Getting Started with DQL: Query Notes Documents with SQL-Style Syntax

📚 The “DQL Trilogy” series

• Part 1: DQL Getting Started (you are here)
• Part 2: DQL Pitfalls: 6 Query-Writing Details the Official Docs Don’t Spell Out
• Part 3: DQL Production-Ready: Catalog Maintenance, Permissions, and sessionAsSigner

Why DQL exists

Notes developers traditionally rely on three ways to retrieve documents:

1. View lookups (NotesView.GetDocumentByKey, GetAllDocumentsByKey, GetAllEntriesByKey) — fastest and most intuitive: design a view with a sorted key column, then look up by key. The cost is design bloat — almost every query shape needs its own view.
2. NotesDatabase.Search — selects documents with an @Formula expression scanned across the whole NSF. No view required, but every call walks every document; fine for one-off admin tasks, painful for hot paths.
3. NotesDatabase.FTSearch — uses the full-text index, supports word stems and boolean keywords. Great for “find documents that mention these words”, but it needs an FT index, and structured-field queries (numeric ranges, complex boolean) are weaker than view-based lookups.

Domino Query Language (DQL), introduced in V10 and stabilized through V12, is the fourth option: a near-SQL syntax that queries documents directly while automatically using the design catalog and existing view indexes, falling back to a full scan when no index can answer the query. The advantage is that you don’t need a dedicated view per query shape, conditions compose naturally, and the same query string runs from LotusScript, Java, and the Domino REST API.

The hard truth: DQL’s “familiar syntax” is only skin deep

Developers picking up DQL often get misled by the “near-SQL syntax” pitch and assume it’ll be a smooth ride coming from SQL or the traditional Notes API. It isn’t. DQL looks like SQL on the surface, but under the hood is the Notes engine with its own set of details to watch for:

• Query-writing traps: view selection silently scoping results, 'view'.column referring to the column’s programmatic name (not a doc field), whitespace required around operators, backslash escaping in view names, @formula being a separate parser, string-stored dates needing @TextToTime — all covered in Part 2 Pitfalls
• Production traps: how the Design Catalog is maintained, why regular users hit permission errors, the sessionAsSigner pattern — all covered in Part 3 Production-Ready

This Part 1 covers the basics: what DQL is, how to write a first query, how to call it from each language, and a syntax cheat sheet. After this article you can start using DQL; before shipping to production, make sure to read Parts 2 and 3 as well.

A first DQL query

The simplest DQL expression looks like this:

Form = 'Customer' and Country = 'Taiwan'

Three things to notice:

• Field names are unquoted
• String values use single quotes
• Operators include =, <, <=, >, >=, in, contains, like

More examples:

Form = 'Order' and OrderDate >= @dt('2026-01-01') and Total > 10000

Form in ('Invoice', 'CreditNote') and Status = 'Open'

Subject contains 'Domino' and Author like 'Bryan%'

💡 Queries that reference a view name require a Design Catalog first. How to maintain the catalog automatically and handle permissions is covered in Part 3 Production-Ready. Bare-field queries (no view reference) don’t need the catalog.

Calling DQL from LotusScript

In LotusScript, DQL is exposed via the NotesDominoQuery object:

Sub QueryCustomers
  Dim session As New NotesSession
  Dim db As NotesDatabase
  Set db = session.GetDatabase("", "crm.nsf")

  Dim dq As NotesDominoQuery
  Set dq = db.CreateDominoQuery()
  dq.UseViewRefreshing = False  ' fast, but may miss just-saved docs

  Dim result As NotesDocumentCollection
  Set result = dq.Execute("Form = 'Customer' and Country = 'Taiwan'")

  Print "Found " & result.Count & " documents"

  Dim doc As NotesDocument
  Set doc = result.GetFirstDocument()
  Do While Not doc Is Nothing
    Print doc.GetItemValue("CustomerName")(0)
    Set doc = result.GetNextDocument(doc)
  Loop
End Sub

To inspect which index DQL chose and how long each step took, enable Explain:

dq.Explain = True
Print dq.ExplainResult  ' prints the query plan and timings

Calling DQL from Java

The Java API has the same shape:

import lotus.domino.*;

Session session = NotesFactory.createSession();
Database db = session.getDatabase("", "crm.nsf");

DominoQuery dq = db.createDominoQuery();
dq.setExplain(true);

DocumentCollection result = dq.execute(
    "Form = 'Order' and OrderDate >= @dt('2026-01-01')"
);

System.out.println("Hits: " + result.getCount());
System.out.println(dq.getExplainResult());

Document doc = result.getFirstDocument();
while (doc != null) {
    System.out.println(doc.getItemValueString("OrderNo"));
    Document next = result.getNextDocument(doc);
    doc.recycle();
    doc = next;
}

Calling DQL from the Domino REST API

The Domino REST API (DRAPI, formerly Project Keep) exposes a /query endpoint:

POST /api/v1/lists/dql HTTP/1.1
Host: domino.example.com
Authorization: Bearer eyJhbGc...
Content-Type: application/json

{
  "query": "Form = 'Customer' and Country = 'Taiwan'",
  "max": 50
}

Response:

{
  "items": [
    {
      "@unid": "ABCD1234...",
      "CustomerName": "Acme Co.",
      "Country": "Taiwan"
    }
  ],
  "count": 1
}

Quick syntax reference

Performance tips

1. Use a view as the base — 'ViewName'.Field = ... is faster than a bare field (watch for view-selection scoping)
2. Avoid leading wildcards — like '%abc' cannot use an index
3. Turn on Explain — dq.Explain = True shows the actual execution path
4. First-hits mode — when you only need a few results, use Execute(query, "", 0, 10) to cap the count
5. Parallelize big scans — set QUERY_MAX_NUMBER_THREADS=4 in notes.ini to parallelize NSF scans

Common errors

• “No design catalog found” — run load updall -e or trigger setRebuildDesignCatalog(true) (details in Part 3)
• “needs to be cataloged via updall -e” — NSF never catalogued (Refresh vs Rebuild in Part 3)
• “You don’t have permission” — catalog ops require Designer ACL (sessionAsSigner solution in Part 3)
• “must have at least one operator” — missing whitespace around comparison operator (details in Part 2)
• “incorrect column name” — wrong column programmatic name (details in Part 2)

📚 Next up

Part 2: DQL Pitfalls — 6 Query-Writing Details the Official Docs Don’t Spell Out

After writing your first query, you’ll quickly run into “unexpected results” or “mystery errors.” Part 2 walks through each trap with the verbatim error message and a working fix.

Part 3: DQL Production-Ready — Catalog Maintenance, Permissions, and sessionAsSigner

The last mile before shipping: automatic Design Catalog maintenance, the sessionAsSigner permission pattern, and a production-ready Java helper class.
