Getting Started with NotesQueryResultsProcessor: Life After DQL

Apr 28, 2026 517 words

Why NQRP exists

DQL gives you a SQL-like syntax to find documents, but it returns a plain NotesDocumentCollection — there is no built-in way to sort, categorise, project columns, or serialise to JSON. If you also want to:

Sort the results on a field (DQL itself does not guarantee order)
Group results into categories
Apply @Formula to compute or normalise field values
Stream the results out as JSON for a frontend or REST endpoint
Materialise the results as a temporary view that users can browse

…you traditionally had to write the loop yourself or build a dedicated view. NotesQueryResultsProcessor (NQRP), introduced in Domino V12, packages all of those post-processing steps into a single fluent API.

Create an NQRP instance

NQRP comes from NotesDatabase.CreateQueryResultsProcessor():

Dim s As New NotesSession
Dim db As NotesDatabase
Set db = s.GetDatabase("myserver", "mydb.nsf")

Dim qrp As NotesQueryResultsProcessor
Set qrp = db.CreateQueryResultsProcessor()

The pattern from there on is always add inputs → define columns → execute.

Add inputs: three sources

1. `AddCollection` — an existing document collection

Dim view As NotesView
Set view = db.GetView("Customers")
Dim col As NotesDocumentCollection
Set col = db.UnprocessedDocuments  ' or view.GetAllDocumentsByKey(...) etc.
Call qrp.AddCollection(col)

Accepts either NotesDocumentCollection or NotesViewEntryCollection.

2. `AddDominoQuery` — feed DQL straight in

Dim dq As NotesDominoQuery
Set dq = db.CreateDominoQuery()
Call qrp.AddDominoQuery(dq, "Form = 'Order' and Total > 10000", "")

NQRP runs the DQL internally and adds the resulting documents to its input set.

3. `AddFormula` — override input field values

When the source documents need a computed or normalised field:

Call qrp.AddFormula("@LowerCase(CustomerName)", "CustomerName", "*")

The third parameter "*" applies the formula to all input collections; passing a specific collection name limits it to that one.

Define output columns: `AddColumn`

Call qrp.AddColumn(String Name, _
                   Optional String Title, _
                   Optional String Formula, _
                   Optional Integer SortOrder, _
                   Optional Boolean Hidden, _
                   Optional Boolean Categorized)

Parameter	Purpose
`Name`	Programmatic name of the column (must be unique)
`Title`	Display header when materialised as a view
`Formula`	Default `@Formula` for the value (omit to read the field of the same name)
`SortOrder`	`SORT_UNORDERED` / `SORT_ASCENDING` / `SORT_DESCENDING`
`Hidden`	true = sort by this column but do not return it
`Categorized`	true = collapse rows with the same value into one entry

Official example:

Set qrp = db.CreateQueryResultsProcessor()
Call qrp.AddColumn("sales_person", "", "", SORT_ASCENDING, False, True)
Call qrp.AddColumn("ordno",        "", "", SORT_DESCENDING, False, False)
Call qrp.AddColumn("order_origin", "", "", SORT_UNORDERED, False, False)
Call qrp.AddColumn("partno")

That defines four columns: categorise by sales_person ascending → within each category sort by ordno descending → display order_origin and partno.

Execute: two output formats

A. `ExecuteToJSON` — for APIs and front-ends

Dim json As NotesJSONNavigator
Set json = qrp.ExecuteToJSON()

Returns a NotesJSONNavigator. The output conforms to RFC 8259 and lives under StreamResults:

{
  "StreamResults": [
    {
      "@nid": "NT0000A572",
      "@DbPath": "dev\\ordwrkqrp.nsf",
      "sales_person": "Alice",
      "ordno": "PO-1042",
      "order_origin": "Web",
      "partno": "X-99"
    }
  ]
}

Special keys:

@nid — document NoteID
@DbPath — source database path
documents — child rows under a categorised entry
Multi-value fields are emitted as JSON arrays
Aggregate functions (@@sum(), @@avg(), @@count()) appear as dedicated keys

B. `ExecuteToView` — materialise as a browsable temp view

Set myview = qrp.ExecuteToView(ByVal Name As String, _
                               Optional ByVal ExpireHours As Long, _
                               Optional Readers As Variant, _
                               Optional DesignSrcDB As NotesDatabase, _
                               Optional ByVal DesignSrcViewName As String) As NotesView

Parameter	Purpose
`Name`	Name of the results view to create
`ExpireHours`	Hours before the view auto-expires (default 24)
`Readers`	Single name or array of names (canonical) controlling who can read it
`DesignSrcDB` / `DesignSrcViewName`	Use an existing view as the design template

Official example, verbatim:

