DDM: Domino's Built-in Proactive Monitoring

Oct 24, 2026 975 words

Server trouble is usually “the users complain first, then you find out” — and by the time you notice, it’s often too late. DDM (Domino Domain Monitoring) is Domino’s built-in, proactive-leaning monitoring: it runs probes on a schedule to check the health of various feature areas, records events into ddm.nsf, gives you a domain-wide status view in the Domino Administrator, and can notify you automatically when something fires — often with a probable cause and a suggested fix. This piece walks through how DDM’s pieces fit together.

TL;DR

What DDM is: monitoring that lets you see the health of the whole domain from one place. HCL says it “Recognizes and reports critical server and client issues within minutes,” automatically determines probable cause (“determines probable cause”), and “Provides corrective actions and links to databases” — not just an alarm, but a next step.
Probes: a discrete check (or set of checks) run against one or more servers, databases, and services. HCL ships 50+ probes across ten areas: administration, application code, database, directory, messaging, operating system, replication, security, server, web. A probe’s configuration document lives in EVENTS4.NSF and edits take effect immediately; it can run on a default schedule, a custom schedule, or as needed when events occur.
ddm.nsf: the Domino Domain Monitor database, storing events from probes and other built-in checks. Each server has its own copy; a collection server’s copy also consolidates data from its subordinate servers.
Collection hierarchy: name one or more collection servers in EVENTS4.NSF, and you can see a server’s own plus its subordinates’ events in one place instead of opening ddm.nsf on each. The periodic collection interval is a fixed 5 minutes — it cannot be changed.
Event handler: a document (also in EVENTS4.NSF) defining what Domino does when an event occurs; carried out by the Event Monitor task, and only when a handler exists for the event. Methods (a dozen-plus in all) include: log to a database, mail, run an agent, run a program, send console commands, SNMP trap.

What DDM is: one place for the whole domain

Traditionally, checking server health meant connecting to each server and reading logs and the console. DDM centralizes that: in the Domino Administrator it gives a “top-down, feature-oriented view of the domain status” that you drill down from (official DDM overview).

Where it leans proactive: it doesn’t wait for you to dig through logs — it runs checks on its own, recognizes and reports critical issues within minutes, and — DDM’s most valuable part — it automatically determines probable cause and provides corrective actions with links to the relevant databases. So a DDM event usually tells you not just “it’s broken” but “probably why, and what to do.”

Events come in two kinds: enhanced events carry specific target info (which server, database, or agent), while simple events don’t. The views also use visual indicators for which problems are most critical, which are resolved, and which aren’t.

Probes: the hand that actually checks

What DDM actually uses to “check” is a probe. HCL’s definition: “A probe is a discrete check, or set of checks, configured to run against one or more servers, databases, and services.” (official DDM probes).

50+ built in, across ten areas: administration, application code, database, directory, messaging, operating system, replication, security, server, web. From “is a database’s view index corrupt” to “is replication stalling” to “are there security misconfigurations,” there’s a matching probe.
Configuration documents live in EVENTS4.NSF (the Monitoring Configuration database), and edits take effect immediately — no restart.
Scheduling comes in three forms: on a default schedule, a schedule you set, or as needed when events occur on a server.

To change what DDM checks and how often, you edit these probe documents in EVENTS4.NSF.

ddm.nsf and the collection hierarchy

The results a probe produces need somewhere to go — that’s ddm.nsf (the Domino Domain Monitor database): it stores the events from DDM probes and other built-in checks. The key point: each server has its own ddm.nsf.

If you had to open each one individually, you’d lose the “one place for the whole domain” benefit. So DDM has a collection hierarchy: name one or more collection servers in EVENTS4.NSF, and a collection server consolidates its subordinate (node) servers’ events — you open the collection server’s ddm.nsf and see its own plus the servers beneath it. The hierarchy can be multi-tiered, or just one level. One number to remember: the periodic collection interval is a fixed 5 minutes and cannot be changed.

Event handlers: how it tells you

DDM “detects and records,” but “whether and how to page you” is a separate mechanism: the event handler (official: event handler notification methods).

Event handler documents also live in EVENTS4.NSF and define what action Domino takes when an event occurs.
They’re carried out by the Event Monitor task, and only when a handler exists for that event — with no handler, the event just sits in ddm.nsf and nothing reaches you.
HCL lists a dozen-plus (13) notification/action methods; common ones are: log to a database, mail, run an agent, run a program, send console commands, SNMP trap — plus broadcast, pager, relay to another server, sound, log to the UNIX system log, and more.

So “DDM caught it but I got no alert” usually isn’t DDM failing to run — it’s that the event has no matching event handler. To be notified, create one in EVENTS4.NSF.

Wrap-up

DDM: built-in monitoring that shows the whole domain’s health from one place; reports within minutes, with probable cause and corrective actions.
Probes: discrete checks against servers/databases/services, 50+ built in across eight areas; configured in EVENTS4.NSF, edits immediate; default/custom/event-triggered scheduling.
ddm.nsf: stores events, one per server; a collection server consolidates its subordinates.
Collection hierarchy: name a collection server to see the whole domain in one place; the collection interval is a fixed 5 minutes; events are enhanced or simple.
Event handler: defined in EVENTS4.NSF, carried out by Event Monitor, notifies only if a handler exists; methods include log/mail/agent/program/console/SNMP.
