Domino Transaction Logging: It Replaces Routine Fixup

Oct 13, 2026 1,277 words

If you’ve seen the Domino maintenance-command rules, you’ll have noticed that “is transaction logging on?” is always the branch that decides everything: with logging, don’t schedule fixup routinely; compact with -b, not the file-shrinking -B; and after anything that changes the DBIID, take a fresh full backup immediately.

How does one setting flip so many rules at once? Because transaction logging changes how Domino protects data and recovers from a crash at the lowest level. This piece lays it out — what it is, how the three styles differ, and why it ties into fixup, compact, and your backups. (For the maintenance commands themselves, see Domino maintenance commands in practice; this piece is the why behind those “is translog on?” branches.)

TL;DR

What it does: records every database change on the server into one transaction log first, in batches (log extents Sxxxxxxx.TXN plus a control file NLOGCTRL.LFH).
Crash recovery: on restart, Domino runs to the end of the log and recovers the writes that weren’t on disk at the time of the crash. In HCL’s words: “Logged databases do not require a consistency check” — so a logged database needs no consistency check, and no routine fixup.
Three styles: circular (default, fixed space, 4GB ceiling, overwrites the oldest), linear (like circular but no 4GB ceiling), archived (log extents are reused only after a backup tool archives them; with no backup tool new log files keep accumulating and can fill the log disk). archived is the style built for the archive-and-media-recovery workflow; circular and linear are mainly for crash recovery.
Why it drives the DBIID: log records are tied to a database’s DBIID. Operations that rebuild a database — enabling logging the first time, changing the logging style, a copy-style / file-shrinking compact, or fixup on a corrupt database — assign a new DBIID, which invalidates the old log records, so you must take a fresh full backup afterward. In-place -b compaction keeps the DBIID — that’s exactly why.
Setup: enable it on the Server document’s Transactional Logging tab (restart required); give the log its own dedicated / mirrored disk (at least 1GB).

What it does: changes go to a log first

Without logging, Domino writes changes straight into each NSF; a crash mid-write can leave a database inconsistent, and you lean on fixup to scan it afterward.

With transaction logging on, changes are written into one central transaction log first, in batches (one per server, stored as Sxxxxxxx.TXN log extents plus an NLOGCTRL.LFH control file), then flushed to the individual databases. That buys two kinds of recovery:

Crash recovery: on restart, Domino “runs through the end of the transaction logs and recovers any writes that were not made to disk at the time of the crash” — it reapplies, from the log, the writes that hadn’t hit disk when the crash happened (official Transaction logging concept).
Media recovery: with a third-party backup tool that uses the Domino C API Toolkit, you can restore a full backup and then apply the logged updates made since that backup, bringing the database up to a more recent state.

The three styles: circular / linear / archived

There are three styles for how the log reclaims space:

circular (default): writes into a fixed-size space in a loop, overwriting the oldest once full. Maximum 4GB (Maximum log space defaults to 500MB, caps at 4096MB). Crash recovery only, simplest performance.
linear: overwrites like circular, but with no 4GB ceiling — for when you want more log space than 4GB and aren’t on archive media yet.
archived (HCL’s eventual recommendation): a log extent is reused only after a backup tool archives it. It’s the style built for the traditional archive-and-media-recovery workflow (a Domino C API Toolkit backup tool) (official: transaction logging with backup and restore); the catch is that without a backup tool to archive them, Domino keeps creating new log files that only pile up and can fill the log disk. HCL’s guidance: start with circular or linear, and move to archived only if you actually need it.

Why it “replaces” routine fixup

This is the root of the familiar “with translog, don’t schedule fixup” rule. HCL is blunt: a logged database “do[es] not require a consistency check” — because on a crash restart Domino has already used the log to recover it to a consistent state, so fixup doesn’t need to scan it again.

So fixup becomes a fallback in a logged environment: the Server document’s “Automatic fixup of corrupt databases” is on by default, and only when Domino can’t recover a database even from the log does it run fixup on it automatically. You almost never need fixup as routine maintenance (which is why the maintenance-commands piece says “with logging on, don’t run fixup routinely”).

How it drives compact and the DBIID

The link between logging and compact is the DBIID (database instance ID). Every record in the log is tied to a database’s DBIID; once a database is rebuilt and gets a new DBIID, the old log records no longer match and are invalid.

Operations that reassign the DBIID:

Enabling logging on a database for the first time, or changing the logging style (official: “After you change the logging style, Domino assigns a new DBIID to each database”).
A copy-style or file-shrinking compact (-c, -B) — those effectively rewrite the database.
fixup on a corrupt database.

After any of these, the old log can’t follow the new database, so you must take a fresh full backup to rebase your backup on the new DBIID. In-place -b compaction (reclaim space only, no file shrink) keeps the DBIID — which is exactly why the maintenance piece says “with logging, compact with -b, not -B”: -b doesn’t break the database-to-log relationship.

Setup: the Server document + a dedicated disk

You enable it on the Server document’s Transactional Logging tab (official steps):

Transactional Logging: set to Enabled — a restart is required for it to take effect.
Log path: defaults to \LOGDIR under the data directory, but HCL recommends a separate, mirrored disk (e.g. a RAID 0/1 device with its own controller), at least 1GB; Domino formats between 3 and 64 log files. Putting the log on the same disk as the data costs you on both performance and safety.
Maximum log space: for circular / linear, default 500MB, cap 4GB.
Automatic fixup of corrupt databases: on by default — the fallback when the log can’t recover a database.
Runtime/Restart performance: Standard by default; you can favor runtime (fewer checkpoints) or restart recovery (more checkpoints).

How to check whether it’s on

Three places confirm it:

The Server document (most authoritative): on the Transactional Logging tab, is “Transactional logging” set to Enabled, and which style? This is where the setting comes from.
notes.ini: TRANSLOG_Status=1 means on (0 or absent means off); TRANSLOG_Style tells you the style (HCL wiki: 0 = circular, 1 = archived, 2 = linear). Note: these TRANSLOG_* values are written from the Server document and get overwritten by it — read them to see the current state, but change it in the Server document, not by editing notes.ini directly (a direct edit won’t stick).
The log path: when on, the log directory (default LOGDIR under the data directory) holds Sxxxxxxx.TXN log extents and an NLOGCTRL.LFH control file; when off, those files aren’t there.

Wrap-up

What it is: database changes are written into one central transaction log first, then flushed to the NSFs.
What you get: automatic recovery on a crash restart, and logged databases need no consistency check — so fixup drops to a fallback, not routine maintenance.
Three styles: circular (default, ≤4GB, overwrites) / linear (no 4GB ceiling) / archived (needs a backup tool to archive, for the archive / media-recovery workflow; without one the log files pile up and can fill the disk).
DBIID link: enabling logging, changing the style, a copy-style / file-shrinking compact, or fixup on a corrupt database all reassign the DBIID and invalidate the old log → take a fresh full backup afterward; in-place -b keeps the DBIID.
Setup: enable on the Server document’s Transactional Logging tab (restart required), with the log on a dedicated / mirrored disk (≥1GB).
