NotesNoteCollection: the Swiss-army tool for NSF design elements

What NotesNoteCollection is

NotesNoteCollection is the LotusScript class for batch-operating on “notes”.

A “note” is the NSF’s internal storage unit — anything that gets a Note ID: data documents, forms, views, folders, agents, ACLs, profile documents, style sheets. Every one of those is a note.

So this class covers a wide surface, controlled by per-class flags:

• Data: data documents
• Design elements: forms, views, folders, pages, subforms, shared fields
• Code: agents, script libraries, Java resources, action bars, the database script
• Resources: image resources, style sheets
• Security / config: ACL, profile documents, replication formulas
• Misc: design indices, format elements, code elements

Its sweet spot:

“I need to batch-process some class of note in the NSF — audit every agent, DXL-export the entire design for version control, harvest every note modified in the last week.”

If you already know NotesDocumentCollection: these are different tools. NotesDocumentCollection only deals with data documents; NotesNoteCollection handles everything at the note level. There’s a full side-by-side comparison after the worked examples below.

Construction: CreateNoteCollection(Boolean)

Obtained from NotesDatabase:

Set nc = db.CreateNoteCollection(False)

That boolean controls the initial state of every Select* property:

• True → every Select* starts as True (start with everything, then turn off what you don’t want)
• False → every Select* starts as False (start with nothing, then turn on what you want)

False is more common in practice — you usually know which class of element you need, so you start empty and switch on the relevant flags.

32 properties — pick what you want

The full list documented in the source:

Lifecycle / general

27 Select* flags (one per note class)

Each is a Boolean. To grab every agent and every view:

Set nc = db.CreateNoteCollection(False)
nc.SelectAgents = True
nc.SelectViews = True
Call nc.BuildCollection()

14 methods — three groups

Lifecycle

Set operations

Bulk presets

Iteration

The documentation does not define GetLastNoteID, GetPrevNoteID, Merge, Subtract, or GetUNID — verify against the official docs when writing code.

Worked example 1: audit every agent in a database

Sub AuditAgents(db As NotesDatabase)
    Dim nc As NotesNoteCollection
    Dim noteID As String
    Dim doc As NotesDocument

    Set nc = db.CreateNoteCollection(False)
    nc.SelectAgents = True
    Call nc.BuildCollection()

    Print "Found " & nc.Count & " agent(s)"

    noteID = nc.GetFirstNoteID()
    Do Until noteID = ""
        Set doc = db.GetDocumentByID(noteID)
        Print doc.GetItemValue("$TITLE")(0) & _
              " | LastModified: " & doc.LastModified
        noteID = nc.GetNextNoteID(noteID)
    Loop
End Sub

Four things this snippet gets right:

1. CreateNoteCollection(False) — start empty, turn on only what you need
2. nc.SelectAgents = True — agents only
3. BuildCollection() — mandatory; the collection is empty without it
4. GetFirstNoteID / GetNextNoteID return Note ID strings, not NotesDocument objects — you fetch the document yourself with db.GetDocumentByID()

Worked example 2: list every view name (two ways compared)

A common real-world need: “get me a list of every view name in this database”. NotesNoteCollection can do it, but there’s a much shorter path:

' Method A: NotesNoteCollection
Set nc = db.CreateNoteCollection(False)
nc.SelectViews = True
Call nc.BuildCollection()

noteID = nc.GetFirstNoteID()
Do Until noteID = ""
    Set doc = db.GetDocumentByID(noteID)
    Print doc.GetItemValue("$TITLE")(0)   ' $TITLE is "Name|Alias|Alias"
    noteID = nc.GetNextNoteID(noteID)
Loop

' Method B: db.Views
ForAll v In db.Views
    Print v.Name      ' v.Name is the resolved primary name
    ' v.Aliases is the alias array
End ForAll

Trade-offs:

Picking the right one:

• “Just give me the view names” → db.Views. Three lines, done.
• “Mixed types, time/condition filtering, or DXL export pipeline” → NotesNoteCollection.

One subtle point: db.Views includes folders (a folder is a specialised view). To strictly exclude folders, filter with view.IsFolder, or use Method A with SelectViews=True only — folders have their own SelectFolders flag.

Worked example 3: pulling data documents (you can, but you usually shouldn’t)

NotesNoteCollection can harvest data documents — just turn on SelectDocuments:

Set nc = db.CreateNoteCollection(False)
nc.SelectDocuments = True       ' data documents only
Call nc.BuildCollection()

noteID = nc.GetFirstNoteID()
Do Until noteID = ""
    Set doc = db.GetDocumentByID(noteID)
    Print doc.UniversalID & " | Form=" & doc.Form(0)
    noteID = nc.GetNextNoteID(noteID)
Loop

Or use the bulk preset nc.SelectAllDataNotes(True) to flip every data-related flag at once.

But — this isn’t usually how you reach for data. Each standard idiom has a shorter path:

Where NotesNoteCollection actually beats them for data

There are three situations where it wins:

1. Mixed harvest: data + design in one pass — e.g. “every note modified in the last 7 days, including views and agents” for an audit or backup

   Call nc.SelectAllNotes(True)
   nc.SinceTime = New NotesDateTime(Now - 7)
   Call nc.BuildCollection()

2. Feeding NotesDXLExporter — when you want data plus design exported together for version control
3. Note IDs instead of NotesDocument objects — writing tooling or audit logs that just need the IDs

One subtlety

SelectDocuments = True does not include:

• Deletion stubs
• Conflict documents are handled slightly differently from NotesDocumentCollection

If you’re doing a “complete database audit” you’ll need to handle those edge cases separately.

The most common real use: DXL export

In practice, the dominant use case for NotesNoteCollection is feeding NotesDXLExporter:

Sub ExportAllDesignToDXL(db As NotesDatabase, outputPath As String)
    Dim nc As NotesNoteCollection
    Dim exporter As NotesDXLExporter
    Dim s As New NotesSession
    Dim stream As NotesStream

    ' 1. Collect every design element (no data documents)
    Set nc = db.CreateNoteCollection(False)
    Call nc.SelectAllDesignElements(True)
    Call nc.BuildCollection()

    ' 2. Open the output file
    Set stream = s.CreateStream()
    Call stream.Open(outputPath, "UTF-8")

    ' 3. Run the DXL exporter on the entire collection
    Set exporter = s.CreateDXLExporter()
    Call exporter.SetInput(nc)
    Call exporter.SetOutput(stream)
    Call exporter.Process()

    Call stream.Close()
    Print "Export complete: " & outputPath
End Sub

This is the “templating tool” pattern — exporting an entire template database’s design as XML for version control, cross-environment deployment, or backup. NotesNoteCollection + NotesDXLExporter is the canonical path.

Advanced: full side-by-side with NotesDocumentCollection

If you already know NotesDocumentCollection, this table maps the differences at a glance:

When not to use NotesNoteCollection

• Plain batch ops on data documents → NotesDocumentCollection or DQL (NotesDominoQuery)
• Walking a view with entry-level metadata → NotesViewNavigator
• Just need a list of design elements → NotesDatabase.GetView() / GetForm() / GetAgent() are simpler

The sweet spot is “I need to batch-process notes at the design level”. For that scenario, there’s no better tool.
