DQL Pitfalls: 6 Query-Writing Details the Official Docs Don't Spell Out

📚 The “DQL Trilogy” series

• Part 1: DQL in Practice: SQL-Looking Syntax, Notes-Specific Traps Everywhere
• Part 2: DQL Pitfalls (you are here)
• Part 3: DQL Production-Ready: Catalog Maintenance, Permissions, and sessionAsSigner

After writing a few DQL queries, you’ll find that the “near-SQL syntax” pitch is genuinely surface-only — under the hood is the Notes engine, with its own set of details the docs don’t spell out and SQL intuition won’t save you from.

This article catalogs 6 traps from real-world testing, each with the verbatim error message and a working fix. Skim it before writing DQL — it’ll save you hours of debugging.

If you haven’t seen the basics or how to call DQL from LotusScript / Java / REST API, start with Part 1 DQL Getting Started; if you’re shipping DQL to production and need to handle the catalog and permissions, head to Part 3 Production-Ready.

Using a view as the base: view selection scopes the result

The HCL View column requirements doc states that the 'view'.column syntax requires the view to use Select @All.

What actually happens if the view’s selection isn’t Select @All? We tested it on Domino 12.

A view called Vtest with this selection (very common Notes pattern, not Select @All):

SELECT Form="Ftest" & deleteFlag !="1"

Three documents in the NSF:

Two queries:

Result: the runtime doesn’t reject queries against views that aren’t Select @All — no error, no warning. But DQL scopes the result to the docs the view’s selection has filtered in, so docs the selection excludes don’t show up.

Why

DQL reuses the Notes view’s existing column index directly, and that column index only contains docs satisfying the view’s selection formula. So “results are scoped to the view’s selection” is just the natural consequence of the underlying Notes architecture — HCL gets the speed of the existing Notes engine for free, in exchange for inheriting the scope of the view selection.

The official “require Select @All” reads more like a strong recommendation: it’s the way to ensure the view spans the whole DB, so the column index has clean DB-wide semantics.

Practical guidance

• View design under your control: change the selection to Select @All to match the official recommendation
• View design not under your control (e.g. someone else’s view, can’t change it): use in ('viewname') and field = value instead — that form isn’t scoped by view selection (the cost is the planner may fall back to an NSF scan)
• Don’t want to deal with views at all: bare-field field = value, let DQL find a view with a collated column for you

For a cleaner long-term solution: build dedicated DQL index views (use a dql prefix or a hidden ($DQL) category), Select @All selection, separate from the views your UI uses. 'dqlVtest'.Form = 'Ftest' then runs fast and has clean semantics.

Sidebar: column collation is a separate rule

Beyond the selection consideration, the referenced column must be collated (either condition counts):

• View’s leftmost column has “Sort order: Ascending” checked
• The column itself has “Click on column header to sort: Ascending” checked

This rule IS enforced — DQL errors out if the column isn’t collated, unlike the selection rule which silently scopes the result.

The column in 'view'.column is the column’s programmatic name, not the field name

This is a high-frequency conceptual trap. 'vwMyJob'.wdocAuthor reads like “look up the wdocAuthor field in view vwMyJob” — but DQL doesn’t look up document fields here. It looks up the view column’s “Name for programmatic use” in Designer’s column properties.

The two often happen to match, which is why people assume they’re the same thing — but any of these break that assumption and produce an immediate error:

1. The column has an auto-generated name ($55, $3 etc.) — Designer assigns these when you create a column without explicitly setting a name
2. The column is a formula, not a single field, e.g. WDocAuthor:WDocAuthorAgent (concatenating two fields)
3. The column’s programmatic name was intentionally set to something different from the field

Actual error message (column Approver has programmatic name $55 in Designer, formula WDocAuthor:WDocAuthorAgent; queried as 'vwMyJob'.wdocAuthor):

Domino Query execution error:
Entry not found in index -  validation error

Error validating view column name - ['vwMyJob'.wdocAuthor]
 ..  incorrect column name or no valid sorted column (bad position, collation or categorized)

'vwMyJob'.wdocAuthor = 'CN=user01/O=TheNet'

(Call hint: NSFCalls::NSFItemInfo, Core call #0)

“Incorrect column name” is DQL saying “there’s no column named wdocAuthor in vwMyJob” — because the column’s programmatic name is $55, not wdocAuthor.

Where to find the programmatic name

In Designer, open the view → click the column → right-side properties panel → switch to the “Programmatic use” (程式設計時使用) tab → “Name” is what DQL knows the column by.

If you see $N auto-numbering there, rename it to something meaningful (e.g. wdocAuthor) so DQL can resolve it.

