DQL Production-Ready: Catalog Maintenance, Permissions, and sessionAsSigner

📚 The “DQL Trilogy” series

• Part 1: DQL in Practice: SQL-Looking Syntax, Notes-Specific Traps Everywhere
• Part 2: DQL Pitfalls: 6 Query-Writing Details the Official Docs Don’t Spell Out
• Part 3: DQL Production-Ready (you are here)

Once you can write working DQL queries, shipping them to production brings two more challenges that the official docs are vague about:

1. How the Design Catalog gets maintained automatically — bootstrapping brand-new NSFs, incremental refresh after design changes, and why an in-memory cache is overengineering
2. Permissions — why regular users hit “You don’t have permission to perform this operation”, how to use sessionAsSigner, and why a Java helper doesn’t carry signer identity by itself

This article verifies each conclusion against real Domino 12 production logs, and ends with a production-ready Java helper class you can drop into your project.

If you don’t have the basics yet, start with Part 1 DQL Getting Started; if your queries return wrong results or hit weird error messages, see Part 2 Pitfalls first.

Why the Design Catalog matters

DQL needs to know which views exist in each NSF, what they’re called, and what columns each view exposes — that “design index” is the Design Catalog. Bottom line up front:

As soon as your query mentions a view name (the single-quoted form), you need the Design Catalog — because that catalog is DQL’s only way to know what view names exist and what columns each view exposes. Without it, DQL can’t tell what 'Customers' even refers to.

The classic trap: a developer adds a view called Vtest and tries to scope a query to it using the documented syntax:

in ('Vtest') and Form = 'Ftest'

You get this error:

Domino Query execution error: Unexpected internal error - validation error
Error opening view name or named document set - [Vtest] does not exist or open failed
(Call hint: NSFCalls::NSFDbGetNamedObjectID, Core call #0)

The message reads as “the view doesn’t exist”, but the view is right there in Designer and opens fine. The real cause is that this NSF’s Design Catalog hasn’t been built yet, or hasn’t been refreshed since the design change.

Two server-console commands to know

<db-path> is relative to Domino\Data, e.g. apps\crm.nsf.

The big warning: relying on console-only is an SOP landmine

This is the part that bites everyone. The scenario:

1. You ran load updall apps\crm.nsf -e once and DQL works fine
2. A developer adds a new view named Vtest in Designer
3. You run in ('Vtest') → boom, does not exist or open failed
4. You spend an hour debugging before remembering: you never ran load updall apps\crm.nsf -d

Leaning on an admin to remember load updall -d is rarely workable: there are too many NSFs, deploys are frequent, and the developer pushing the design change usually doesn’t have server-console access. Pushing catalog sync onto the admin team is just burying the landmine in the handoff.

The next section solves this from app code.

Version note: where the catalog lives

• Domino 10.x: the Design Catalog is a standalone file GQFdsgn.cat, sitting next to the NSF in the data directory
• Domino 11+: the Design Catalog moved inside the NSF as hidden design elements (not visible in Designer by default). No .cat files appear at the filesystem level anymore, but the load updall -e / -d workflow is identical

After upgrading an older NSF to 11+, you still need to run load updall <db-path> -e once to populate the catalog inside the NSF.

Advanced: explicitly mark fields as DQL-usable

If you have specific fields you want DQL to use as query conditions through a view index, add this to the view’s selection formula:

SELECT @IsAvailable($DQLField)

That view then becomes a candidate index source for DQL — the query planner will prefer it over a full NSF scan.

Sync the catalog from app code (recommended)

NotesDominoQuery exposes two properties to trigger catalog sync from app code:

Three field-tested facts (Domino 12.x)

Fact 1: The Catalog is NSF-persistent state (Domino 11+)

The catalog lives inside the NSF as hidden design elements — not in-memory state. It survives server restart, HTTP task restart, JVM restart. An NSF only needs its catalog built once; after that it persists permanently (unless the NSF itself is deleted and recreated).

Field log (first round of queries after a server restart — every NSF returns successfully with no harvest activity):

03:23:35  HTTP JVM: DB [dorm] 找到 1 筆
03:23:35  HTTP JVM: DB [docdb] 找到 6 筆
... (12 NSFs all succeed, zero harvest log lines)

Fact 2: RefreshDesignCatalog = True is a ~0ms no-op when the catalog is already current

HCL checks internally whether the catalog needs updating before doing real harvest work. When nothing’s changed, the console gets no harvested message and the cost is essentially zero — so you can safely turn it on for every query.

