Inherited properties

• ExitOnFirstFatalError (read-write Boolean) — stop on the first fatal error.
• Log (read-only String) — the warnings, errors, and fatal errors raised during processing, as XML.
• LogComment (read-write String) — a comment prepended to the log so you can identify the run later.

Log being XML rather than plain text is intentional — if you need to act on errors programmatically, parse it with a DOMParser.

Inherited methods

• SetInput — specifies the input. Accepted types depend on the derived class: DXLExporter takes NotesDatabase / NotesDocumentCollection / NotesDocument; DOMParser / SAXParser take NotesStream or a file-path string; DXLImporter takes DXL strings or a NotesStream.
• SetOutput — specifies the destination (again, varies — typically a NotesStream or a file-path string).
• Process — runs the conversion or parse. Synchronous: the call returns when processing finishes.

Example: export the whole database to DXL

The most common starting case is using NotesDXLExporter to dump the current database to a DXL file:

Sub Initialize
    Dim session As New NotesSession
    Dim db As NotesDatabase
    Set db = session.CurrentDatabase

    ' Open a NotesStream as the output sink
    Dim stream As NotesStream
    Set stream = session.CreateStream
    Dim filename As String
    filename = "C:\dxl\" & Left(db.FileName, Len(db.FileName) - 3) & "xml"
    If Not stream.Open(filename) Then
        Messagebox "Cannot open " & filename, , "Error"
        Exit Sub
    End If
    Call stream.Truncate

    ' Create the DXL exporter (NotesXMLProcessor is abstract — go through a derived class)
    Dim exporter As NotesDXLExporter
    Set exporter = session.CreateDXLExporter

    ' Wire input and output
    Call exporter.SetInput(db)
    Call exporter.SetOutput(stream)

    ' Stop on fatal errors; tag the log so we can find this run later
    exporter.ExitOnFirstFatalError = True
    exporter.LogComment = "Exported by " & session.UserName

    ' Actually run it
    Call exporter.Process

    ' Surface any warnings / errors
    If Len(exporter.Log) > 0 Then
        Print "DXL export log:"
        Print exporter.Log
    End If

    Call stream.Close
    Messagebox "DXL export complete."
End Sub

Things worth noting in this snippet:

1. NotesXMLProcessor is never New’d directly — you always go through session.CreateXxx.
2. SetInput / SetOutput on their own do nothing — you must call Process to actually run.
3. Process is synchronous — for a big database, the Sub blocks until it finishes.
4. Log is XML, not plain text — feed it through a DOMParser if you want to act on errors programmatically.

Common pairings worth knowing

Typical NSF XML workflows:

• Backup / version-control of NSF design: DXLExporter → file, then track in git.
• Deploying DXL into NSFs: DXLImporter ← from a trusted source, with ACL pre-verified.
• Parsing third-party XML: DOMParser (< 10 MB) or SAXParser (larger).
• DXL → another XML dialect: DXLExporter → DXL → XSLTransformer with an XSLT → target format.

Summary

NotesXMLProcessor itself is unusable — the value is in the contract it defines: every derived class shares the same SetInput / SetOutput / Process triplet and the same Log mechanism. In real code, the work is just picking the right derived class and wiring up the I/O.
