The ODS Developers Rarely Notice: Domino's Database Format Versions, and What Actually Triggers an Upgrade

As a developer you spend all day in LotusScript, XPages, and agents, and you’ve probably never actively wondered: the database you’re working with — which version is its underlying file format? That version is the ODS (on-disk structure), and normally it’s invisible, until one day it suddenly becomes a problem —

• you want to use a feature (like the LargeSummary covered in the previous article) and it requires the database to be at a certain ODS or higher;
• or you move an old database around between servers and can’t tell whether the ODS follows, or when it changes.

This article lays out, from a developer’s angle, how ODS has evolved and — the key part — what triggers an upgrade and what governs it, then answers a very concrete case a lot of people are unsure about: an R9-era, ODS 51 database, manually new-copied from an R12 client to a second R12 server — does its ODS change automatically?

TL;DR

• ODS = a database’s file-format version. Each Domino release has a default ODS; a higher ODS unlocks bigger databases, more ACL entries, LargeSummary, and so on.
• The counterintuitive part: upgrading the server version does not upgrade the ODS. Per the official table, new databases on Domino 12 / 14 still default to ODS 52; to get ODS 55 you must set Create_R12_Databases=1.
• Just opening an old database on a newer server does not auto-upgrade its ODS. Only a copy-style compact (compact -c / dbmt -ods) does.
• The target ODS is governed by the notes.ini Create_Rx_Databases setting (unset = default 52).
• A new copy / new replica is “creating a new file” → it takes the create-ODS of wherever the file is created; a plain OS-level file copy preserves the ODS as-is.
• The Notes client, on startup, auto-upgrades local databases below the default ODS via copy-style compact (a client behavior; servers don’t do this).

What ODS is (the developer version)

The official definition is short: “Domino on-disk structure (ODS) refers to the file format of a database.” It’s the database’s file-format version.

For a developer, ODS is something you usually ignore — but it decides “what this database can withstand.” A higher ODS unlocks capabilities older formats can’t do: larger database ceilings, more ACL entries, and the LargeSummary from the last article (raising a single document’s summary limit from 64K to 16MB). So ODS isn’t purely an ops topic — the moment you want a feature that “needs a certain ODS or higher,” it becomes your problem.

Mapping: which ODS goes with which release

The common mapping (modern rows per the official HCL ODS documentation):

Notice that 52 spans several generations — which is exactly where the next, counterintuitive point comes from.

The counterintuitive part: upgrading the server ≠ upgrading the ODS

Many people assume “the server is on R12 / R14, so the database’s ODS is automatically the newest.” It isn’t.

The server-side ODS control docs are explicit: new databases on Domino 12 / 14 still default to ODS 52; to use ODS 55 you must set:

Create_R12_Databases=1

And simply “opening” an old-ODS database on a newer server, or using it day to day, does not auto-upgrade its ODS. Verbatim: existing databases are only upgraded to the target version when they “are compacted using copy-style compacting.” In other words — ODS does not jump up just because you moved to a new server or opened it a few times.

So when does the ODS actually change?

Organize the triggers into three groups — this is the table to remember:

ODS does NOT change:

• An OS-level file copy (copying the .nsf directly) — no rewrite, ODS preserved as-is.
• Just opening / using / replicating data.
• In-place maintenance: fixup, updall, in-place compact (the kind that doesn’t rebuild the file).

ODS DOES change:

• Copy-style compact (load compact -c, or preferably load dbmt … -ods) — it rewrites the whole database at “the destination’s create-ODS.” This is the only upgrade path the docs explicitly name.
• Creating a New Copy / New Replica — this is “creating a new database file,” and the new file takes the create-ODS of “whichever machine the file is created on.”
• The Notes client’s startup auto-upgrade — after startup the client checks for local databases below the default ODS and copy-style-compacts them up to the client default (a client-only behavior; servers don’t do this).

What governs the target ODS:

Whether it’s a new file or a copy-style compact, the ODS it lands at is governed by the notes.ini Create_Rx_Databases setting on “the machine where the file is created / rewritten”:

Back to your case: ODS51, new-copied from an R12 client to R12 ap02

Now we can answer precisely. An R9-era database stuck at ODS 51 (originally on ap01), manually “new-copied” from an R12 client to R12 ap02 — does its ODS change?

It depends on what “new-copy” means:

• If it’s a New Copy / New Replica (creating a new database through Notes): this creates a new file on ap02, so the new file’s ODS = ap02’s create-ODS:
  • ap02 without Create_R12_Databases=1 → the new file is ODS 52 (it leaves 51, but it will not be 55).
  • ap02 with Create_R12_Databases=1 → the new file is ODS 55.
  • Either way, the result does not stay at ODS 51 — because it’s a new file taking the destination’s settings, not inheriting the source.
• If it’s an OS-level file copy (moving the .nsf directly): no rewrite, so ODS 51 is preserved.
• If the copy lands in the client’s local data directory: the client will copy-style-compact it up to the client’s default ODS on its next startup.

So “does it change automatically?” The answer is: it depends on whether you do a “new copy/replica” or a “file copy,” and on the destination’s Create_Rx_Databases setting. A lot of people assume “R12 means the newest ODS” or “a copy always preserves the original ODS” — both intuitions are wrong in different situations. The real decider is “where the new file gets created, and how that machine is configured.”

How to check, how to control

• Check a database’s ODS: it’s shown in the database properties; on the server you can also use a command like show database <db> to see format info.
• To upgrade an existing DB: set Create_Rx_Databases=1 on the destination server, then run a copy-style compact on the DB (prefer load dbmt … -ods; the -ods flag skips databases already at the target ODS so you don’t compact for nothing).
• To deliberately keep an old ODS (for compatibility): don’t run a copy-style compact and don’t New-Copy it on a higher-configured server; an OS-level file copy preserves the format.

How this connects to LargeSummary

This also completes the chain the previous LargeSummary article left open. That piece described a trap: a customer’s database was upgraded from R9 to R12, its ODS looked like 55, yet LargeSummary was off.

Put the two together and the full set of layers is:

server version (R12/R14)
   ↓ does NOT auto-upgrade ODS
ODS version (needs Create_R12_Databases=1 + a copy-style compact to reach 55)
   ↓ ODS55 only means "the structure can hold it", not "the feature is on"
LargeSummary (still needs compact -LargeSummary on to actually enable)

Every layer is “necessary but not sufficient” — upgrading the layer above does not pull the one below up with it. ODS is the bottom of that chain, the layer developers most easily ignore, yet the one that decides whether the layers above can be unlocked at all. Next time a feature “won’t work even though the version is clearly new enough,” check the ODS and its create settings first — the answer is often right there.