Field log (every query carries setRefreshDesignCatalog(true), no design changes):

04:06:40  HTTP JVM: DB [dorm] 找到 3 筆
04:06:40  HTTP JVM: DB [law] 找到 14 筆
... (12 NSFs, zero harvest log lines, all near-instant)

Fact 3: RefreshDesignCatalog automatically does an incremental harvest on stale catalogs

When the design has just changed, the next query carrying Refresh detects it and updates the catalog automatically — no manual reset, no in-memory cache, no scheduled agent.

Field log (after editing the design of LAW and EForm):

04:07:59  CTI\LAW\LCM_Ext2.nsf harvested, ... 278.534 msecs
04:07:59  HTTP JVM: DB [law] 找到 14 筆
04:08:00  CTI\EForm.nsf harvested, ... 468.698 msecs
04:08:00  HTTP JVM: DB [EForm] 找到 4 筆

Exception: Refresh cannot bootstrap a brand-new NSF

For an NSF that’s never been catalogued, RefreshDesignCatalog = True fails; you must use RebuildDesignCatalog = True for the first build. The HCL doc on updall -d says “If the catalog doesn’t already exist, updall automatically creates it” — but the API behaves differently from the console command. Refresh does not auto-bootstrap.

Field log (a freshly added workorder.nsf that’s never been catalogued):

04:06:27  HTTP JVM: DQL: catalog 缺失於 [CTI\Safety\workorder.nsf] — 執行 Rebuild 後重試
04:06:28  CTI\Safety\workorder.nsf harvested, ... 963.684 msecs
04:06:28  HTTP JVM: DB [workorder] 找到 0 筆

When the catalog is missing, DQL surfaces this marker phrase in the error: needs to be cataloged via updall -e.

Final pattern: always Refresh + catch Rebuild

Combining the three facts and the one exception, the recommended pattern is:

' LotusScript
Function RunDql(db As NotesDatabase, query As String) As NotesDocumentCollection
    Dim dq As NotesDominoQuery

    ' Phase 1: Refresh + execute (current catalog ~0ms / stale auto-incremental)
    On Error Goto RebuildAndRetry
    Set dq = db.CreateDominoQuery()
    dq.RefreshDesignCatalog = True
    Set RunDql = dq.Execute(query)
    Exit Function

RebuildAndRetry:
    ' Phase 2: brand-new NSF (no catalog) → Rebuild + retry
    If InStr(Error$, "needs to be cataloged via updall -e") = 0 Then Error Err
    Set dq = db.CreateDominoQuery()
    dq.RebuildDesignCatalog = True
    Set RunDql = dq.Execute(query)
End Function

Properties:

• ✅ 99% of queries: ~0ms overhead
• ✅ Design changes: auto incremental refresh
• ✅ Brand-new NSF: catch + Rebuild bootstraps it once
• ✅ No in-memory cache, no reset, no SOP needed

Sibling properties

Two more “sync before next query” properties live on the same object: RefreshFullText (refreshes the FT index before the query) and RefreshViews (refreshes any view the query will touch). Same True → next-Execute-syncs pattern.

Permissions: catalog operations require Designer-level ACL

Both RefreshDesignCatalog and RebuildDesignCatalog write into the NSF’s catalog design elements, which requires at minimum Designer-level ACL. Regular users (Reader / Author / Editor) running the operation get:

NotesException: DQL execution failed ... cause=[
Domino Query execution error:
您沒有權限執行此作業 (You don't have permission to perform this operation)
]

⚠️ The Final pattern above looks fine in code, but deploy it to production where regular users trigger it and you’ll wall straight into permissions. Catalog operations cannot run as the end user.

Why some contexts hit this and some don’t: execution identity

Catalog operations run as the identity in effect when DQL is invoked. Different deployment models have different identities:

The key observation: a Java helper class doesn’t “automatically carry” signer identity. Even if the Java code was written by the developer and the JAR was signed by an admin, when called from SSJS it inherits the calling identity (the logged-in user). Elevation must happen on the SSJS side, by opening the Database via sessionAsSigner.getDatabase() and passing that into Java. The Java side can’t elevate by itself.

XPages solution: sessionAsSigner

XPages SSJS has a sessionAsSigner global that returns a Session for the identity who signed the XPages app (typically an admin / Designer):

var dbPath = "CTI/EForm.nsf";

// Open the DB as the signer — catalog operations now have permission
var db = sessionAsSigner.getDatabase("", dbPath);

var util = new service.DQLUtil();
var result = util.executeQuery(db, dqlQuery);

Prerequisite: The XPages app must have been signed by an ID with at least Designer / Manager rights. Check Domino Designer → File → Application → Properties → Design tab → the “Signed by” field.

