A Practical Guide to LotusScript NotesStream: Files Done Right

What NotesStream actually is

NotesStream is the LotusScript abstraction for reading and writing a file from inside a Notes/Domino agent or script library. You construct one through NotesSession.CreateStream, point it at a file with Open, and then read or write — either as text (with an optional charset) or as raw bytes.

It is not a generic “fopen with a mode flag.” There is no "r", "w", or "a". The closest thing to a write mode is the explicit Truncate call described later.

Creating and opening a stream

CreateStream takes no arguments and returns a fresh, empty stream:

Dim session As New NotesSession
Dim s As NotesStream
Set s = session.CreateStream

Open has exactly two parameters — and the second one is charset, not a mode:

If Not s.Open("C:\reports\sales.txt", "UTF-8") Then
    Error 1, "Cannot open file"
End If

The signature is flag = notesStream.Open(pathname$ [, charset$]). charset$ is optional and defaults to "System". Valid values include ASCII, UTF-8, UTF-16, Big5, Shift_JIS, and the special "Binary" for byte-only streams. If the file does not exist, Open creates it. The full charset list is on the NotesStream.Open method reference.

Open returns False when the path is invalid, the stream is already open, the stream already has buffered content, or the charset is unrecognised.

Reading: text vs bytes

There are two read methods, and they are not interchangeable:

ReadText reads the whole stream (up to 2 GB) by default, but you can pass STMREAD_LINE to read one line at a time. Read is capped at 65 535 bytes per call — for larger binary files, loop and accumulate until IsEOS is True.

Writing text

Set s = session.CreateStream
If Not s.Open("C:\out.txt", "UTF-8") Then Error 1, "open failed"
Call s.Truncate
Call s.WriteText("Hello, Domino", EOL_CRLF)
Call s.Close

Two things worth noticing:

1. Truncate is how you get “write-from-scratch” semantics. Per the NotesStream.Truncate reference, it deletes the stream contents and resets Bytes to 0, Position to 0, and IsEOS to True. Call it after Open when you want to overwrite an existing file.
2. WriteText quietly writes a BOM when the charset is Unicode / UTF-16 / UTF-16BE / UTF-16LE and the stream is empty at the moment of the write. The Bytes property reported afterwards explicitly excludes that BOM.

WriteText(text$, [eol&]) accepts up to 2 GB per call. eol& controls the line terminator: EOL_CRLF (default), EOL_CR, EOL_LF, EOL_LFCR, or EOL_NONE.

Writing binary

For binary I/O, Write takes a Variant byte array — capped at 65 535 bytes per call:

Dim s As NotesStream
Dim buf(0 To 3) As Byte
buf(0) = 72   ' H
buf(1) = 101  ' e
buf(2) = 108  ' l
buf(3) = 108  ' l

Set s = session.CreateStream
If Not s.Open("C:\out.bin", "Binary") Then Error 1, "open failed"
Call s.Truncate
Call s.Write(buf)
Call s.Close

The "Binary" charset tells the stream to treat the file as raw bytes with no encoding translation. Write returns the number of bytes written as a Long.

Position and IsEOS

Position is a read/write Long — the byte offset from the start of the stream. Set it to 0 to rewind, or to any value beyond the size to jump straight to end-of-stream. Reads consume from the current Position; writes always update Position to end-of-stream regardless of where you set it.

IsEOS becomes True after Truncate, after any Write / WriteText, or when reading has consumed everything. It is the canonical “are we done?” check inside a read loop.

Documented caveat: setting Position to a non-zero value has no special handling for multi-byte characters — you can land mid-character.

Three gotchas the docs spell out

1. Closing a zero-byte stream deletes the file

Per the NotesStream class reference, “Closing a stream with zero bytes deletes the associated file.” If you Open + Truncate + Close without writing anything, the file is gone.

2. Read / Write are capped at 65 535 bytes per call

For larger binary payloads, loop on Read(length&) until IsEOS, or chunk your Write calls.

3. Open is not idempotent

Open fails if the stream is already open or if it still has buffered content. Call Close first when you want to reuse a stream object for a different file.

Closing well

The reference says streams close implicitly at end of scope, but always call Close explicitly. It releases the file lock, flushes pending state, and — combined with the zero-byte rule above — makes the file lifecycle predictable instead of “whenever LotusScript decides to clean up.”
