NotesRichTextItem: writing rich text fields from LotusScript

A premise the docs put up front: it inherits from NotesItem

The documentation opens with:

NotesRichTextItem inherits from NotesItem. Because NotesRichTextItem inherits from NotesItem, all of the NotesItem properties and methods can be used on a NotesRichTextItem, too.

So everything on NotesItem (Name, Type, Text, Values, Remove(), etc.) is already on a NotesRichTextItem. This post only covers what NotesRichTextItem adds on top.

It defines exactly one of its own properties — EmbeddedObjects (read-only): every embedded file, OLE object, and object link inside the rich-text item.

The interesting surface is the 22 methods.

Two ways to construct one

A — From the document

Set rt = doc.CreateRichTextItem("Body")

Body is the field name. If a same-named field already exists on the document, the existing one is returned.

B — New directly

Dim rt As New NotesRichTextItem(doc, "Body")
' or
Set rt = New NotesRichTextItem(doc, "Body")

Same effect; pick whichever reads better. CreateRichTextItem is the right call from OLE automation contexts (no New available).

22 methods in five buckets

1. Append text (the workhorse)

2. Style and paragraph format

3. Tables, sections, doclinks

4. Embedded files / objects

EmbedObject’s type% uses these built-in constants:

EMBED_ATTACHMENT  = 1454   ' file attachment
EMBED_OBJECT      = 1453   ' OLE object
EMBED_OBJECTLINK  = 1452   ' OLE object link

5. Navigator / Range / read / housekeeping

A practical example: a reply email with an attachment

Sub SendReplyWithAttachment(targetMail As String, attachPath As String)
    Dim s As New NotesSession
    Dim db As NotesDatabase
    Dim doc As NotesDocument
    Dim body As NotesRichTextItem
    Dim style As NotesRichTextStyle

    Set db = s.GetDatabase("", "mail.box")
    Set doc = db.CreateDocument()
    doc.Form = "Memo"
    doc.SendTo = targetMail
    doc.Subject = "Monthly report attached"

    ' Build the rich-text body
    Set body = doc.CreateRichTextItem("Body")

    ' Plain prose
    Call body.AppendText("Hi,")
    Call body.AddNewLine(2)
    Call body.AppendText("Attached is this month's sales report. Please review.")
    Call body.AddNewLine(2)

    ' Switch to bold red
    Set style = s.CreateRichTextStyle()
    style.Bold = True
    style.NotesColor = COLOR_RED
    Call body.AppendStyle(style)
    Call body.AppendText("Note: please confirm by Friday whether further analysis is needed.")

    ' Attach the file
    Call body.EmbedObject(EMBED_ATTACHMENT, "", attachPath)

    ' Send
    Call doc.Send(False)
End Sub

Four things this snippet gets right:

1. CreateRichTextItem("Body") — Body is the rich-text field a Memo form expects
2. Every AppendText after AppendStyle inherits that style until the next AppendStyle
3. EmbedObject uses the named constants (EMBED_ATTACHMENT etc.) — clearer than the raw integers
4. doc.Send(False) calls Update for you; no manual body.Update() needed

Three gotchas worth knowing

Gotcha 1: Save before EmbedObject?

The docs don’t require it. But if you embed a large attachment (>several MB) into a brand-new in-memory document, you may hit memory pressure. In that case, call doc.Save(True, False) once before the embed.

Gotcha 2: GetFormattedText vs GetUnformattedText

Both return plain text, but:

• GetFormattedText(False, 80, 0) keeps line breaks, wraps at 80 chars — good for an email-quote view
• GetUnformattedText() flattens everything to one whitespace-collapsed string — what you want for InStr matching or full-text comparison

Picking the wrong one will give your search logic surprising false negatives.

Gotcha 3: rich text isn’t readable from @Formula

@GetField("Body")     ' returns "" rather than the rich-text content
@Text(Body)           ' same — no good

Use @Abstract([TextOnly];0;"";"Body") from formula, or GetUnformattedText() from LotusScript.

Companion classes worth knowing

NotesRichTextItem is the entry point for the entire Notes “write content into a document” API chain — formatting, tables, attachments all hang off it.