Two fixes

1. Rename the column’s programmatic name in Designer’s “Programmatic use → Name”, save, then refresh the catalog

2. Switch to in() syntax:

   in ('vwMyJob') and wdocAuthor = 'CN=user01/O=TheNet'

   in() doesn’t depend on column programmatic names — DQL evaluates wdocAuthor directly against the document fields, regardless of how the columns inside the view are named.

Comparison operators require whitespace on both sides

The DQL parser is stricter about token whitespace than SQL parsers ——

The actual error message when you skip the spaces (heads up: it’s misleading):

Domino Query execution error:
Query is not understandable -  syntax error   - must have at least one operator

'(personal\pendingSignDoc)'.wdocAuthor='CN=user01/O=TheNet'

(Call hint: OSCalls::OSLocalAllc, Core call #0)

“Must have at least one operator” is wildly misleading — = is right there. The DQL tokenizer splits tokens on whitespace, so without spaces the whole wdocAuthor='CN=user01/O=TheNet' becomes one mystery token with no recognized operator inside. The error doesn’t sound like it’s about whitespace, but the fix is to add whitespace.

Treat =, <, >, <=, >=, != as always needing a space on each side.

This trips up anyone coming from SQL — Form='Customer' and Form = 'Customer' are interchangeable in SQL parsers, but not in DQL.

Backslash (\) in view names needs escaping

Notes view names can contain backslashes for hierarchical categorization, e.g. the hidden view (personal\pendingSignDoc) (parens = hidden, backslash = nested category). Writing the backslash raw in DQL gets it eaten somewhere along the way, and the resulting error message looks identical to “Design Catalog isn’t built”:

Domino Query execution error:
Entry not found in index -  syntax error

Error validating view column name - ['(personalpendingSignDoc)'.wdocAuthor]
 ..  invalid view name or database needs to be cataloged via updall -e

'(personalpendingSignDoc)'.wdocAuthor = 'CN=user01/O=TheNet'

(Call hint: NSFCalls::NSFDbGetNamedObjectID, Core call #0)

Notice the view name in the error is (personalpendingSignDoc) — the backslash is gone. The “please run updall -e” hint sends you down the wrong rabbit hole; the real issue is escaping, not the catalog.

Side-by-side:

Same for in() syntax:

in ('(personal\\pendingSignDoc)') and wdocAuthor = 'CN=user01/O=TheNet'

Why the double backslash?

The DQL parser itself treats \\ as a single \ (\ is an escape character in DQL string literals). So if you want a literal \ in the view name, the query string DQL receives must contain \\.

But how many \ you write in source gets multiplied or chewed by your language’s string handling:

LotusScript string literals don’t escape \ (the way to embed a quote is "" doubled), so two slashes in source = two slashes in the value. Java / Node.js / JSON string literals collapse \\ to a single \, so you need four backslashes in source to end up with two in the string value.

Real-world report: an engineer hit this in Node.js / JSON and wrote a single \ in source. JSON parsing ate it, DQL never saw any \, and the view name turned into (personalpendingSignDoc) instead of the real (personal\pendingSignDoc).

DQL is case-insensitive (and accent-insensitive) — this one is good news

The HCL DQL syntax doc states explicitly:

“Text string evaluation is case insensitive and accent insensitive.”

Real-world behavior:

All three of these are equivalent:

'vwMyJob'.wdocAuthor = 'CN=user01/O=TheNet'
'VWMYJOB'.WDOCAUTHOR = 'cn=USER01/o=thenet'
'vwmyjob'.WdocAuthor = 'cn=user01/o=thenet'

The view name, the column programmatic name, and the value comparison — all three are case-insensitive.

Accent-insensitivity is a bonus — 'café' matches 'cafe' and vice versa, useful for European-language data.

⚠️ If you actually need a case-sensitive comparison, DQL’s = doesn’t have a case-sensitive variant — you’ll need to filter the results in app code (LotusScript StrCompare, Java string compare, etc.) after fetching.

@formula(...) is a separate Formula Language parser

One of the most common questions from Notes developers: “Can DQL use the @Functions I already know?” — yes. DQL provides @formula(...) (also writable as @fl() or @FORMULA(), case-insensitive) to embed a Formula Language expression into a query.

Case study: find documents whose docno starts with 056

Say docno looks like "056123456789" and you want all documents whose first three characters are 056.

Two ways:

-- Option A: embed @Left via @formula
@formula('@Left(docno;3) = "056"')

-- Option B: native DQL like + wildcard (recommended)
docno like '056%'

Same result, very different performance:

@formula conditions don’t get optimized by the view index. Use native like / contains / = / in / between whenever they can express the predicate. Reach for @formula only when native syntax can’t.