Dim theReaders(1 To 4) As String
theReaders(1) = "CN=User1 UserLN1/O=MYORG"
theReaders(2) = "CN=User2 UserLN2/O=MYORG"
theReaders(3) = "PrivilegedGroup"
theReaders(4) = "CN=User3 UserLN3/O=MYORG"

Dim s As New NotesSession
Dim db As NotesDatabase
Dim qrp As NotesQueryResultsProcessor
Dim myview As NotesView
Set db = s.GetDatabase("myserver", "mydb.nsf")
Set qrp = db.CreateQueryResultsProcessor()
Set myview = qrp.ExecuteToView("MyNewResultsView", 2, theReaders)

The view is auto-cleaned up by the server, so the NSF design does not bloat over time.

Safety knobs: don’t let a query run forever

qrp.MaxEntries = 50000      ' max input documents; throws if exceeded
qrp.TimeOutSec = 30         ' max execution seconds; throws if exceeded

Public-facing endpoints should always set both, otherwise a malicious or accidental query can exhaust the server.

The Java side

The Java class is lotus.domino.QueryResultsProcessor. Naming maps 1:1 from LotusScript: drop the Notes prefix, switch to camelCase, and keep JSON upper-case in method names:

LotusScript	Java
`db.CreateQueryResultsProcessor()`	`db.createQueryResultsProcessor()`
`qrp.AddCollection(col)`	`qrp.addCollection(col)`
`qrp.AddDominoQuery(dq, q, "")`	`qrp.addDominoQuery(dq, q, "")`
`qrp.AddColumn(...)`	`qrp.addColumn(...)`
`qrp.ExecuteToJSON()`	`qrp.executeToJSON()`
`qrp.ExecuteToView(name, ...)`	`qrp.executeToView(name, ...)`
`qrp.MaxEntries = 50000`	`qrp.setMaxEntries(50000)`
`qrp.TimeOutSec = 30`	`qrp.setTimeoutSec(30)`

The Java end-to-end equivalent:

import lotus.domino.*;

Session session = NotesFactory.createSession();
Database db = session.getDatabase("", "orders.nsf");

QueryResultsProcessor qrp = db.createQueryResultsProcessor();
qrp.setMaxEntries(10000);
qrp.setTimeoutSec(20);

DominoQuery dq = db.createDominoQuery();
qrp.addDominoQuery(dq,
    "Form = 'Order' and OrderDate >= @dt('2026-01-01')", "");

qrp.addColumn("region",  "",          "", QueryResultsProcessor.SORT_ASCENDING,  false, true);
qrp.addColumn("total",   "Total NTD", "", QueryResultsProcessor.SORT_DESCENDING, false, false);
qrp.addColumn("orderNo", "Order No",  "", QueryResultsProcessor.SORT_UNORDERED,  false, false);

JSONNavigator json = qrp.executeToJSON();
// walk the JSONNavigator API ...

qrp.recycle();   // like every lotus.domino.Base, recycle when done

recycle() is the standard lotus.domino.Base discipline: native handles need to be released explicitly so the JVM doesn’t hold onto them longer than necessary.

End-to-end: DQL + sort + JSON (LotusScript)

Sub TopOrdersToJSON
  Dim s As New NotesSession
  Dim db As NotesDatabase
  Set db = s.GetDatabase("", "orders.nsf")

  Dim qrp As NotesQueryResultsProcessor
  Set qrp = db.CreateQueryResultsProcessor()
  qrp.MaxEntries = 10000
  qrp.TimeOutSec = 20

  Dim dq As NotesDominoQuery
  Set dq = db.CreateDominoQuery()
  Call qrp.AddDominoQuery(dq, _
    "Form = 'Order' and OrderDate >= @dt('2026-01-01')", "")

  Call qrp.AddColumn("region",  "",          "", SORT_ASCENDING,  False, True)
  Call qrp.AddColumn("total",   "Total NTD", "", SORT_DESCENDING, False, False)
  Call qrp.AddColumn("orderNo", "Order No",  "", SORT_UNORDERED,  False, False)

  Dim json As NotesJSONNavigator
  Set json = qrp.ExecuteToJSON()
  ' walk the tree with the NotesJSONNavigator API
End Sub

When to reach for NQRP — and when not

Need	Pick
Single document by key	`view.GetDocumentByKey()`
Full-text keyword search	`db.FTSearch()`
Structured condition query	DQL (`NotesDominoQuery`)
DQL results that also need sort / category / projection / JSON	NQRP
REST endpoint with categorised output	NQRP + ExecuteToJSON
Temporary browsable result table for users	NQRP + ExecuteToView

NQRP has been stable since V12 and is a key building block for “Domino-as-API” backends, REST API services, and reporting batch jobs.