Safety caveat: reader-fields bypass

⚠️ Running queries via signer is essentially running them with admin rights — reader fields and ACL get bypassed. If your NSF uses reader fields to control “who sees which docs”, users running queries through your code may see docs they shouldn’t → data leak.

Defenses (recommended top-down):

1. Bake the user identity filter into the query (simplest): every query gets a wdocAuthor = 'CN=...' style explicit user filter; never write “list all” queries
2. Two-DB architecture: queries go through session.getDatabase() (user DB, ACL applies); catalog operations go through sessionAsSigner.getDatabase() (signer DB). The Java API splits into two parameters — more complex but safe

Outside XPages

sessionAsSigner only exists inside the XPages context. Alternatives elsewhere:

• Scheduled agent: write a scheduled agent with “Run on” set to the right server, signed by an admin ID, running catalog maintenance on schedule or on demand
• NotesFactory.createSessionWithFullAccess(): pure-Java path to an admin session, requires notes.ini to list FullAccessAdministrator. More dangerous, generally not recommended

Java production-ready helper

The full-pattern helper, including error enrichment and pairing with sessionAsSigner:

package service;

import lotus.domino.Database;
import lotus.domino.DocumentCollection;
import lotus.domino.DominoQuery;
import lotus.domino.NotesException;

public class DQLUtil {

    /**
     * Execute a DQL query.
     * @param db must be opened via sessionAsSigner.getDatabase() because catalog
     *           operations require Designer-level ACL
     * @param dqlQuery the DQL query string
     */
    public DocumentCollection executeQuery(Database db, String dqlQuery) throws NotesException {
        if (db == null) throw new NotesException(0, "DQLUtil: Database is null");
        if (!db.isOpen()) throw new NotesException(0, "DQLUtil: Database is not open");
        if (dqlQuery == null || dqlQuery.trim().isEmpty()) {
            throw new NotesException(0, "DQLUtil: query is empty");
        }

        String dbPath = safeFilePath(db);

        // Phase 1: Refresh + execute
        DominoQuery dql = null;
        try {
            dql = db.createDominoQuery();
            dql.setRefreshDesignCatalog(true);
            DocumentCollection col = dql.execute(dqlQuery);
            if (col == null) throw new NotesException(0, "DQL execute returned null");
            return col;
        } catch (NotesException firstError) {
            if (!isCatalogMissingError(firstError)) {
                throw rethrowWithContext(firstError, dbPath, dqlQuery);
            }
            System.out.println("DQL: catalog missing on [" + dbPath + "] — running Rebuild + retry");
        } finally {
            recycle(dql);
        }

        // Phase 2: Rebuild + retry (only reached for brand-new NSFs)
        DominoQuery dqlRebuild = null;
        try {
            dqlRebuild = db.createDominoQuery();
            dqlRebuild.setRebuildDesignCatalog(true);
            DocumentCollection col = dqlRebuild.execute(dqlQuery);
            if (col == null) throw new NotesException(0, "DQL execute returned null (after Rebuild)");
            return col;
        } catch (NotesException secondError) {
            throw rethrowWithContext(secondError, dbPath, dqlQuery);
        } finally {
            recycle(dqlRebuild);
        }
    }

    private static boolean isCatalogMissingError(NotesException ne) {
        String text = ne.text;
        return text != null && text.contains("needs to be cataloged via updall -e");
    }

    private static NotesException rethrowWithContext(NotesException ne, String dbPath, String query) {
        String causeText = (ne.text != null) ? ne.text : "(no text)";
        String enrichedMsg = String.format(
            "DQL execute failed [%s] query=[%s] cause=[%s]", dbPath, query, causeText
        );
        NotesException rethrow = new NotesException(ne.id, enrichedMsg);
        rethrow.setStackTrace(ne.getStackTrace());
        return rethrow;
    }

    private static void recycle(DominoQuery dql) {
        if (dql != null) {
            try { dql.recycle(); } catch (NotesException ignore) {}
        }
    }

    private static String safeFilePath(Database db) {
        try { return db != null ? db.getFilePath() : "null"; }
        catch (NotesException e) { return "<unable to get path>"; }
    }
}

SSJS caller:

var db = sessionAsSigner.getDatabase("", "CTI/EForm.nsf");
var util = new service.DQLUtil();
var result = util.executeQuery(db, dqlQuery);

Catalog-related error message lookup

📚 End of the trilogy

• Part 1: DQL Getting Started — why DQL exists, basic syntax, calling from various languages
• Part 2: DQL Pitfalls — 6 query-writing details the docs don’t spell out
• Part 3: DQL Production-Ready (you just finished) — catalog maintenance and permissions

Hit a trap that’s not covered here? Let me know — I’ll keep updating the series.