@formula syntax notes

@formula('@Left(docno;3) = "056"')

Three details that catch people out:

1. The whole formula is wrapped in single quotes
2. Strings inside the formula use double quotes (avoiding the outer single-quote conflict)
3. Function arguments are separated by ; (Formula Language convention, not commas)

Important: DQL-native @ and Formula Language @Function are two different worlds

DQL actually has two parser contexts that don’t recognize each other’s @ functions:

Inside @formula, DQL-native @dt / @all / @ftsearch are not recognized, and vice versa — DQL-native syntax doesn’t recognize Formula Language @Year / @Left outside @formula. The two parsers are isolated.

Real-world trap: @dt written inside @formula

'vwMyJob'.wdocAuthor = 'CN=USER05/O=thenet'
  and @formula('@Year(@dt(ApplyDate)) = "2021"')

DQL hands the contents of @formula('...') to the Formula compiler, which sees @dt and doesn’t recognize it:

Formula Error -  error during planning and tree generation
Error filling node for @Year(@dt(ApplyDate)) = "2021"

(Call hint: NSFCalls::NSFFormulaCompile, Core call #0)

The right rewrite depends on two things: the intent (extract the year vs range comparison) and what ApplyDate actually is (a real date field or a string).

Intent A: check whether ApplyDate’s year is 2021 — use Formula Language

If ApplyDate is a true date field:

@formula('@Year(ApplyDate) = 2021')

If ApplyDate is stored as a string (very common in older Notes apps), you have to convert it with Formula’s @TextToTime first:

@formula('@Year(@TextToTime(ApplyDate)) = 2021')

💡 Field-tested (reader-reported): lots of real-world Notes apps store ApplyDate as a string. @Year(ApplyDate) directly fails on a string — @TextToTime is the missing step. The string format has to be one Notes recognises (e.g. "2021/05/15" or "2021-05-15") for @TextToTime to parse.

In both cases the comparison value is the number 2021, not the string "2021" (@Year returns a number; comparing it to a string fails).

Intent B: do a date range comparison and let view indexes help — use DQL native, drop @formula entirely

ApplyDate >= @dt('2021-01-01') and ApplyDate < @dt('2022-01-01')

This is faster than the @formula version because native DQL conditions can use view indexes — but only if ApplyDate is actually a date field. If it’s a string, native DQL does a string comparison rather than a date comparison, and the result may be wrong unless your strings happen to be in a sortable format like ISO 8601 (where string ordering equals date ordering).

“If native syntax can express it, prefer native” is the general rule (echoing the optimization pattern below) — but for string-stored dates, you may be stuck with @formula('@Year(@TextToTime(...)) = 2021'). To get the native-optimization path, the field type also has to be clean.

DQL-native @ function reference

These work only in the DQL body — putting them inside @formula(...) triggers a Formula compile error.

When you actually need @formula

Conditions that native DQL syntax can’t express:

@formula('@Year(orderDate) = 2026')              -- date functions
@formula('@Length(content) > 1000')              -- string length
@formula('@Modulo(amount; 100) = 0')             -- numeric arithmetic
@formula('@Matches(title; "[A-Z]??-2026-*")')    -- pattern matching

Optimization pattern: native pre-filter + @formula fine-filter

@formula and native DQL conditions compose with and / or. The recommended pattern: let native conditions do the coarse filter and @formula do the fine filter.

Form = 'Order' and @formula('@Year(orderDate) = 2026')

The DQL planner uses Form = 'Order' first (with view-index optimization if available) to narrow the candidate set, then applies the @formula predicate on what’s left. Much faster than throwing a single @formula at the whole NSF.

Restrictions (HCL Formula Language in DQL)

• Each @formula text term is capped at 256 bytes
• Not every @Function is supported — HCL lists a 130+ supported subset (@Left, @Year, @Contains, @Matches, @Length, @Modulo, @Lowercase, etc. — most common ones are in)
• DQL doesn’t validate Formula syntax before executing — errors surface only at runtime
• Substitution variables (?varname) don’t work inside @formula, but they do work outside the clause: @fl('@doclength') > ?doclengthval

Trap-error message lookup

A quick reference for matching error messages to root causes:

📚 Next: DQL Production-Ready: Catalog Maintenance, Permissions, and sessionAsSigner

Once you can write queries that work, the next hurdle is shipping to production: how the catalog is auto-maintained, how design changes propagate, and why regular users hit permission errors. Part 3 walks the full real-world pattern.

For basic syntax and how to call DQL from LotusScript / Java / REST API, head back to Part 1 DQL Getting Started.
