Domino V12 lets notes.ini hold multiple HTTPAdditionalRespHeader entries

Why this matters

Domino shops typically configure security HTTP headers (HSTS, CSP, X-Frame-Options, etc.) using one of two models:

1. Internet Site documents + Web Site Rules — UI-driven, per-site policies. Custom HTTP headers go in a Web Site Rule document.
2. Server document only (no Internet Sites enabled) + notes.ini — simpler, server-wide. Custom headers can only be set via HTTPAdditionalRespHeader in notes.ini.

For shops on model 2, notes.ini is the only place to put security headers — not a fallback, just the day-to-day config surface. For shops on model 1, notes.ini is also the firefighting path when the HTTP task won’t start and the admin client can’t get in.

Both situations hit the same historical limit: HTTPAdditionalRespHeader has been around since 9.0.1 FP6, but only ever supported one header. A second HTTPAdditionalRespHeader=... line silently overwrote the first (notes.ini’s last-write-wins behaviour), so you had to pick one security control (X-Frame-Options OR CSP, never both) and ship with the rest exposed.

HCL removed that cap in Domino V12.0.x with a small naming convention.

The old (single) syntax

HTTPAdditionalRespHeader=X-Frame-Options: SAMEORIGIN

A second HTTPAdditionalRespHeader=... line overwrites the first, so in practice you got exactly one header. Layering HSTS, CSP, and X-Frame-Options at the same time through notes.ini was simply not possible.

The new (multiple) syntax

The first header keeps the original name (no number). Every additional header uses a two-digit suffix starting at 01:

HTTPAdditionalRespHeader=X-Frame-Options: SAMEORIGIN
HTTPAdditionalRespHeader01=X-XSS-Protection: 1; mode=block
HTTPAdditionalRespHeader02=Content-Security-Policy: default-src 'self'
HTTPAdditionalRespHeader03=Strict-Transport-Security: max-age=31536000; includeSubDomains
HTTPAdditionalRespHeader04=X-Content-Type-Options: nosniff

Things to know:

• The suffix is two digits starting at 01, not 1 — HTTPAdditionalRespHeader1 is ignored
• Order in the file doesn’t change runtime behaviour (Domino reads all of them), but consecutive numbering keeps the file readable
• Run tell http restart (or restart the server) before the changes take effect
• Available in HCL Domino 12.0.x and later — older releases are still capped at one

A minimum-viable security-header baseline

If your server currently has no security headers, dropping these five lines into notes.ini covers most of what SSL Labs / Mozilla Observatory grade you on:

HTTPAdditionalRespHeader=Strict-Transport-Security: max-age=31536000; includeSubDomains
HTTPAdditionalRespHeader01=X-Frame-Options: SAMEORIGIN
HTTPAdditionalRespHeader02=X-Content-Type-Options: nosniff
HTTPAdditionalRespHeader03=Referrer-Policy: strict-origin-when-cross-origin
HTTPAdditionalRespHeader04=Content-Security-Policy: default-src 'self'; img-src 'self' data: https:; style-src 'self' 'unsafe-inline'

The CSP line will almost certainly need tuning for your application — unsafe-inline is technically wrong, but Notes-style web apps lean heavily on inline styles, so start loose enough that nothing breaks, then tighten it. For HSTS, max-age=31536000 is one year — the first time you enable it, ship with something small (say 300 for five minutes) until you’ve confirmed every endpoint really is HTTPS-clean, then bump it up.

Choosing between the two models

If your environment has Internet Sites enabled, Web Site Rules tend to be the better long-term home for custom headers:

• Per-site policies (*.example.com can differ from api.example.com)
• Edit history is preserved (who changed what, when)
• Changes pick up on tell http refresh instead of tell http restart — refresh keeps user sessions alive and doesn’t blow away the in-memory caches

If your environment only uses the Server document and never enabled Internet Sites, notes.ini was always your only option. The V12 multi-header support is a real feature unlock for you, not a “fallback patch”.

Note that tell http refresh and tell http restart cover different scopes:

• tell http refresh reloads only Web Site documents (and the rules / file protection / authentication realms attached to them)
• tell http restart reloads the Server document, notes.ini, HTTPD.CNF, servlets — everything else

So changes to HTTPAdditionalRespHeader in notes.ini always require tell http restart (or a full server restart) to take effect.
